TRITECTOR
Instruction Manual
Electronic leak detector

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRITECTOR and is the answer not in the manual?

Questions and answers

Related Manuals for Refco TRITECTOR

Summary of Contents for Refco TRITECTOR

  • Page 1 TRITECTOR Instruction Manual Electronic leak detector...

  • Page 2: Table Of Contents

    INTRODUCTION GENERAL INFORMATION SPECIFICATION PRODUCT AND PART DESCRIPTION PRODUCT BUTTONS AND NAVIGATION TRANSPORT, PACKAGING AND STORAGE TRANSPORT PACKAGING STORAGE COMMISSIONING AND FUNCTIONS COMMISSIONING FUNCTIONS SENSOR EXCHANGE TEST LEAK MAINTENANCE TROUBLESHOOT GUARANTEE 10.0 RETURN DISPOSAL 11.0 SPARE PARTS AND ACCESSORIES...

  • Page 3: Introduction

    INTRODUCTION Congratulations on your purchase of this device. The REFCO TRITECTOR is equipped with interchangeable sensors for three different applications: refrigerant (CFC, HCFC, HFC, HFO), combustible gases and tracer gases. The latest manual can be downloaded from www.refco.ch. GENERAL INFORMATION Before you start working with the TRITECTOR, please read the operating instructions carefully.
  • Page 4 REFCO disclaims all responsibility and liability for accidents, injuries or death. REFCO expressly states that the products should only be used by professionally-trained specialists. The leak detector must not be used in EX zones.

  • Page 5: Specification

    Intended use The leak detector has been developed for finding leaks conditions in mobile and stationary refrigeration systems and in heat pumps. Only trained refrigeration technicians are permitted to use this REFCO product. SPECIFICATION Property Value Sensor Metal-Oxide Semiconductor (heated diode)
  • Page 6 Power supply 4 x 1.5 V AA batteries Operating time of approx. 12 hours when used continuously. Alternative Micro USB Power supply Tube length 40 cm / 16” Auto reset Every 30 sec. Automatic power save 10 min. without pressing any button mode Humidity 0 to 90 % relative humidity (no condensation)

  • Page 7: Product And Part Description

    PRODUCT AND PART DESCRIPTION PRODUCT Snake tube LCD display Buttons Sensor head Refrigerant: Green Tracer gas: Yellow Combustible gas: Battery compartment BVM04720210204 Instruction Manual...

  • Page 8: Buttons And Navigation

    BUTTONS AND NAVIGATION On/Off Mute Sensitivity Peak Reset Low Medium High Refrigerant sensor is plugged in Combustible gas sensor is plugged in Tracer gas sensor is plugged in If no sensor is plugged in, all icons will flash and an alarm will sound.

  • Page 9: Transport, Packaging And Storage

    COMMISSIONING Insert four batteries into the battery compartment on the bottom. Observe the correct polarity of the batteries. If you will not be using the TRITECTOR for a long period of time, remove the batteries from the battery compartment. BVM04720210204...

  • Page 10: Functions

    Ambient concentration reset When entering a contaminated area, it is important to have a function which allows you to reset the leak detector. Upon initial power on, the TRITECTOR automatically resets itself to ambient concentration, to ignore the level of refrigerant present at the tip.

  • Page 11: Sensor Exchange

    To disable the function press and hold the peak button again. Battery Management To increase the battery life time, the TRITECTOR has two functions: Auto shut off: After 10 minutes without pressing any button, the device will turn off.

  • Page 12: Test Leak

    TEST LEAK The TRITECTOR comes with a leak test vial that allows the user to ensure that the detector is performing properly. The Tracer gas sensor does not respond to the test leak vial, but it can be tested with tracer gas (N 95% and H 5%).

  • Page 13: Maintenance

    MAINTENANCE The leak detector requires maintenance when used regularly: Replace Filter: Unscrew the sensor tip, as shown below. Replace the filter whenever it becomes visibly dirty or every 3 to 4 months, depending on use. Cleaning: Clean the screen and the housing surface with a cloth and cleaning agent. Do not use corrosive cleaning agents or solvents to clean the unit.

  • Page 14: Guarantee

    Manufacturing Ltd has been certified according to DIN EN ISO 9001:2015. Regular quality control checks as well as an accurate manufacturing process guarantee reliable functionality and are the basis for the REFCO guarantee, in accordance with the General Terms and Conditions of Sale and Delivery applicable on the day of delivery.

  • Page 15: Return Disposal

    The leak detector has been developed for long-term use. Attention was paid to energy saving and environmental compatibility at the material procurement and production stages. REFCO embraces its responsibility towards the environment, and has therefore been certified in accordance with DIN EN ISO 14001:2015. When decommissioning the device, the user must follow local disposal regulations.
