Signature

Power Box Installation Guide

We're very excited you received your replacement power box and are eager to get your unit

back up to optimal operation! This power box is designed with customer installation in mind,

and this guide will help you through that process while avoiding any potential pitfalls.

Labeling

The wiring connections of your power box are labeled with stickers to help you classify them.

INSTALLATION

Step 1

Unplug the unit from the power source, or flip the breaker for the dedicated circuit to the

sauna.

Step 2

Your dust covers, the pieces of plywood board screwed down on the roof of the unit, cover

the power box. Elevate yourself with a stepladder or something similar so that you're looking

down into the roof of the sauna and unscrew the dust covers. Remove them, and you'll see

the roof divided into three segments, with your power box in the center.

Step 3

Once exposed, remove the phillips screws anchoring the power box to the ground. Two on

the long front edge, and one on the right edge close to the back wall (as you are facing the

back wall).

Step 4

Disconnect the power cord on the left edge of the power box.

Need help?

Do you have a question about the Signature Power Box and is the answer not in the manual?

Page 1 Signature Power Box Installation Guide ® We’re very excited you received your replacement power box and are eager to get your unit back up to optimal operation! This power box is designed with customer installation in mind, and this guide will help you through that process while avoiding any potential pitfalls. Labeling The wiring connections of your power box are labeled with stickers to help you classify them.
Page 2 Remove the small black box near where the power box sits, the intermediary wire, connecting S6 (a split wire out to both lights) and the power box. Step 8 The Signature power box being replaced is now ready for extraction. Remove it from the central segment and insert your new replacement boxes. Step 9 Congratulations! All connections will now be separated for removal of the power box.
