Amano American Sanders Super 7R Australia Operator's Manual

Hide thumbs Also See for American Sanders Super 7R Australia:
Table of Contents

Advertisement

Quick Links

Download this manual
Edger
Super 7R Australia
Operator's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the American Sanders Super 7R Australia and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Amano American Sanders Super 7R Australia

Summary of Contents for Amano American Sanders Super 7R Australia

  • Page 1 Edger Super 7R Australia Operator’s Manual...

  • Page 3: Table Of Contents

    READ THIS BOOK This book has important information for the use and safe operation of this machine. Failure to read this book prior to operating or attempting any service or maintenance procedure to your American Sanders machine could result in injury to you or to other personnel;...

  • Page 4: Operator Safety Instructions

    Operator Safety Instructions In this Operation Manual you will find three statements that you must read and observe to ensure safe operation of this machine. DANGER means: Severe bodily injury or death can occur to you or other personnel if the DANGER statements found on this machine or in this Operation Manual are ignored or are not adhered to.

  • Page 5: General Power Tool Safety Warnings

    General Power Tool Safety Warnings WARNING: Read all safety warnings and d) Remove any adjustment wrench or key before turning instructions. Failure to follow warnings and the power tool on. A wrench or key left attached to a instructions may result in electric shock, fire and rotating part of the power tool may result in personal injury.

  • Page 6: Safety Warnings For Sanding Operations

    Safety Warnings for Sanding Operations 1. This power tool is intended to function as a 9. Keep bystanders a safe distance away from work sander. Read all safety warnings, instructions and area. Anyone entering the work area must wear specifications provided with this power tool. Failure personal protective equipment.

  • Page 7: Kickback And Related Warnings

    Kickback and Related Warnings Additional Rules For Safe Operation Kickback is a sudden reaction to a pinched or 1. Empty the dust bag or dust collection receiver snagged rotating wheel, backing pad, brush or any frequently. Do not leave residue in dust bag or dust other accessory.

  • Page 8: Machine Components

    Machine Components Component 1. Control Switch 2. Dust Collection Bag 3. Operating Handles 4. Abrasive Wrench 5. Sanding Pad 6. Wall Guard 7. Caster Adjustment Screw...

  • Page 9: Machine Specifications

    Machine Specifications Model Super 7R Model Number 07098A Voltage / Frequency 230V / 50Hz Amperage (A) 1 hp Motor 750 Watts Abrasive Size 7” X 7/8” Disc Disc Rate 2800 Disc Driver System Gear Driven Power Cable H05V/F3G 1.0mm sq X 15.4m Dust Collection Standard Dust Control Rate...

  • Page 10: Dust Collection

    Dust Collection This sanding machine is designed to be operated with a remote vacuum dust collection system or with the included dust bag Preparing Remote Vacuum Dust Collection Systems Preparing Using the Dust Bag To prepare the machine for remote vacuum dust To prepare the machine for use with the included dust collection systems that have a 2”...

  • Page 11: Machine Setup

    Machine Set-Up Operating Instructions Preparing the Machine for Operation 1. Move machine to the location of your work. Set any exposed nails with hammer and punch to avoid 1. Familiarize yourself with the machine. Read all encounter with abrasive. danger, warning, and caution statements and the Owner’s Manual before operating this machine.

  • Page 12: Adjustment Procedures

    Adjustment Procedures Sanding Cuts & Sandpaper Leveling Initial Cut: The purpose of the initial cut is to remove old finish and To level machine: Grasp caster adjusting screw “A” gross imperfections on the floor surface. Use a course with an appropriate tool (pliers etc.). Using a similar (20-36 grit) grain abrasive.

  • Page 13: Maintenance

    Maintenance Gearbox Lubricant CAUTION: Maintenance and repairs performed To change the lubricant in the gearbox, follow this by unauthorized personnel could result in damage procedure: or injury. Maintenance and repairs performed by 1. Put the machine upside down on a bench. unauthorized personnel will void your warranty.

  • Page 14: Parts Manual & Notes

    Super 7R Australia Edger Parts Manual Notes: ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________ ________________________________________________...

  • Page 15: Electrical Schematic

    Electrical Schematic...

  • Page 16: Lower Assembly

    Lower Assembly RF062000 070116...
  • Page 17 Lower Assembly (continued) Item Ref. No. Description Item Ref. No. Description 318303 SPRING, LOAD 316804 PLUG, PIPE 307702 SHAFT, DRIVE, GEAR 56380216 DECAL, CAUTION 915028 KEY, WOODRUFF, 1/8” X 5/8” 56380639 DECAL, PROP 65 87609A WASHER, SEAL 53544B BAG, DUST 317204 DISC, GUARD, RETAINER 303502...

  • Page 18: Upper Assembly

    Upper Assembly RF062100 121916...
  • Page 19 Upper Assembly (continued) Item Ref. No. Description Item Ref. No. Description 902567 BEARING BALL DOUBLE 962404 SCREW, 10-24 X 3-1/4, FH, ST, SEALED AS013500 FIELD & COIL, SUPER 7R, ASM., 10110A ARMATURE ASM SUPER 7R 240V 240V 50 293514 PINION, ARMETURE 298306 SPRING, LOAD, 56 308202...

  • Page 21: Limited Warranty

    Limited Warranty Super 7R Australia TO QUALIFY FOR THIS WARRANTY INSTRUCTIONS AND CONDITIONS FOR WARRANTY REIMBURSEMENT (1) Machine must be registered within 30 days from the time of purchase on a form provided by American Sanders. Your Order replacement part: Orders will be processed and charged, American Sanders Distributor is responsible for the registration as normal procedure.
  • Page 24 LT074500 © 2017 American Sanders Super7R Aust_B...
