- Page 1 EΛ INSTRUCTION MANUAL EN Cooking Hob...
- Page 2 Visit our website www.brandt.com where you will find our latest innovations, as well as useful and complementary information. BRANDT is delighted to assist you every day and hopes you get the most out of your purchase. Important : Before using your appliance, read this user guide carefully to familiarise yourself more quickly with its operation.
-
Page 3: Table Of Contents
Table of contents Table of contents SAFETY ADVICE ..................4 ENVIRONMENT AND ENERGY SAVING ............6 IDENTIFICATION ..................7 INSTALLATION ..................9 Unpacking ...................9 Enclosure ..................9 Electrical connection ..............11 USING ....................12 Choice of cookware ..............12 Burner selection ................. 12 Switching on / Stopping ............13 + / - Setting the power ............. -
Page 4: Safety Advice
SAFETY ADVICE SAFETY ADVICE IMPORTANT SAFETY INSTRUCTIONS TO BE READ CAREFULLY AND KEPT FOR FUTURE USE. This guide can be downloaded from the brand web site. This appliance can be used by Your appliance complies with children over 8 years old and applicable European Directives persons with reduced physical, and regulations. - Page 5 SAFETY ADVICE SAFETY ADVICE clean your cooking hob. Do not place any hot lids flat on The appliance is not designed to your cooking hob. A suction effect be switched on using an external may damage the vitroceramic timer or a separate remote surface.
-
Page 6: Environment And Energy Saving
ENVIRONMENT AND ENERGY SAVING ENVIRONMENT AND ENERGY SAVING Protecting the environment This symbol indicates that this product should not be treated as household waste. Your appliance also contains a great amount of recyclable material. It is marked with this symbol to indicate that used appliances must be disposed of in certified collection points. -
Page 7: Identification
APPL. REF REF ID CERAN HIGHTRANS ECO GL4P00304 Validated for execution BPI621UB 0092450_00 BRANDT 2021 ALWAYS BLACK ép:4+/-0.2 This component should be in accordance with these standards : Temp use (°C) : Specifications (F.S.N) Temp max (°C) : Default tolerances (Norm-Class) - Page 8 BASIC REF BAS. DRAWING APPL. REF REF ID BPI1638UB Validated for execution CERAN HIGHTRANS ECO GL4P00306 BRANDT 21 21/16/XL ALWAYS BLACK ép:4+/-0.2 This component should be in accordance with these standards : Temp use (°C) : Specifications (F.S.N) Temp max (°C) :...
-
Page 9: Installation
INSTALLATION INSTALLATION UNPACKING For future use, remove all protective elements. Check and respect the appliance’s characteristics that appear on the nameplate. Note in the boxes below the service and standard references shown on this plate. Service : ................. Type : ................ENCLOSURE Check that the air intake and outlet are free of obstruction... - Page 10 INSTALLATION INSTALLATION If you are installing the hob above a drawer, or above a built-in oven, comply with the dimen- sions provided on the illustrations to ensure a sufficient air outlet at the front. Carefully glue the sealing joint to the entire surround of the glass hob insert the table into the cabinet...
-
Page 11: Electrical Connection
INSTALLATION INSTALLATION Important If your hob is located above your oven, the hob’s thermal safety devices can impede the simultaneous use of the hob and the oven’s pyrolysis programme, display code “F7” in the control zones. In such circumstances we recommend that you increase the hob’s ventilation by creating an opening in the side of the cabinet (8 x 5 cm). -
Page 12: Using
USING CHOICE OF COOKWARE Tips Most cookware is compatible with induction. Only When using the two hobs simultaneously, the glass, earthenware, aluminium without a special hob manages the power distribution so as not to bottom, copper and some non-magnetic stainless exceed the total power of the hob. -
Page 13: Switching On / Stopping
UTILIS USING SWITCHING ON - STOPPING Switching on: Press the key corresponding to the required burner. A 0 and a beep indicate that the cooking UPress to access the maximum power. zone is on. You can adjust the required power of the burner selected. -
Page 14: Child Safety
USING The setting is then made by pressing + or -. 99 CHILD SAFETY minutes can be accessed directly by pressing the key at the start. Your hob has a child safety device which locks the If the +/- keys are not pressed for 20 seconds, the controls when the hob is not in use or when it is cooking time is validated (LED b is no longer lit) being used for cooking. -
Page 15: Safety Precautions And Recommandations
USING SAFETY PRECAUTIONS AND RECOMMENDA- TIONS Residual heat: After intensive use, the cooking zone that you have just used can remain hot for several minutes. The symbol H is displayed during this period . Auto-Stop : Your hob has an auto-stop device, which automa- tically stops any cooking zone which remains swit- ched on for an excessive length of time (between 1 and 10 hours depending on the power used). -
Page 16: Maintenance
MESSAGES PARTICULIERS, INCIDENTS MESSAGES PARTICULIERS, INCIDENTS MAINTENANCE MAINTENANCE For light dirt, use a disinfectant sponge. Tho- roughly moisten the zone to be cleaned with hot water, then wipe off (5). For a build-up of baked-on dirt or sweet over- flows, use a disinfectant sponge and/or a special glass scraper. -
Page 17: Special Messages, Incidents
SPECIAL MESSAGES, INCIDENTS SPECIAL MESSAGES, INCIDENTS to the cookware. DURING INITIAL USE: - An indicator light appears. This is normal. It - The fan continues to function after your hob will go away after 30 seconds. is turned off. This is normal. It cools the electronic parts. - Your installation blows a fuse or one side only of the hob works. -
Page 18: Energy Efficiency
ENERGY EFFICIENCY ENERGY EFFICIENCY... -
Page 19: After-Sales Service
AFTER-SALES SERVICE AFTER-SALES SERVICE Interventions Any work on your appliance must be carried out by a qualified professional who is a brand owner. When you call, in order to make it easier to deal with your request, please have the complete references of your appliance (commercial reference,...
