Page 1 HPE ProLiant DL180 Gen10 Server User Guide Abstract This document is for the person who installs, administers, and troubleshoots servers and storage systems. Hewlett Packard Enterprise assumes you are qualified in the servicing of computer equipment and trained in recognizing hazards in products with hazardous energy levels.
Page 2 © Copyright 2017－2020 Hewlett Packard Enterprise Development LP Notices The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.
Page 3: Table Of Contents
Contents Component identification....................8 Front panel components......................................8 Serial number/iLO information pull tab............................10 Front panel LEDs and buttons....................................10 UID button functionality..................................11 Power fault LEDs......................................11 Rear panel components......................................12 Rear panel LEDs..........................................13 PCIe riser board slot definitions...................................14 PCIe slot description........................................17 System board components.....................................
Page 4 Electrical grounding requirements..............................45 Server warnings and cautions....................................45 Rack warnings..........................................46 Electrostatic discharge......................................47 Installing the server into the rack..................................47 POST screen options........................................49 Operating system......................................... 49 Installing the operating system with Intelligent Provisioning..................50 Installing or deploying an operating system..........................50 Hardware options installation..................
Page 5 Installing the serial port......................................96 Power supply option........................................97 Hot-plug power supply calculations..............................97 Installing the redundant power supply assembly........................97 Installing the chassis intrusion detection switch.............................103 HPE Trusted Platform Module 2.0 Gen10 option..........................104 Overview........................................104 HPE Trusted Platform Module 2.0 guidelines........................104 Installing and enabling the HPE TPM 2.0 Gen10 option....................
Page 6 Active Health System Viewer..................................... 133 Active Health System.................................... 133 HPE iLO 5............................................134 iLO Federation......................................134 iLO Service Port......................................135 iLO RESTful API......................................136 RESTful Interface Tool..................................136 iLO Amplifier Pack....................................136 Integrated Management Log....................................136 Intelligent Provisioning......................................136 Intelligent Provisioning operation..............................137 Management security......................................138 Scripting Toolkit for Windows and Linux..............................
Page 7 Support and other resources..................157 Accessing Hewlett Packard Enterprise Support............................. 157 Accessing updates........................................157 Remote support..........................................158 Warranty information......................................158 Regulatory information......................................158 Documentation feedback......................................159...
Page 8: Component Identification
Component identification Front panel components • 8-bay LFF drive model Item Description LFF drives Optical drive (optional) iLO Service Port USB 3.0 port • 12-bay LFF drive model Item Description LFF drives USB 3.0 port • 8-bay SFF drive model Component identification...
Page 9 Item Description Optical drive (optional) 8-bay SFF drive bays (optional) SFF drives iLO Service Port USB 3.0 port Serial number/iLO information pull tab • 16-bay SFF drive model Item Description Optical drive (optional) SFF drives iLO Service Port USB 3.0 port Serial number/iLO information pull tab •...
Page 10: Serial Number/Ilo Information Pull Tab
Serial number/iLO information pull tab The serial number/iLO information pull tab is double-sided. One side shows the server serial number and the QR code labels. The other side shows the default iLO account information. Use a mobile device to scan the QR code label to display the server mobile product page (https://www.hpe.com/qref/ dl180gen10).
Page 11: Uid Button Functionality
Solid green = Normal Health LED Flashing green (1 flash per second) = iLO is rebooting Flashing amber = System degraded Flashing red (1 flash per second) = System critical If the health LED indicates a degraded or critical state, review the system IML ("Integrated Management Log"...
Page 12: Rear Panel Components
Subsystem LED behavior FlexibleLOM 5 flashes Removable HPE Flexible Smart Array controller 6 flashes System board PCIe slots 7 flashes Power backplane or storage backplane 8 flashes Power supply 9 flashes Rear panel components Rear panel components with optional rear 2-bay SFF SAS/SATA drives Item Description PCIe slots 1 - 3 top to bottom (primary riser for processor 1)
Page 13: Rear Panel Leds
Item Description PCIe slots 1 - 3 top to bottom (primary riser for processor 1) FlexibleLOM (optional) Serial port (optional) PCIe slots 4 - 6 (secondary riser for processor 2, optional) Flexible Slot power supply 1 (hot-plug) Flexible Slot power supply 2 (hot-plug, optional) NIC port 2 NIC port 1 VGA port...
Page 14: Pcie Riser Board Slot Definitions
NIC activity LED Solid green = Link to network Flashing green = Network active Off = No network activity UID LED Solid blue = Activated Flashing blue: • 1 flash per second = Remote management or firmware upgrade in progress •...
Page 15 Item Type Form factor Connector link width Negotiable link width PCIe 3.0 Full height, full length 16, 8, 4, 1 PCIe 3.0 Full height, full length 8, 4, 1 • Three-slot PCIe riser cage assembly: By default, installed in the primary PCIe riser connector Item Type Form factor...
Page 16 Item Type Form factor Connector link width Negotiable link width PCIe 3.0 Full height, full length 16, 8, 4, 1 PCIe 3.0 Half height, half length 8, 4, 1 • x8, x8, x8 secondary riser cage assembly: Install in the secondary PCIe riser connector. Component identification...
