please select the option "Connect Wi-Fi" in the menu of the app.
During Wi-Fi configuration, the app will ask you to activate Wi-Fi configuration mode on the station by pressing and holding the SET
y
(Fig.2-F) and "+" (Fig.2-D) buttons simultaneously (for 5 seconds).
After a restart, the station automatically tries to connect to the known network (Wi-Fi symbol
y
lished after 15 minutes, the Wi-Fi symbol disappears.
6.7 Battery displays
As soon as the battery symbol
y
corresponding transmitter.
As soon as the battery symbol
y
or they should be changed.
6.8 Checking device ID and additional transmitters
6.8.1 SENSOR button (Fig.2-C)
If you briefly press the SENSOR button once in normal mode, the station displays the device ID of the base station and the measured
y
values (indoor temperature and indoor humidity) that are transmitted from this device to the server/app.
If you briefly press the SENSOR button again, the station displays the device ID of the temperature-humidity transmitter and the measured
y
values (outdoor temperature and outdoor humidity) that are transmitted from this device to the server/app.
If you briefly press the SENSOR button again, you will return to normal mode.
y
y
If you want to remove the currently received temperature-humidity transmitter, select the transmitter and press and hold the "-" button
(Fig.2-E) for 5 seconds.
The device will automatically quit the mode if no button is pressed for 5 seconds.
y
6.8.2 Manual search for the transmitter
Press and hold the SENSOR button (Fig.2-C) in normal mode for 3 seconds to start the transmitter search. The radio symbol
y
flashing in this area.
For a successful transmitter search, it is recommended to place the desired transmitter next to the base station during the search and to
y
insert the batteries in the corresponding transmitter immediately after initiating the manual search, or also to briefly press the TX button
(Fig.4-E) of the corresponding transmitter.
After a transmitter has been successfully received, a short beep is emitted, its measured values and the corresponding radio symbol are
y
permanently displayed.
6.9 Factory-reset & firmware information
6.9.1 Factory-reset
In case of a serious malfunction or if you want to reset all settings and memories of the station to factory settings, press and hold the
y
buttons ALERTS (Fig.2-A) and LIGHT (Fig.2-G) simultaneously for 3 seconds.
6.9.2 Check the firmware version
To check the firmware version, press and hold the SENSOR (Fig.2-C) and TEMP (Fig.2-B) buttons simultaneously for 3 seconds. A version
y
info of the station firmware is displayed and then a version info of the firmware of the Wi-Fi module appears briefly.
7. Positioning
Positioning and mounting of the base station and the transmitter
With the foldable stand (Fig.3-B) at the back, the base station can be placed onto any flat surface.
y
The base station can be mounted at a chosen location with the mounting holes (Fig.3-A) found at the back of the device.
y
Make sure to avoid the vicinity of any source of interference such as computer screens, TV sets or solid metal objects.
y
Do not use the base station in the vicinity of radiators, other sources of heat or in direct sunlight.
y
The outdoor transmitter (Fig.4) can be placed onto any flat surface or wall mounted at a chosen location with the mounting hole (Fig.4-B)
y
found at the back of the device. When placed outdoors, choose a shady and dry place for the transmitter. Direct sunlight may trigger
incorrect measurement and continuous humidity damages the electronic components needlessly.
y
Once the desired location is chosen, check whether the transmission from the transmitter to the base station is possible (transmission
range of up to 100 m in open areas). Within solid walls, especially ones with metal parts, the transmission range can be reduced
considerably.
If necessary, choose another position for the outdoor transmitter and/or base station.
y
Make sure that the base station has sufficient reception of the Wi-Fi signal at the installation location.
y
appears on the display of the outdoor transmitter (Fig.1-B), change the batteries of the
appears in the display of the indoor values (Fig.1-C), either no backup batteries are inserted
25
flashes). If no connection could be estab-
is shown
