Tools Needed; Parts - Robern CURATED CARTESIAN VANITY H4-2 DRAWER Manual

TOOLS NEEDED

PARTS

Stone Top
(1) 24", 30", or 36" Cartesian frame
30" shown here
24", 30", or 36" Plumbing Drawer
[225-1039] = 24" [225-1040] = 30" [225-1041] = 36"
Divider Set Plumbing Drawer
[211-1073]
Divider Glass
(4) Divider Clip
© 2016 Robern, Inc. 701 N. Wilson Ave. Bristol, PA 19007 U.S.A.
800.877.2376 www.robern.com
Installation instructions
Cloth
[210-1100]
(2, 4, or 6) Bracket
(2) Drawer front
[202-1179]
(1) Glass Center Bin
[211-1098]
(4) Divider Clip Shoe
[228-1015]
Sink Box
Sink
[VM2SKH4D21##]
Side kit
Side kit
24", 30", or 36" Full Drawer
[225-1042]
Divider Set Full Drawer
[211-1073]
(4) Divider Clip
Divider Glass
2
[1193643]
(4) Bracket
(not needed
for this model)
[216-1073]
Mounting Hardware Bag
[203-1256]
(8) 5/16" x 2-1/2"
Structural Bolt
[SS674]
(10) #10 x 2" Screw
Drawer front Hardware Bag
(8) #8-32 x 1/2" Screw
[211-1098]
(4) Divider Clip Shoe
Curated Cartesian H4 - 2 Drawer
[216-1120]
Sink Hardware Bag
[203-1337]
(4) Acorn Nut
[203-1335]
(4) #10-24 x 1.5" Screw
[203-1270]
T-30 Driver
[216-1074]
[203-1219]
[203-1198]
(8) Washer
[211-1095]
(4) Screw cover
Part no. 209-1275 rev. 04/19/23