Page 17: Pcie Slot Description
Item Type Form factor Connector link width Negotiable link width PCIe 3.0 Full height, full length 8, 4, 1 PCIe 3.0 Full height, half length 8, 4, 1 PCIe 3.0 Half height, half length 8, 4, 1 PCIe slot description Item Description Definition...
Page 18: System Board Components
System board components Item Description Secondary PCIe riser connector for processor 2 Smart Array modular controller connector microSD card slot TPM connector Serial port connector iLO Service Port connector Primary PCIe riser connector for processor 1 System maintenance switch Mini-SAS port 1 Mini-SAS port 3 Media Module adapter connector Mini-SAS port 2...
Page 19: System Maintenance Switch Descriptions
Front I/O cable connector Fan connector 6 Fan connector 5 Fan connector 4 Fan connector (Reserved) Fan connector 3 Fan connector 2 Fan connector 1 Energy pack connector Chassis intrusion detection switch connector Drive backplane power connector Rear drive power connector Non-hot-plug power supply connector System battery Internal USB 3.0 port...
Page 20: Dimm Label Identification
Position Default Function — Reserved — Reserved To access the redundant ROM, set S1, S5, and S6 to On. When the system maintenance switch position 6 is set to the On position, the system is prepared to restore all configuration settings to their manufacturing defaults.
Page 21: Dimm Slot Locations
Item Description Example Data width on DRAM x4 = 4-bit x8 = 8-bit x16 = 16-bit Memory generation PC4 = DDR4 Maximum memory speed 2133 MT/s 2400 MT/s 2666 MT/s 2933 MT/s CAS latency P = CAS 15-15-15 T = CAS 17-17-17 U = CAS 20-18-18 V = CAS 19-19-19 (for RDIMM, LRDIMM) V = CAS 22-19-19 (for 3DS TSV LRDIMM)
Page 22: Processor, Heatsink, And Socket Components
The arrow points to the front of the server. Processor, heatsink, and socket components Item Description Heatsink nuts Processor carrier Pin 1 indicator Heatsink guide/keying feature Alignment post Heatsink keying frame Symbol also on the processor and frame. Component identification...
Page 23: Drive Leds And Buttons
Drive LEDs and buttons Low-profile LFF drive LED definitions Item Status Definition Fault Solid amber The drive has failed. \Locate Solid blue The drive is operating normally and being identified by a management application. Flashing amber/blue The drive has failed, or a predictive failure alert has been received for this drive;...
Page 24: Smart Carrier (Sc) Drive Led Definitions
Smart Carrier (SC) drive LED definitions Item Status Definition Locate Solid blue The drive is being identified by a host application. Flashing blue The drive carrier firmware is being updated or requires an update. Activity Rotating green Drive activity ring No drive activity Do not Solid white...
Page 25: Drive Bay Numbering
• Rear box Drive bay numbering • 8-bay LFF hot-plug drive model • 12-bay LFF hot-plug drive model Component identification...
Page 26 • 8-bay SFF hot-plug drive model • 16-bay SFF hot-plug drive model • 24-bay SFF hot-plug drive model Component identification...
Page 27: Fan Bay Numbering
Fan bay numbering Component identification...
Page 28: Operations
Operations Power up the server Procedure 1. To power up the server, use one of the following methods: • Press the Power On/Standby button. • Use the virtual power button through iLO. Power down the server Before powering down the server for any upgrade or maintenance procedures, perform a backup of critical server data and programs.
Page 29: Removing The Server From The Rack
a. Power down the server. b. Disconnect all peripheral cables from the server. c. Disconnect each power cord from the server. 2. Disengage the server from the rack: a. Pull down the quick release levers on each side of the server. b.
Page 30: Releasing The Cable Management Arm
a. Disconnect all peripheral cables from the server. b. Disconnect each power cord from the server. 3. Extend the server from the rack. 4. Remove the server from the rack. For instructions on how to extend or remove the server from the rack, see the documentation that ships with the rack rail system.
Page 31: Removing The Access Panel
Removing the access panel WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the internal system components to cool before touching them. CAUTION: To prevent damage to electrical components, take the appropriate anti-static precautions before beginning any installation, removal, or replacement procedure.
Page 32: Installing The Access Panel
Installing the access panel Prerequisites • T-15 Torx screwdriver • All internal cables must be connected and secured with clips. Procedure 1. Place the access panel on top of the server with the latch open. Allow the panel to extend past the rear of the server approximately 1.25 cm (0.5 in). 2.
Page 33: Removing A Riser Cage
Removing a riser cage WARNING: To reduce the risk of personal injury from hot surfaces, allow the drives and the internal system components to cool before touching them. Procedure 1. If installed, remove the front bezel. 2. Power down the server. 3.
Page 34: Removing An Expansion Slot Blank
Removing an expansion slot blank Prerequisites T-10 Torx screwdriver Procedure 1. Power down the server. 2. Remove all power: a. Disconnect each power cord from the power source. b. Disconnect each power cord from the server. 3. Do one of the following: •...
Page 35 • Primary riser cage • Secondary riser cage ◦ Slot 4 ◦ Slot 5 or 6 Operations...
Page 36: Removing A Riser Board
Removing a riser board Prerequisites T-15 Torx screwdriver Procedure 1. Power down the server. 2. Remove all power: a. Disconnect each power cord from the power source. b. Disconnect each power cord from the server. 3. Do one of the following: Extend the server from the rack.
