Reflex Control Basic Operating Manual page 25

Device controllers with Reflex Control Remote and I/O module and/or bus module.
1 Control Touch controller with Control Remote
2 I/O module
Jumper / Switch
Setting
Control Remote
Control Touch
Control Basic
I/O module
Bus module
• Lon Works
• Profibus DP
• Ethernet
Terminator settings
Jumpers J10 and J11
Activated Deactivate
d
‐‐
‐‐ ‐‐
‐‐ ‐‐
‐‐ X
‐‐ ‐‐
Control Remote — 09.11.2015
3 Bus module
4 Control Basic controller with Control
Remote
DIP switches 1 and 2
Activated Deactivated
‐‐ X
X ‐‐
X ‐‐
‐‐ ‐‐
‐‐ ‐‐
Settings
Jumper J3
1 and 2 and 3 and 4
Activated Deactivate
d
‐‐ ‐‐
‐‐ ‐‐
X ‐‐
‐‐ ‐‐
X ‐‐
German — 9
