Step # 1
1. Always work on a protected surface. Two or more people may be
required to perform these tasks.
2. Remove product from box and place it on
location.
Note: Do not allow children to play with plastic wrapping or
small parts as these could be potential choking hazards. Discard
immediately.
PART
DESCRIPTION
A
Tables
Suggested Assembly instructions
Jasper Tables
HQ20006,HQ20067,HQ20074DT,HQ20044DT
desired installation
QTY
1
Advertisement
Table of Contents
Related Manuals for Winston Jasper HQ20006
Summary of Contents for Winston Jasper HQ20006
- Page 1 Suggested assembly instructions Jasper Tables HQ20006,HQ20067,HQ20074DT,HQ20044DT Step # 1 1. Always work on a protected surface. Two or more people may be required to perform these tasks. 2. Remove product from box and place it on desired installation location. Note: Do not allow children to play with plastic wrapping or small parts as these could be potential choking hazards.
- Page 2 Suggested assembly instructions Jasper Tables HQ20006,HQ20067,HQ20074DT,HQ20044DT Hardware is included in the tables PART DESCRIPTION PICTURE 1/4-20 x 3/4 SS Hex Hd 3000067 Bolt 3005352 Lock washer 0.3125 Suggested tool for assembly PART DESCRIPTION PICTURE 3/8” Wrench...
- Page 3 Suggested assembly instructions Jasper Tables HQ20006,HQ20067,HQ20074DT,HQ20044DT Suggested assembly: 1. Put the washer and the screws on the leg. 2. Place the leg with the hardware in the frame to proceed to the assembly, as show in the picture A and B Picture B Picture A...