Page 37: Removing The Air Baffle
• Secondary riser cage Removing the air baffle CAUTION: For proper cooling, do not operate the server without the access panel, baffles, expansion slot blanks, or blanks installed. If the server supports hot-plug components, minimize the amount of time the access panel is open. Procedure 1.
Page 38: Installing The Air Baffle
6. Remove the access panel. 7. If the 12G SAS expander is installed, remove the riser cage. 8. Remove the air baffle. Installing the air baffle CAUTION: For proper cooling, do not operate the server without the access panel, baffles, expansion slot blanks, or blanks installed.
Page 39 3. Install the access panel. 4. Install the server into the rack. 5. Connect all peripheral cables to the server. 6. Connect each power cord to the server. 7. Connect each power cord to the power source. 8. Power up the server. 9.
Page 40: Setup
Setup Optional service Delivered by experienced, certified engineers, Hewlett Packard Enterprise support services help you keep your servers up and running with support packages tailored specifically for HPE ProLiant systems. Hewlett Packard Enterprise support services let you integrate both hardware and software support into a single package. A number of service level options are available to meet your business and IT needs.
Page 41: Setting Up The Server
• Installation by an HPE authorized technical specialist. • Verification prior to installation that all service prerequisites are met. • Delivery of the service at a mutually scheduled time convenient to your organization. • Allows your IT resources to stay focused on their core tasks and priorities. •...
Page 42 The server does not ship with OS media. All system software and firmware is preloaded on the server. Install the hardware options (Optional) Install hardware options. For installation instructions, see Hardware options installation. Rack the server Install the server in a rack. Decide how to manage the server: •...
Page 43: Operational Requirements
• To configure the server to boot from a SAN, see the following guide: https://www.hpe.com/info/boot-from-san-config-guide • If an HPE Smart Array SR controller is installed, use HPE Smart Storage Administrator to create arrays: a. From the boot screen, press F10 to run Intelligent Provisioning. b.
Page 44: Space And Airflow Requirements
Space and airflow requirements To allow for servicing and adequate airflow, observe the following space and airflow requirements when deciding where to install a rack: • Leave a minimum clearance of 63.5 cm (25 in) in front of the rack. •...
Page 45: Power Requirements
Power requirements Installation of this equipment must comply with local and regional electrical regulations governing the installation of information technology equipment by licensed electricians. This equipment is designed to operate in installations covered by NFPA 70, 1999 Edition (National Electric Code) and NFPA-75, 1992 (code for Protection of Electronic Computer/Data Processing Equipment).
Page 46: Rack Warnings
WARNING: To reduce the risk of fire or burns after removing the energy pack: • Do not disassemble, crush, or puncture the energy pack. • Do not short external contacts. • Do not dispose of the energy pack in fire or water. •...
Page 47: Electrostatic Discharge
Electrostatic discharge Be aware of the precautions you must follow when setting up the system or handling components. A discharge of static electricity from a finger or other conductor may damage system boards or other static-sensitive devices. This type of damage may reduce the life expectancy of the system or component.
Page 48 6. Install the rack rail hook-and-loop strap. 7. Secure the cables to the cable management arm. IMPORTANT: When using cable management arm components, leave enough slack in each of the cables to prevent damage to the cables when the server is extended from the rack. 8.
Page 49: Post Screen Options
WARNING: To reduce the risk of electric shock or damage to the equipment: • Do not disable the power cord grounding plug. The grounding plug is an important safety feature. • Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all times. •...
Page 50: Installing The Operating System With Intelligent Provisioning
For more information on using these installation methods, see the Hewlett Packard Enterprise website. Installing the operating system with Intelligent Provisioning Procedure 1. Connect the Ethernet cable between the network connector on the server and a network jack. 2. Press the Power On/Standby button. 3.
Page 51: Hardware Options Installation
Hardware options installation This chapter provides detailed instructions on how to install hardware options. For more information on supported options, see the product QuickSpecs on the website at: http://www.hpe.com/info/qs To view the warranty for your server and supported options, see Warranty information. Introduction Install any hardware options before initializing the server.
Page 52: Drive Options
Drive options Drive guidelines Depending on the configuration, the server supports SAS and SATA drives. • The system automatically sets all drive numbers. • If only one drive is used, install it in the bay with the lowest drive number. For drive numbering, see Drive bay numbering.
Page 53 Procedure 1. If installed, remove the front bezel. 2. Remove the drive blank. • • 3. Prepare the drive. • Hardware options installation...
Page 54 • 4. Install the drive. • • Hardware options installation...
Page 55: Drive Cage Options
5. If removed, install the front bezel. 6. Determine the status of the drive from the drive LED definitions. The installation is complete. To configure arrays, see the HPE Smart Array SR Gen10 Configuration Guide at the Hewlett Packard Enterprise website.
Page 56 Do one of the following: • Extend the server from the rack. Remove the server from the rack. • Remove the access panel. Remove the air baffle. Remove the 8-bay SFF drive box blank. Install the 8-bay SFF drive cage. 10.
Page 57: Installing The Rear 2-Bay Sff Drive Cage
14. Install the air baffle. 15. Install the access panel. 16. Install the server into the rack. 17. Connect all peripheral cables to the server. 18. Connect each power cord to the server. 19. Connect each power cord to the power source. 20.
