V7 DOCKTB4PT Instruction Manual page 5

OVERVIEW
BACK
1
3. Thunderbolt™ 4 downstream port x 2
•
Thunderbolt 4 up to 40Gbps, compatible with Thunderbolt 3, USB4, DP Alt
mode, USB
•
Cascade Thunderbolt devices up to 6 levels
•
Max 8K or dual 4K/60Hz resolution video
•
Each Thunderbolt 4 port supports 15W downstream charging for connected
device
•
Note: These 2 ports do not support PD charging from Power Supply
4. DC Power Jack (use included V7 DC 20V/7.5A 150W Power Adapter Only)
•
Thunderbolt 4 up to 40Gbps, compatible with Thunderbolt 3, USB4, DP Alt
mode, USB
•
Cascade Thunderbolt devices up to 6 levels
•
Max 8K or dual 4K/60Hz resolution video
•
Each Thunderbolt 4 port supports 15W downstream charging for connected
device
•
Note: These 2 ports do not support PD charging from Power Supply
2
3 4
