- Page 1 HYGIENIC COMBI TANKS series HYG B vertical models 500, 800, 1000, 1500 L HYG BR2 - with two coils HYG BR - with one coil HYG B without coil INSTALLATION and OPERATION MANUAL Version 0.6...
- Page 2 INSTALLATION and OPERATION MANUAL...
-
Page 3: Table Of Contents
INSTALLATION and OPERATION MANUAL TABLE OF CONTENTS INSTRUCTIONS TO INSTALLER ................4 DESCRIPTION ON HYGIENIC COMBI TANK ............5 CONNECTING OF RELIEF VALVE TO WATER TANK ..........6 TECHNICAL PARAMETERS TO HYGIENIC COMBI TANK HYG B......7 4.1. HYG B - without coil....................7 4.2. -
Page 4: Instructions To Installer
HYG-B series - Inlet/Outlet arrangement – 90 • safety during installation - personal angle degrees. protective equipment HYG-B models, the heat source is an electric Use only original SUNSYSTEM heater. parts. HYG-BR models have a built-in heat exchanger (coil type) designed to connect to a solar installation or boiler. - Page 5 INSTALLATION and OPERATION MANUAL 2.1. Removable insulation and outer casing. The quality of the insulation of a water heater is a key factor for its heat conservation capability and energy efficiency. All Hygienic Combi tanks HYG series/ HYG-B series have Removable insulation with...
-
Page 6: Connecting Of Relief Valve To Water Tank
INSTALLATION and OPERATION MANUAL 3. CONNECTING OF RELIEF VALVE TO WATER TANK 3.1. Connecting of Buffer tank. Heating system Safety (relief) pressure valve Heat carrier inlet 3.2. Connecting of Stainless HYG coil. Cold water inlet - water supply Check (return) valve Safety (relief) pressure valve Cold water inlet - HYG coil Stop (Shut-off) valves should never... -
Page 7: Hyg Br - With One Coil
INSTALLATION and OPERATION MANUAL 4.2. HYG BR - with one coil HYG BR HYG BR HYG BR HYG BR 1000 1500 Capacity 1000 1500 Capacity of water tank DHW / Buffer tank L1/L2 22/478 25/775 25/975 40/1460 Height without insulation / with insulation H, Hi, mm 1710/1750 1850/1890... - Page 8 INSTALLATION and OPERATION MANUAL HYG BR 500 - 1500 Di, ø D, ø 90° HYG BR HYG BR HYG BR HYG BR 1000 1500 Boiler heat carrier outlet С1, mm ”/150 ”/170 ”/170 ”/235 Boiler heat carrier outlet С2, mm ”/150 ”/170 ”/170...
-
Page 9: Transport And Packaging
INSTALLATION and OPERATION MANUAL 5. TRANSPORT AND PACKAGING 6. WARRANTY 6.1. Manufacturing defects and materials guarantee We recommend to transport the water tank to the installation site in its packaging placed on NES Ltd. expressly guarantees that the prod- the pallet, and stretch foil. ucts it manufactures shall be free from defects During transport and installation, depending in materials and workmanship which can pre-... - Page 10 INSTALLATION and OPERATION MANUAL values established by NES Ltd. and set forth in in it. product manuals, or use of water with charac- teristic values exceeding: b) After receiving the claim form, NES Ltd. con- - Dissolvable salts – 500 mg/l; siders it and makes decision whether the claim - Calcium carbonate –...
-
Page 11: Recycling
INSTALLATION and OPERATION MANUAL 7. RECYCLING AND WASTE DISPOSAL Warranty Certificate is limited to the above- mentioned obligations and up to the sum in accordance with the purchase receipt of the Submit all packaging material for recycling product to be claimed; excluded is any liabil- according to the local regulations and require- ity for indirect damages such as loss of data at ments. - Page 12 ISO 9001 BUREAU VERITAS Certification tel.: +359 700 17 343 www.burnit.bg...