Page 58 Remove the air baffle. If installed, remove one of the following components: a. Secondary riser cage blank b. Secondary riser cage Install the rear 2-bay SFF drive cage: a. Remove the screw from the system board. b. Install the rear 2-bay SFF drive cage, and then install the screws. Hardware options installation...
Page 59: Installing The 8 To 12 Upgrade Option In The Lff Chassis
10. Connect the Mini-SAS cable or the SATA and the SATA management port cables. 11. Connect rear 2-bay SFF power cable. 12. Install the drives. 13. Install the air baffle. 14. Install the access panel. 15. Install the server into the rack. 16.
Page 60 a. Disconnect each power cord from the power source. b. Disconnect each power cord from the server. Disconnect all peripheral cables from the server. Do one of the following: • Extend the server from the rack. • Remove the server from the rack. Remove the access panel.
Page 61 Retain the fillers for future use. 12. Install the partition. a. Lift the top cover upward slightly. b. Insert the partition. c. Secure the partition with two screws. 13. Remove all fans. Hardware options installation...
Page 62 14. Install the drive backplane. 15. Connect the Mini-SAS cable. 16. Disconnect the existing power cable. 17. Connect the power cable. 18. Install the drive in box 1. 19. Install all fans. Hardware options installation...
Page 63: Optical Drive Cage And Optical Drive Options
20. Install the air baffle. 21. Install the access panel. 22. Install the server into the rack. 23. Connect all peripheral cables to the server. 24. Connect each power cord to the server. 25. Connect each power cord to the power source. 26.
Page 64 a. Disconnect each power cord from the power source. b. Disconnect each power cord from the server. Disconnect all peripheral cables from the server. Do one of the following: • Extend the server from the rack. • Remove the server from the rack. Remove the access panel.
Page 65 b. Install the optical drive into cage. c. Install the optical drive cage into the box 1. Hardware options installation...
Page 66: Installing The Optical Drive In The Sff Chassis
d. Connect the optical drive cable. 11. Connect the iLO service port cable to system board. 12. Install the air baffle. 13. Install the access panel. 14. Install the server into the rack. 15. Connect all peripheral cables to the server. 16.
Page 67 a. Disconnect each power cord from the power source. b. Disconnect each power cord from the server. Disconnect all peripheral cables from the server. Do one of the following: • Extend the server from the rack. • Remove the server from the rack. Remove the access panel.
Page 68 10. Install the cage assembly into box 1. 11. Connect the optical drive cable. 12. Install the air baffle. 13. Install the access panel. 14. Install the server into the rack. 15. Connect all peripheral cables to the server. 16. Connect each power cord to the server. 17.
Page 69: Storage Controller Options
Storage controller options The server supports the following storage controllers: • For SATA drives only – Embedded HPE Smart Array S100i SR Gen10 Controller. • For SAS and SATA drives: ◦ Smart Array type-a modular controller ◦ Smart Array PCIe plug-in controller For more information on PCIe slot descriptions, see PCIe riser board slot definitions.
Page 70 • If the new Smart Array is the new boot device, install the device drivers. • If the new Smart Array is not the new boot device, go to the next step. 5. Ensure that users are logged off and that all tasks are completed on the server. CAUTION: In systems that use external data storage, be sure that the server is the first unit to be powered down and the last to be powered back up.
Page 71: Configuring An Hpe Smart Array Gen10 Controller
• For the Smart Array PCIe plug-in controller, install the controller into an expansion slot. Cable the controller. 10. To enable HPE Smart Array SR SmartCache in a Smart Array P-class Gen10 controller, install an energy pack. SmartCache and CacheCade enable solid-state drives to be used as caching devices for hard drive media. These features accelerate access to frequently used data by caching hot data from the hard drives onto the solid-state drives.
Page 72: Energy Pack Options
6. If the new controller is not the new boot device, install the device drivers. 7. If the controller firmware is not the latest version, use SPP to update it. 8. Use UEFI System Utilities or HPE Smart Storage Administrator (HPE SSA) to create arrays and logical drives. See the following resources for more information: •...
Page 73: Installing An Energy Pack
The capacitor pack is fully charged after the system boots. Minimum firmware versions Product Minimum firmware version 2.00 HPE ProLiant DL180 Gen10 Server system ROM HPE Smart Array SR controllers 1.90 Installing an energy pack Prerequisites Before you perform this procedure: •...
Page 74 Route the energy pack cable as shown in below illustration. 10. Connect the storage controller backup power cable. 11. Install the air baffle. 12. If removed, install the secondary riser cage. 13. Install the access panel. 14. Install the server into the rack. 15.
Page 75: M.2 Ssd Enablement Option
The installation is complete. M.2 SSD enablement option The server supports the installation of one M.2 SSD enablement board. Each enablement board can support two M.2 SSDs. The M.2 SSD enablement board is supported in the PCIe3 expansion slots 1–4. Use the embedded HPE Smart Array S100i SR Gen10 Controller to manage the M.2 SATA SSDs.
