JEHNERT SOUND DESIGN 65740 Assembly Instruction Manual

Mercedes Sprinter
W907 / W910
from 2018, Cab System
3-way sound system Mercedes Sprinter (65740)
(for vehicles with/without front blind , only for vehicles without cover aps on the dashboard/storage compartment)
Model/year of manufacture: Sprinter VS30 from 2018 (Type W907 / W910)
Packing list:
1x mid-high module incl. acoustic fabric cover (left & right), covered
2x »XE26« neodymium softdome tweeter Ø 26mm
2x »XE80« midrange driver Ø 80mm
2x »XM165« low-midrange driver „Power-Woofer" Ø 165mm
2x mounting ring for „XM165" with M4x16 premounted on woofer
2x mid-high crossover incl. cable assembly (Art.-No.: 7000 FW)
1x mounting set - Mercedes Sprinter art.-no.: 65740
1x cable crossover for center speaker jacketed
Mounting kit part no. 65740:
Mid-tweeter module dashboard
2x Spax screw 4x25
2x spax screw 4x55
Required tools
Phillips screwdriver
Torx screwdriver (TX 20/25/30)
Cutter knife (sharp!)
insulating tape
Hot air dryer
Plastic wedge
Recommendation:
In order to achieve the full sound performance of the sound system, we recommend Sound Package I, which,
with the additional ampli er and subwoofer, which signi cantly increases the sound performance of the system.
