Refco REF-LOCATOR Instruction Manual

Electronic leak detector

Hide thumbs Also See for REF-LOCATOR:

Instruction manual (60 pages)

page of 60

/ 60
Bookmarks

Quick Links

Download this manual

All manuals and user guides at all-guides.com

TRACE-LOCATOR

Instruction Manual

Electronic Leak Detector

Bedienungsanleitung

Elektronisches Lecksuchgerät

Mode d'emploi

Détecteur de fuites électronique

Istruzioni per l'uso

Rilevatore di perdite elettronico

Manual de instrucciones

Detector de fugas electrónico

REF-LOCATOR

4686714

4686715

Need help?

Do you have a question about the REF-LOCATOR and is the answer not in the manual?

Questions and answers

Summary of Contents for Refco REF-LOCATOR

Page 1 REF-LOCATOR All manuals and user guides at all-guides.com 4686714 TRACE-LOCATOR 4686715 Instruction Manual Electronic Leak Detector Bedienungsanleitung Elektronisches Lecksuchgerät Mode d’emploi Détecteur de fuites électronique Istruzioni per l’uso Rilevatore di perdite elettronico Manual de instrucciones Detector de fugas electrónico...
Page 2 All manuals and user guides at all-guides.com...
Page 3 All manuals and user guides at all-guides.com Instruction Manual REF-LOCATOR / TRACE-LOCATOR English...
Page 4 All manuals and user guides at all-guides.com English Instruction Manual REF-LOCATOR / TRACE-LOCATOR detector will sound a slow “beep”. The warm . The audio “beep” increases in frequency.
Page 5 All manuals and user guides at all-guides.com Instruction Manual REF-LOCATOR / TRACE-LOCATOR English Three Bars: Full Voltage Two Bars: 1/2 Life One Bar: 1/4 Life No Bars: Low Voltage (Change Batteries) No Bars/ Blinking: Unit will be disabled and not function properly in this state...
Page 6 All manuals and user guides at all-guides.com English Instruction Manual REF-LOCATOR / TRACE-LOCATOR : LED’s should last for years under normal use. If necessary, the LED’s can be...
Page 7 All manuals and user guides at all-guides.com Instruction Manual REF-LOCATOR / TRACE-LOCATOR English “...
Page 8 All manuals and user guides at all-guides.com English Instruction Manual REF-LOCATOR / TRACE-LOCATOR Replace ﬁlter whenever (ﬁgure...
Page 9 All manuals and user guides at all-guides.com Instruction Manual REF-LOCATOR / TRACE-LOCATOR English Figure 1 Figure 2 Figure 3 Figure 4 Figure 5 Guide slot Raised spline Sensor Socket Sensor...
Page 10 All manuals and user guides at all-guides.com English Instruction Manual REF-LOCATOR / TRACE-LOCATOR HFC’s R410A, R404A, R407C, & R134a 3 white LED’s and 3 UV LED's. Auto shutoff after Instantaneous (static test) 0.100 sec moving at 3”/sec BTN LCD (black) with 10 segment color “pie ”...
Page 11 All manuals and user guides at all-guides.com Instruction Manual REF-LOCATOR / TRACE-LOCATOR English 3 white LED’s and 3 UV LED's. Auto shutoff after 5 minutes BTN LCD (black) with 10 segment color “pie ” IP54. Housing incorporates “O ring” seal, openings...
Page 12 All manuals and user guides at all-guides.com English Instruction Manual REF-LOCATOR / TRACE-LOCATOR...
Page 13 All manuals and user guides at all-guides.com Instruction Manual REF-LOCATOR / TRACE-LOCATOR English...
Page 14 All manuals and user guides at all-guides.com Deutsch Bedienungsanleitung REF-LOCATOR / TRACE-LOCATOR...
Page 15 All manuals and user guides at all-guides.com Bedienungsanleitung REF-LOCATOR / TRACE-LOCATOR Deutsch...
Page 16 All manuals and user guides at all-guides.com Deutsch Bedienungsanleitung REF-LOCATOR / TRACE-LOCATOR...
Page 17 All manuals and user guides at all-guides.com Bedienungsanleitung REF-LOCATOR / TRACE-LOCATOR Deutsch...