Page 76: Processor Heatsink Assembly Option
a. Insert the SSD into the M.2 slot at a 45° angle. b. Carefully press the SSD down to the horizontal position. c. Install the SSD mounting screw. d. If you are installing a second SSD, repeat steps a–c. 10. Connect the SATA cable to enablement board. 11.
Page 77: Installing The Processor Heatsink Assembly
CAUTION: If installing a processor with a faster speed, update the system ROM before installing the processor. To download firmware and view installation instructions, see the Hewlett Packard Enterprise Support Center website. CAUTION: THE CONTACTS ARE VERY FRAGILE AND EASILY DAMAGED. To avoid damage to the socket or processor, do not touch the contacts.
Page 78 a. Locate and align the Pin 1 indicator on the processor frame and the socket. b. Align the processor heatsink assembly with the heatsink alignment posts and gently lower it down until it sits evenly on the socket. The heatsink alignment posts are keyed. The processor will only install one way. A standard heatsink is shown, your heatsink might look different.
Page 79: Enable The Enhanced Cooling Function
11. Install the air baffle. 12. Install the access panel. 13. Install the server into the rack. 14. Connect all peripheral cables to the server. 15. Connect each power cord to the server. 16. Connect each power cord to the power source. 17.
Page 80: Fan Mode Behavior
Configuration Fan redundancy Bay 1 Bay 2 Bay 3 Bay 4 Bay 5 Bay 6 One processor with rear 2-SFF drives installed Two processors Blank Two processors Fan mode behavior • In nonredundant fan mode, a fan failure or a missing fan causes: ◦...
Page 81 10. Install the fan: a. Install the fan into the fan cage. b. Route the fan cable through the groove on the fan cage. c. Connect the fan cable to the system board. 11. Install the air baffle. 12. Install the access panel. 13.
Page 82: Memory Options
17. Power up the server. 18. If removed, install the front bezel. The installation is complete. Memory options IMPORTANT: This server does not support mixing LRDIMMs and RDIMMs. Attempting to mix any combination of these DIMMs can cause the server to halt during BIOS initialization. All memory installed in the server must be of the same type.
Page 83: Riser Board And Riser Cage Options
The DIMM slots are structured to ensure proper installation. If you try to insert a DIMM but it does not fit easily into the slot, you might have positioned it incorrectly. Reverse the orientation of the DIMM and insert it again. Install the air baffle.
Page 84 a. Disconnect each power cord from the power source. b. Disconnect each power cord from the server. Disconnect all peripheral cables from the server. Do one of the following: • Extend the server from the rack. • Remove the server from the rack. Remove the access panel.
Page 85: Installing A Pcie Riser Cage
13. Connect all peripheral cables to the server. 14. Connect each power cord to the server. 15. Connect each power cord to the power source. 16. Power up the server. The installation is complete. Installing a PCIe riser cage Prerequisites Before you perform this procedure, make sure that you have a T-15 Torx screwdriver available.
Page 86 • Rear 2-bay SFF drive cage If installing the expansion board, do it now. Install the riser cage: a. Align the riser board with the corresponding connectors on the system board, and then press down the PCIe riser cage. b. Push down the release tab, rotate it 180° clockwise, and then press it flat on the PCIe riser cage. •...
Page 87: Expansion Board Options
• Secondary riser cage Install the access panel. 10. Install the server into the rack. 11. Connect all peripheral cables to the server. 12. Connect each power cord to the server. 13. Connect each power cord to the power source. 14.
Page 88: Pcie Slot Guidelines For Network Cards And Pcie Workload Accelerator Options
PCIe slot guidelines for network cards and PCIe workload accelerator options The following table shows the PCIe riser board slots supported with the network cards and the PCIe workload accelerator options of the server. Component Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Slot 6...
Page 89 • Primary riser cage • Secondary riser cage ◦ Slot 4 ◦ Slot 5 or 6 Hardware options installation...
Page 90: Installing The Flexiblelom Adapter
12. If internal cables are required for the expansion board, connect the cables. 13. If removed, install the air baffle. 14. Install the riser cage. 15. Connect all cables to system board/backplane. 16. Install the access panel. 17. Install the server into the rack. 18.
Page 91 Remove all power: a. Disconnect each power cord from the power source. b. Disconnect each power cord from the server. Disconnect all peripheral cables from the server. Do one of the following: Extend the server from the rack. • Remove the server from the rack. •...
Page 92: Installing The Media Module Adapter
10. Install the FlexibleLOM riser cage. 11. Install the access panel. 12. Install the server into the rack. 13. Connect the LAN segment cables. 14. Connect all peripheral cables to the server. 15. Connect each power cord to the server. 16.
Page 93 • Extend the server from the rack. • Remove the server from the rack. Remove the access panel. Remove the primary riser cage. Remove the Media Module adapter blank. Install the Media Module adapter: a. Align the Media Module adapter to the opening on the rear panel. b.
Page 94 d. Install the Media Module adapter screws. 10. Install the primary riser cage. 11. Install the access panel. 12. Install the server into the rack. 13. Connect all peripheral cables to the server. 14. Connect each power cord to the server. 15.
Page 95: Internal Usb Device Option
Internal USB device option The server has one internal USB 3.0 port. You can use this port to install internal USB device, that is intended to be rarely removed, such as USB flash media devices for booting up from flash solutions or for data backup/redundancy. Installing an internal USB device Procedure If installed, remove the front bezel.
