OVERVIEW
BACK
1
1. RJ45 x1
•
10M/100M/1000M/2.5G bandwidth
•
Complies with IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3bz. support IEEE 802.3az-
2010(EEE), IEEE 802.1P, IEEE 802.1Q, IEEE 802.3x
•
Supports Wake-On-LAN and Wake-On-WAN
•
LED indicator: 1) No light: power off. 2) Orange: power on. 3) Blue: Host connection OK.
2.
One Display
Two Displays
Three Displays
2
DisplayPort:
· Max 8K/30Hz
· 4K UHD 60/120/144Hz
· 2K WQHD 60/120/144/240Hz
· 1080P 60/120/144/240Hz
HDMI:
· Max 4K UHD 30/60Hz
· 2K WQHD 60/120/144/240Hz
· 1080P 60/120/144/240Hz
HDMI / DisplayPort:
· Max 4K UHD 30/60Hz
· 2K WQHD 60/120/144/240Hz
· 1080P 60/120/144/240Hz
HDMI / DisplayPort:
· Max 4K UHD 30/60Hz
· 2K WQHD 60/120/144/240Hz
· 1080P 60/120/144/240Hz
HDMI / DisplayPort #2:
· Max 4K UHD 30Hz
· 2K WQHD 60/120/144/240Hz
· 1080P 60/120/144/240Hz
3 4