Page 18 All manuals and user guides at all-guides.com Deutsch Bedienungsanleitung REF-LOCATOR / TRACE-LOCATOR – Test Leck Maximal 1.6 mm...
Page 19 All manuals and user guides at all-guides.com Bedienungsanleitung REF-LOCATOR / TRACE-LOCATOR Deutsch...
Page 20 All manuals and user guides at all-guides.com Deutsch Bedienungsanleitung REF-LOCATOR / TRACE-LOCATOR Führungsschlitz Erhöhter Längsnut Sensor-Anschlussbuchse Sensor...
Page 21 All manuals and user guides at all-guides.com Bedienungsanleitung REF-LOCATOR / TRACE-LOCATOR Deutsch inklusive HFC’s R410A, R404A, R407C, & 3 weisse LED’s und 3 UV LED's. Automatische Zertifizierung für ASHRAE , Richtlinien 2014/30/EU, 2011/65/EU...
Page 22 All manuals and user guides at all-guides.com Deutsch Bedienungsanleitung REF-LOCATOR / TRACE-LOCATOR 3 weisse LED’s und 3 UV LED's. Automatische Zertifizierung SAE-J2970 Richtlinien 2014/30/EU, 2011/65/EU...
Page 23 All manuals and user guides at all-guides.com Bedienungsanleitung REF-LOCATOR / TRACE-LOCATOR Deutsch...
Page 24 All manuals and user guides at all-guides.com Deutsch Bedienungsanleitung REF-LOCATOR / TRACE-LOCATOR...
Page 25 All manuals and user guides at all-guides.com Français Mode d'emploi REF-LOCATOR / TRACE-LOCATOR Mode d’emploi...
Page 26 All manuals and user guides at all-guides.com Français Mode d'emploi REF-LOCATOR / TRACE-LOCATOR Lors de l’utilisation en mode sensibilité MAX, le symbole Phase de chauffage ne disparaît qu’après 60 secondes d’utilisation.
Page 27 All manuals and user guides at all-guides.com Français Mode d'emploi REF-LOCATOR / TRACE-LOCATOR...
Page 28 All manuals and user guides at all-guides.com Français Mode d'emploi REF-LOCATOR / TRACE-LOCATOR...
Page 29 All manuals and user guides at all-guides.com Français Mode d'emploi REF-LOCATOR / TRACE-LOCATOR Testeur de fuite 1,6 mm maximum...
Page 30 All manuals and user guides at all-guides.com Français Mode d'emploi REF-LOCATOR / TRACE-LOCATOR nouveau capteur en dévissant l’ancien capteur situé sur la tige et vissez . Veillez à aligner l’encoche qui se trouve dans le...
Page 31 All manuals and user guides at all-guides.com Français Mode d'emploi REF-LOCATOR / TRACE-LOCATOR Cannelure surélevée Fente de guidage Douille de raccordemment du capteur Capteur La fente de guidage doit être alignée cannelure surélevée.
Page 32 All manuals and user guides at all-guides.com Français Mode d'emploi REF-LOCATOR / TRACE-LOCATOR 3 lampes d'inspection LED et 3 UV Arrêt automatique après 5 3, Directives 2014/30/UE, 2011/65/UE...
Page 33 All manuals and user guides at all-guides.com Français Mode d'emploi REF-LOCATOR / TRACE-LOCATOR 3 lampes d'inspection LED et 3 UV. Arrêt automatique après 5 Directives 2014/30/UE, 2011/65/UE.
Page 34 All manuals and user guides at all-guides.com Français Mode d'emploi REF-LOCATOR / TRACE-LOCATOR...
Page 35 All manuals and user guides at all-guides.com Français Mode d'emploi REF-LOCATOR / TRACE-LOCATOR Adhésif d’étanchéité Ford (mouillé) Tout a été mis en œuvre afin de proposer des produits fiables et de qualité maximale. Cependant, si l’appareil doit être réparé et que la garantie est encore valable, veuillez...
Page 36 All manuals and user guides at all-guides.com Italiano Istruzioni per l'uso REF-LOCATOR / TRACE-LOCATOR Instruzioni per l’uso...
Page 37 All manuals and user guides at all-guides.com Istruzioni per l'uso REF-LOCATOR / TRACE-LOCATOR Italiano l’immagine in figura 2...
Page 38 All manuals and user guides at all-guides.com Italiano Istruzioni per l'uso REF-LOCATOR / TRACE-LOCATOR Una volta individuata l’origine della perdita, il numero massimo di segmenti...