Page 96: Installing The Serial Port
14. Power up the server. 15. If removed, install the front bezel. The installation is complete. Installing the serial port Prerequisites Before you perform this procedure, make sure that you have a hex nut screwdriver available. Procedure If installed, remove the front bezel. Power down the server.
Page 97: Power Supply Option
Install the access panel. Install the server into the rack. Connect all peripheral cables to the server. 10. Connect each power cord to the server. 11. Connect each power cord to the power source. 12. Power up the server. 13. If removed, install the front bezel. The installation is complete.
Page 98 Prerequisites Before you perform this procedure, make sure that you have the following items available: • T-10 Torx screwdriver • T-15 Torx screwdriver Procedure If installed, remove the front bezel. Power down the server. Remove all power: a. Disconnect each power cord from the power source. b.
Page 99 Secondary riser cage • • Rear 2-bay SFF drive cage 10. Remove the non-hot-plug power supply. Hardware options installation...
Page 100 11. Install the power supply cage: a. Align the arrow on the power supply cage with the arrow on the chassis as shown in following illustration. b. Install the power supply cage. Hardware options installation...
Page 101 12. Install the power supply in bay 1. 13. If enabling redundant power supply mode, do the following: a. Remove the power supply bay 2 blank. Hardware options installation...
Page 102 b. Install the power supply in bay 2. 14. If removed, install one of the following items: • Secondary riser cage blank Secondary riser cage • • Rear 2-bay SFF SAS/SATA drive cage 15. Install the air baffle. 16. Install the access panel. 17.
Page 103: Installing The Chassis Intrusion Detection Switch
Installing the chassis intrusion detection switch Procedure If installed, remove the front bezel. Power down the server. Remove all power: a. Disconnect each power cord from the power source. b. Disconnect each power cord from the server. Disconnect all peripheral cables from the server. Remove the air baffle.
Page 104: Hpe Trusted Platform Module 2.0 Gen10 Option
HPE Trusted Platform Module 2.0 Gen10 option Overview Use these instructions to install and enable an HPE TPM 2.0 Gen10 Kit in a supported server. This option is not supported on a Gen9 and earlier server. This procedure includes three sections: 1.
Page 105: Installing And Enabling The Hpe Tpm 2.0 Gen10 Option
• If the TPM is removed from the original server and powered up on a different server, all data stored in the TPM including keys will be erased. • When using BitLocker, always retain the recovery key/password. The recovery key/password is required to complete Recovery Mode after BitLocker detects a possible compromise of system integrity.
Page 106 8. Remove any components or cables that may prevent access to the TPM connector. 9. Proceed to Installing the TPM board and cover. Installing the TPM board and cover Procedure 1. Observe the following alerts: CAUTION: If the TPM is removed from the original server and powered up on a different server, data stored in the TPM including keys will be erased.
Page 107 4. Proceed to Preparing the server for operation. Preparing the server for operation Procedure 1. Install any options or cables previously removed to access the TPM connector. 2. Install the access panel. 3. Install the server into the rack. 4. Connect each power cord to the server. 5.
Page 108 • "Current TPM Type" is set to TPM 2.0. • "Current TPM State" is set to Present and Enabled. "TPM Visibility" is set to Visible. • 4. If changes were made in the previous step, press the F10 key to save your selection. 5.
Page 109 For more information, see the Microsoft website. Retaining the BitLocker recovery key/password The recovery key/password is generated during BitLocker setup, and can be saved and printed after BitLocker is enabled. When using BitLocker, always retain the recovery key/password. The recovery key/password is required to enter Recovery Mode after BitLocker detects a possible compromise of system integrity.
Page 110: Cabling
Cabling Cabling guidelines The cable colors in the cabling diagrams used in this chapter are for illustration purposes only. Observe the following guidelines when working with server cables. Before connecting cables • Note the port labels on the PCA components. Not all these components are used by all servers: ◦...
Page 111: Cable Routing: Lff Drive Model
• Remove cables that are no longer being used. Retaining them inside the server can restrict airflow. If you intend to use the removed cables later, label and store them for future use. Cable routing: LFF drive model LFF drive to system board Cabling...
Page 112: Lff Drive To Smart Array P408I-A Sr Gen10 Controller
Color Description Orange LFF box 1 to Mini-SAS port 1 Blue LFF box 2 to Mini-SAS port 2 Gold LFF box 3 to Mini-SAS port 3 LFF drive to Smart Array P408i-a SR Gen10 controller Color Description Orange Box 1 Mini-SAS cable to the onboard SATA port 1* Blue Box 2 to the Smart Array P408i-a SR Gen10 controller port 1 Gold...
Page 113: Lff Drive To Smart Array P816I-A Sr Gen10 Controller
LFF drive to Smart Array P816i-a SR Gen10 controller Color Description Orange Box 1 to the Smart Array P816i-a SR Gen10 controller port 1 Blue Box 2 to the Smart Array P816i-a SR Gen10 controller port 2 Gold Box 3 to the Smart Array P816i-a SR Gen10 controller port 3 LFF drive to type-p controller Color Description...
