Assemble the leg on the rim using a 1.25" bolt and a flat
washer. Finger tighten only.
3
Place the base over the table top fitting the assembly brackets
using 1" bolts and flat washers. Once all brackets are fitted, confirm
legs are attached at correct angle and fully tighten all bolts.
Assembly Instructions: Round 42" Counter Table
HQ3042BWTK
(WA1CE42)
2
Assemble remaining legs using the same method.
4
1
2
6
5
3
7
8
See parts list
on reverse.
