Assembly Instructions: Rectangular 84" Dining Table
HQ3084WTK
(WA1RD84)
2
1
Assemble the leg on the rim using a 1.25" bolt and a flat
Assemble remaining legs using the same method.
washer. Finger tighten only.
3
7
6
4
5
1
2
3
8
9
Place the base over the table top fitting the assembly brackets
using 1" bolts and flat washers. Once all brackets are fitted, confirm
legs are attached at correct angle and fully tighten all bolts.
See parts list on reverse.