Page 114: 8-Bay Lff And Optical Drive Power Cable
* Box 1 can be connected to a type-a controller port 1. 8-bay LFF and optical drive power cable Color Description Orange P2 power cable to LFF box 2 Blue P3 power cable to LFF box 3 Gold P4 power cable to the optical drive 12-bay LFF power cable Color Description...
Page 115: Cable Routing: Sff Drive Model
Blue P3 power cable to LFF box 2 Gold P4 power cable to LFF box 3 Cable routing: SFF drive model Box 1 to Smart Array P408i-a SR Gen10 controller Box 1 to type-p controller Cabling...
Page 116: Box 2 To Smart Array P408I-A Sr Gen10 Controller
Box 2 to Smart Array P408i-a SR Gen10 controller Box 2 to type-p controller Cabling...
Page 117: Box 3 To System Board
Box 3 to system board Box 3 to Smart Array P408i-a SR Gen10 controller Cabling...
Page 118: Boxes 2 And 3 To Smart Array P816I-A Sr Gen10 Controller
Boxes 2 and 3 to Smart Array P816i-a SR Gen10 controller Color Description Orange Box 2 to the Smart Array P816i-a SR Gen10 controller ports 1 and 2 Blue Box 3 to the Smart Array P816i-a SR Gen10 controller ports 3 and 4 Box 3 to type-p controller Cabling...
Page 119: 8-Bay Sff Power Cable (Default)
8-bay SFF power cable (default) 16-bay/24-bay SFF power cable Color Description Pink P2 power cable to SFF box 1 Blue P3 power cable to SFF box 2 Gold P4 power cable to SFF box 3 Orange P5 power cable to optical drive Cable routing: 12G SAS expander •...
Page 120 Color Description Blue Smart Array P408i-a SR Gen10 controller port 1 to 12G SAS expander port 1 Orange Smart Array P408i-a SR Gen10 controller port 2 to 12G SAS expander port 2 • Type-p controller to SAS expander Color Description Orange Type-p controller port 1 to 12G SAS expander port 1 Blue...
Page 121: Cable Routing: Rear 2-Bay Sff Drive
Color Description Orange and Blue 12G SAS expander ports 3 & 4 to SFF box 1 ports 1 & 2 Gold and Pink 12G SAS expander ports 5 & 6 to SFF box 2 ports 1 & 2 Green and Black 12G SAS expander ports 7 &...
Page 122: Mini-Sas Cable To Smart Array P408I-A Sr Gen10 Controller
Mini-SAS cable to Smart Array P408i-a SR Gen10 controller Mini-SAS cable to Smart Array P816i-a SR Gen10 controller Cabling...
Page 123: Mini-Sas Cable To Type-P Controller
Mini-SAS cable to type-p controller Mini-SAS cable to SAS expander Cabling...
Page 124: Sata Cable To System Board
SATA cable to system board Color Description Orange Rear 2-bay SFF drive backplane to SATA port 5 Blue Rear 2-bay SFF drive backplane to SATA port 4 Gold Rear 2-bay SFF drive backplane to SATA management port Rear 2-bay SFF power cable Cable routing: M.2 SSD •...
Page 125 • M.2 SSD enablement board installed in secondary riser Cabling...
Page 126: Cable Routing: Energy Pack
Cable routing: Energy pack Cable routing: Optical drive • Color Description Orange Optical drive signal cable to SATA port 5 Blue Optical drive power cable Gold Optical drive power cable • Cabling...
Page 127: Cable Routing: Fan
Color Description Orange Optical drive signal cable to SATA port 5 Blue Optical drive power cable Gold Optical drive power cable Cable routing: Fan Cable routing: Front I/O • Cabling...
Page 128 Color Description Orange Front I/O cable Blue USB cable Gold Thermal sensor cable • Color Description Orange Front I/O cable Blue USB cable Gold Thermal sensor cable Cabling...
Page 129: Cable Routing: Usb 3.0
Cable routing: USB 3.0 Cable routing: Serial port Cable routing: iLO Service Port • Cabling...
Page 130 • Cabling...
Page 131: Cable Routing: Chassis Intrusion Detection Switch
Cable routing: Chassis intrusion detection switch Cable routing: Controller backup power cable • Primary riser cage • Secondary riser cage ◦ Slot 4 Cabling...
Page 132 ◦ Slot 5 or 6 Cabling...
Page 133: Software And Configuration Utilities
Software and configuration utilities Server mode The software and configuration utilities presented in this section operate in online mode, offline mode, or in both modes. Software or configuration utility Server mode Active Health System Online and Offline HPE iLO 5 Online and Offline HPE Smart Storage Administrator Online and Offline...
Page 134: Hpe Ilo 5
The Active Health System provides: • Continuous health monitoring of over 1600 system parameters • Logging of all configuration changes • Consolidated health and service alerts with precise time stamps • Agentless monitoring that does not affect application performance For more information about the Active Health System, see the iLO user guide at the following website: https:// www.hpe.com/support/ilo-docs.
Page 135: Ilo Service Port
When configured for iLO Federation, iLO uses multicast discovery and peer-to-peer communication to enable communication between the systems in iLO Federation groups. When you navigate to one of the iLO Federation pages, a data request is sent from the iLO system running the web interface to its peers, and from those peers to other peers until all data for the selected iLO Federation group is retrieved.
