JEHNERT SOUND DESIGN 68501 Assembly Instruction Manual

Fiat Ducato III + Serie 8,
CampTec Style
Basic Installer Paket, 2-Ways
2-way sound system Fiat Ducato III and Serie 8
»68501 Front «
Packing list:
Package 1 (Art. No. 68601):
2x »XA19 DUC« Neodymium soft dome tweeter Ø 19mm
2x »XA165« Low-midrange »Power-Woofer« Ø 165mm incl.
2x Mounting ring for »XA165« with M4x16 pre-mounted on woofer
1x Center crossover
4x Alubutyl blank 110 x 220 x 3mm
Required tools / accessories
• Phillips screwdriver
• Torx screwdriver (TX 20/25/30)
• Gloves
• Plastic wedge
• Padding material for surface protection
• Tray, or similar for storing small parts
• Insulating tape
Recommendation:
To achieve the full sound performance of the sound system, we recommend the expansion set, which signifi cantly
increases the sound performance of the system with the additional amplifi er and subwoofer.
Fiat Ducato Series 8: for an optimal sound experience, the complete insulation of the door lining is recommended.
(required damping material not included, can be reordered, Art.No.: 27970)
Radio settings:
To achieve the best sound, all settings on the radio (bass, treble, loudness, equalizing, etc.)
should be set to ZERO or OFF.
