- Page 1 EDGER DOLLY Operator’s Manual...
-
Page 2: Table Of Contents
READ THIS BOOK This book has important information for the use and safe operation of this machine. Failure to read this book prior to operating or attempting any service or maintenance procedure to your American Sanders machine could result in injury to you or to other personnel;... - Page 3 DANGER: Failure to read the Owner’s Manual prior to operating or servicing your American Sanders machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well. You must have training in the operation of this machine before using it.
-
Page 4: Introduction
Introduction KNOW YOUR MACHINE 1. Seat Frame 2. Seat Cushion 3. Chest Pad 4. Seat Adjustment 5. Chest Pad Adjustment 6. Base Frame 7. Work Tray 8. Cord Hanger 9. Storage Hooks 10. Swivel Casters Figure 1 Machine Specifications Model 07246A Construction Welded Steel Tubing... -
Page 5: Machine Setup
Machine Setup 1. Insert the seat frame stem in the base frame tube. Be sure the seat 3. Connect the chest pad frame to the seat frame. Position it cushion is towards the closed-end of the base frame and the chest approximately 2”, (5 cm), from the seat cushion. -
Page 6: Operating Instructions
Operating Instructions Storage and Transportation 1. Follow all safety procedures and operation instructions outlined in the 1. Loosen the thumb screw and push the chest pad towards the middle edger manual. of the machine. 2. Remove the clevis pin and lower the seat frame to the bottom hole. 3. -
Page 7: Parts Manual
Edger Dolly Parts Manual Notes: ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________... - Page 8 Parts List ITEM PART NUMBER DESCRIPTION AS119100 FRAME, WELDMENT, EDGER DOLLY AS119500 SEAT, TOP, WELDMENT, EDGER DOLLY AS119900 SEAT ADJUSTER ASM., EDGER DOLLY AS120600 CASTER, EDGER DOLLY AS079200 DECAL, PINCH POINT MP038100 PIN, CLEVIS, 3/8" X 2-1/8" NB025600 PIN, PRESTO, 3/32 X 1 5/8, SS NB064900 SCREW, #10 x 1/2", TRUSS HD, PHIL.
-
Page 9: Warranty
Limited Warranty Edger Dolly TO QUALIFY FOR THIS WARRANTY INSTRUCTIONS AND CONDITIONS FOR WARRANTY REIMBURSEMENT (1) Machine must be registered within 30 days from the time of purchase l Order replacement part: Orders will be processed and charged, as on a form provided by American Sanders. Your American Sanders normal procedure. - Page 12 American Sanders an AMANO Company 1 Eclipse Rd • PO Box 909 Sparta, North Carolina 28675 • USA www.pioneereclipse.com www.americansanders.com +1-336-372-8080 1-800-367-3550 Fax 1-336-372-2913 LT091800_A Edger Dolly_A © 2023 American Sanders 032323...