Page 39 All manuals and user guides at all-guides.com Istruzioni per l'uso REF-LOCATOR / TRACE-LOCATOR Italiano...
Page 40 All manuals and user guides at all-guides.com Italiano Istruzioni per l'uso REF-LOCATOR / TRACE-LOCATOR Rilevazione di prova Massimo 1,6 mm...
Page 41 All manuals and user guides at all-guides.com Istruzioni per l'uso REF-LOCATOR / TRACE-LOCATOR Italiano di allineare la scanalatura guida con l’indentatura sull’attacco del sensore (Fig. 5).
Page 42 All manuals and user guides at all-guides.com Italiano Istruzioni per l'uso REF-LOCATOR / TRACE-LOCATOR Scanalatura guida L’indentatura Attacco del sensore Sensore La scanalatura guida deve essere allineata con) l’indentatura...
Page 43 All manuals and user guides at all-guides.com Istruzioni per l'uso REF-LOCATOR / TRACE-LOCATOR Italiano 3 luci di ispezione a LED e 3 UV Spegnimento automatico dopo Direttive 2014/30/UE, 2011/65/UE...
Page 44 All manuals and user guides at all-guides.com Italiano Istruzioni per l'uso REF-LOCATOR / TRACE-LOCATOR 3 luci di ispezione a LED e 3 UV. Spegnimento automatico dopo Certificazione SAE-J2970 Direttive 2014/30/UE, 2011/65/UE...
Page 45 All manuals and user guides at all-guides.com Istruzioni per l'uso REF-LOCATOR / TRACE-LOCATOR Italiano...
Page 46 All manuals and user guides at all-guides.com Italiano Istruzioni per l'uso REF-LOCATOR / TRACE-LOCATOR l’R134a dell’affidabilità. Tuttavia, nel caso in cui il prodotto necessiti di riparazioni, le unità ancora in garanzia possono essere restituite al rivenditore da cui l’apparecchio è s...
Page 47 All manuals and user guides at all-guides.com Manual de instrucciones REF-LOCATOR / TRACE-LOCATOR Español...
Page 48 All manuals and user guides at all-guides.com Español Manual de instrucciones REF-LOCATOR / TRACE-LOCATOR...
Page 49 All manuals and user guides at all-guides.com Manual de instrucciones REF-LOCATOR / TRACE-LOCATOR Español...
Page 50 All manuals and user guides at all-guides.com Español Manual de instrucciones REF-LOCATOR / TRACE-LOCATOR...
Page 51 All manuals and user guides at all-guides.com Manual de instrucciones REF-LOCATOR / TRACE-LOCATOR Español Test de fugas Máx. 1.6 mm...
Page 52 All manuals and user guides at all-guides.com Español Manual de instrucciones REF-LOCATOR / TRACE-LOCATOR...
Page 53 All manuals and user guides at all-guides.com Manual de instrucciones REF-LOCATOR / TRACE-LOCATOR Español ranura guía Línea superior enchufe del sensor sensor La ranura guía debe quedar alineada con la línea superior...
Page 54 All manuals and user guides at all-guides.com Español Manual de instrucciones REF-LOCATOR / TRACE-LOCATOR 3 luces de inspección LED y 3 UV con apagado automático a los ASHRAE , Directivas 2014/30/UE, 2011/65/UE...
Page 55 All manuals and user guides at all-guides.com Manual de instrucciones REF-LOCATOR / TRACE-LOCATOR Español 3 luces de inspección LED y 3 UV con apagado automático a los Certificado SAE-J2970 Directivas 2014/30/UE, 2011/65/UE...
Page 56 All manuals and user guides at all-guides.com Español Manual de instrucciones REF-LOCATOR / TRACE-LOCATOR...
Page 57 All manuals and user guides at all-guides.com Manual de instrucciones REF-LOCATOR / TRACE-LOCATOR Español...
Page 58 All manuals and user guides at all-guides.com...
Page 59 All manuals and user guides at all-guides.com...
Page 60 All manuals and user guides at all-guides.com REFCO Manufacturing Ltd. Industriestrasse 11 6285 Hitzkirch - Switzerland Telefon +41 41 919 72 82 Telefax +41 41 919 72 83 info@refco.ch www.refco.ch...
