Product Specifications for PCR
Suitable for T960
Please read the manual before installation and operation
Drawell International Technology Limited
Chongqing Drawell Instrument CO,.Ltd
Add:Suite 2705,Building No.12,Shiyou Road No.1,Yuzhong District,
Chongqing,China
Tel: 0086-023-63268643
Shanghai Drawell Scientific Instrument Co.,Ltd
Add : Suite 1117,Lane561 XiuChuan Rd.,PuDong New Area,Shanghai,China
Web : www.drawell.com.cn
Email : sales05@drawell.com.cn
www.drawell.com.cn
Advertisement
Table of Contents
Related Manuals for Drawell DW-T960
Summary of Contents for Drawell DW-T960
- Page 1 Please read the manual before installation and operation Drawell International Technology Limited Chongqing Drawell Instrument CO,.Ltd Add:Suite 2705,Building No.12,Shiyou Road No.1,Yuzhong District, Chongqing,China Tel: 0086-023-63268643 Shanghai Drawell Scientific Instrument Co.,Ltd Add : Suite 1117,Lane561 XiuChuan Rd.,PuDong New Area,Shanghai,China Web : www.drawell.com.cn Email : sales05@drawell.com.cn www.drawell.com.cn...
-
Page 2: Table Of Contents
Working condition and performance indicator Chapter 3 Instructions Program installation Startup interface Files Setting Heat Lid Gradient Apply System Help Chapter 4 Programming Create files Open files Appendix A Maintenance and troubleshooting Maintenance Troubleshooting Appendix B Instrument Guarantee Guarantee Content Guarantee Scope www.drawell.com.cn... -
Page 3: Unpacking Check
2 Safety notice Please read the manual carefully before operating the instrument, the wrong operation may be hazardous to the operator or the instruments itself. www.drawell.com.cn... - Page 4 The instrument falls from a high place or the instrument shell is damaged. The operating instrument produces the abnormal noise or the pungent odor. The features of the instrument change apparently, such as failures of startup or shutdown or failure to run user program, etc. www.drawell.com.cn...
- Page 5 The above figure indicates that the remaining trial time is 91 hours. ④ How to get the encryption key after the trial period expires When the trial period is about to end, please contact the merchant or manufacturer to get the encryption key, to facilitate you to continue to use. www.drawell.com.cn...
-
Page 6: Chapter 2 Basic Functions
(7)LCD Screen (8)Aluminum panel (9) Power switch (10) Power socket (11) Fuse socket (12) Network interface (13) USB interface (14) JTEG interface (15) Shell (16) Ventilation window (17) Long label (18) Lid wrench (19) Block selecting knob (20) Block selecting indicator www.drawell.com.cn... -
Page 7: Lid-Opening Angle
Frequently, experiments need different reaction tubes, that is, use different blocks to match the tubes. The design of the heat lid gear positions realize the heat lid to match different sample plate blocks just by turning the knob to the appropriate position. www.drawell.com.cn... -
Page 8: Module
(The block parts of different specifications differ with blocks corresponding to tubes of different specifications). And this guarantees that users can change or install the block in a fast and high-efficient way only by choosing www.drawell.com.cn... - Page 9 Step 1: Move the handle to the state vertical to the shell to make the block parts unlocked. (Figure 3) Step 2: Move the block parts upward slightly, and lay it in a safe place after the block parts are completely off the shell. (Figure 4) www.drawell.com.cn...
- Page 10 Notice: Since all the lines of the instrument are connected by connectors, the user shall use proportional strength while taking out or installing block parts, and use skilled strength to shake them left and right. No tough strength is allowed in case of any damage to connectors. www.drawell.com.cn...
-
Page 11: Touch Screen
Notice: In order to guarantee the normal use of the instrument and the accuracy of experimental results, please run or store the instrument according to prescribed working conditions and storage conditions. Or the wrong operation will damage the instrument and even personal safety. www.drawell.com.cn... - Page 12 Heat lid temp: 20℃~110℃ Temp control: block,tube ,calculated Stored program number: 2000(The External U disk unlimited) Maximum number of cycles: 999 Display: 7 inch LCD Communication: USB2.0、 RS232、 RJ45 Size: 380mm(L)*270mm(W)*250mm(H) Weight: 8.1kg www.drawell.com.cn...
