THE UROSHIELD
The actuator is attached onto the urinary
catheter after the catheter's insertion into
the patient's urethra. When the UroShield
driver is active, the actuator generates
ultrasound waves on the surface of the
catheter. The actuator is intended for single
use only, should be worn continually and
changed every 30 days.
First time users of the UroShield
system should ensure that it is used on a
new catheter.
THE UROSHIELD® DRIVER
The driver supplies electrical signals to the
actuator. It has the following parts:
Built-in rechargeable battery
Charging port
Actuator port
O N/OFF button
Operational display screen
The driver is small and lightweight and can
be attached using a lanyard (fig.1), or placed
on the patient's bed. When the patient needs
to be mobile, the UroShield
placed in a pocket, attached to a belt or a
leg strap if used to manage the catheter, or
attached to a walker or wheelchair using
a lanyard.
fig.1
ACTUATOR
®
5
2
1
3
®
®
driver can be
11
4.1
®
4
4.2
4