-
Page 13: Chapter 3 Instructions
If the screen is dark or any other abnormal phenomena occur while turn on the instrument, please cut off the power immediately and refer to Chapter 5 for maintenance or contact the distributor or the supplier for settlement. www.drawell.com.cn... -
Page 14: Files
Notice: "Create file” -- Create new files. "Delete file” -- Delete files. Specific program file setting showed in chapter 4. 3.4 Setting In the" Main Menu" select "Set" submenu to get into the "Operation Parameters Settings" interface. (Figure 3-4) www.drawell.com.cn... -
Page 15: Heat Lid
In the "Main Menu" select "Lid" submenu to get into the "Heat Lid Function Settings" interface. (Figure 3-5) Notice:The Heat lid temperature scope is: 20℃～110℃. 3.6 Gradient In the" Main Menu" select “Grads" submenu to get into the "Gradient View" interface. (Figure 3-6) www.drawell.com.cn... -
Page 16: Apply
3. The colour of the gradient figured above, don’t refer to the temperature and the colour of the block, it is the position of every line. 3.7 Apply In the" Main Menu" select "apply" submenu to get into the "Appointment and Alarm Settings" interface. (Figure 3-7) www.drawell.com.cn... -
Page 17: Log
Press the “Apply” key to modify the system date, alert sound, file list arrangement type, etc. Insert the U disk into your machine,then press the "Export" button,the user's program files will be copied to the "jgFolder" folder in the U disk. www.drawell.com.cn... -
Page 18: Help
2. When the trial period is about to end，click the "unlock" key to get a verification code，then contact the merchant or manufacturer to obtain the corresponding encryption key. www.drawell.com.cn... -
Page 19: Chapter4 Programming
Step 1：Open the "File" menu ,then input the file name，to search the file that you want to use (Figure 4-2). Also，you can click the "Create File" key，then input the file name and password（If you need） ，click the "Confirm" key to confirm after closing the small keyboard(Figure 4-3). www.drawell.com.cn... - Page 20 " and select the "Cycle End Point". (Figure 4-5) Notice: if you want to delete the finished cycle, you can choose the temperature point in the cycle, then click “cycle edit” pull down frame ”cycle edit”, change the number to 0 and then click ok. www.drawell.com.cn...
- Page 21 Figure 4-6） ， to open the "Temp Edit " and "Cycle Edit" interface（ Figure 4-7）. Keep pressing here for 2 sec,appear a popup window similar to Figure 4-7 Step 4: Click the "Run" key to start running files. (Figure4-8) You can choose the “Run”,”Pause”,”Stop” keys to operate the www.drawell.com.cn...
-
Page 22: Open Files
Click the "File" on the "main menu" interface to get into the "File" interface (Figure 4-10), click the file that you need to get into the "file edit" interface(Figure4-11),then click the "Run" to start running.click run then the program that you choose is running immediately(Figure4-9). 4-10 www.drawell.com.cn... - Page 23 4-11 Notice: if you want to enter other interfaces from the running interface, you must click the “stop” at first, and then click the www.drawell.com.cn...
-
Page 24: Appendix A Maintenance And Troubleshooting
E. The preparation process is not specially treated. F. The time and temperature value in the programming is not suitable. G. The temperature of the sample or sample electrode is a little low, whereas the base temperature is a little high. www.drawell.com.cn... - Page 25 Contact the supplier Heating film is damaged heating the heat or manufacturer Temperature sensor is damaged The link line is loose The screen Contact the supplier Bad contact of the chip displays or manufacturer The chip is damaged abnormal character www.drawell.com.cn...
-
Page 26: Appendix B Instrument Guarantee
If the user fails to operate according to the standard specified or uses it under the inappropriate conditions, or arbitrarily dismantles or repairs the instrument without authorization, then any damage or default thus occurred shall not be contained in the maintenance scope. www.drawell.com.cn... - Page 27 Drawell International Technology Limited Chongqing Drawell Instrument CO,.Ltd Add:Suite 2705,Building No.12,Shiyou Road No.1,Yuzhong District, Chongqing,China Tel: 0086-023-63268643 Shanghai Drawell Scientific Instrument Co.,Ltd Add : Suite 1117,Lane561 XiuChuan Rd.,PuDong New Area,Shanghai,China Web : www.drawell.com.cn Email : sales05@drawell.com.cn www.drawell.com.cn...