Page 136: Ilo Restful Api
For more information about the iLO Service Port, see the iLO user guide at the following website: https://www.hpe.com/ support/ilo-docs. iLO RESTful API iLO includes the iLO RESTful API, which is Redfish API conformant. The iLO RESTful API is a management interface that server management tools can use to perform configuration, inventory, and monitoring tasks by sending basic HTTPS operations (GET, PUT, POST, DELETE, and PATCH) to the iLO web server.
Page 137: Intelligent Provisioning Operation
NOTE: • Rapid Setup Software is only available on the ProLiant 300 Series servers or below. When you launch F10 mode from the POST screen, you are prompted to select whether you want to enter the Intelligent Provisioning or HPE Rapid Setup Software mode.
Page 138: Management Security
Intelligent Provisioning provides installation help for the following operating systems: • Microsoft Windows Server • Red Hat Enterprise Linux • SUSE Linux Enterprise Server • VMware ESXi/vSphere Custom Image • ClearOS Not all versions of an OS are supported. For information about specific versions of a supported operating system, see the OS Support Matrix on the Hewlett Packard Enterprise website (https://www.hpe.com/info/ossupport).
Page 139: Selecting The Boot Mode
• Support for boot partitions larger than 2.2 TB. Such configurations could previously only be used for boot drives when using RAID solutions. • Secure Boot that enables the system firmware, option card firmware, operating systems, and software collaborate to enhance platform security.
Page 140: Launching The Embedded Uefi Shell
• Preboot UEFI Shell applications • OS UEFI boot loaders When Secure Boot is enabled: • Firmware components and operating systems with boot loaders must have an appropriate digital signature to execute during the boot process. • Operating systems must support Secure Boot and have an EFI boot loader signed with one of the authorized keys to boot.
Page 141: Hpe Smart Storage Administrator
HPE Smart Storage Administrator HPE SSA is the main tool for configuring arrays on HPE Smart Array SR controllers. It exists in three interface formats: the HPE SSA GUI, the HPE SSA CLI, and HPE SSA Scripting. All formats provide support for configuration tasks. Some of the advanced tasks are available in only one format.
Page 142: Redundant Rom Support
For additional security, external USB functionality can be disabled through USB options in UEFI System Utilities. Redundant ROM support The server enables you to upgrade or configure the ROM safely with redundant ROM support. The server has a single ROM that acts as two separate ROM images. In the standard implementation, one side of the ROM contains the current ROM program version, while the other side of the ROM contains a backup version.
Page 143 • Discovery engine that finds installed versions of hardware, firmware, and software on nodes. • SUM deploys updates in the correct order and ensures that all dependencies are met before deploying an update. • Interdependency checking. • Automatic and step-by-step Localhost Guided Update process. •...
Page 144: Drivers
4. Launch the System Utilities, and select Embedded Applications > Firmware Update. 5. Select a device. The Firmware Updates screen lists details about your selected device, including the current firmware version in use. 6. Select Select Firmware File. 7. Select the flash file in the File Explorer list. The firmware file is loaded and the Firmware Updates screen lists details of the file in the Selected firmware file field.
Page 145: Software And Firmware
• Download Smart Update Manager for Linux • Download specific drivers To locate the drivers for a server, go to the Hewlett Packard Enterprise Support Center website, and then search for the product name/number. Software and firmware Update software and firmware before using the server for the first time, unless any installed software or components require an older version.
Page 146: System Battery Replacement
System battery replacement System battery information The server contains an internal lithium manganese dioxide, a vanadium pentoxide, or an alkaline battery that provides power to the real-time clock. If this battery is not properly handled, a risk of the fire and burns exists. To reduce the risk of personal injury: •...
Page 147 To replace the component, reverse the removal procedure. 10. Properly dispose of the old battery. For more information about battery replacement or proper disposal, contact an authorized reseller or an authorized service provider. System battery replacement...
Page 148: Troubleshooting
Troubleshooting NMI functionality An NMI crash dump enables administrators to create crash dump files when a system is hung and not responding to traditional debugging methods. An analysis of the crash dump log is an essential part of diagnosing reliability problems, such as hanging operating systems, device drivers, and applications.
Page 149: Specifications
Specifications Environmental specifications Specification Value Temperature range — Operating 10°C to 35°C (50°F to 95°F) Nonoperating -30°C to 60°C (-22°F to 140°F) Relative humidity (noncondensing) — Operating Minimum to be the higher (more moisture) of -12°C (10.4°F) dew point or 8% relative humidity Maximum to be 24°C (75.2°F) dew point or 90% relative humidity Nonoperating...
Page 150: Power Supply Specifications
Power supply specifications Depending on the installed options and the regional location where the server was purchased, the server can be configured with one of the following power supplies: • HPE 500W Flex Slot Platinum Hot-plug Low Halogen Power Supply HPE 800W Flex Slot Platinum Hot-plug Low Halogen Power Supply •...
Page 151: Hpe 800W Flex Slot Platinum Hot-Plug Low Halogen Power Supply
Specification Value Rated steady-state power 500 W at 100 VAC to 127 VAC input 500 W at 100 VAC to 240 VAC input 500 W at 240 VDC input for China only Maximum peak power 500 W at 100 VAC to 127 VAC input 500 W at 100 VAC to 240 VAC input 500 W at 240 VDC input for China only HPE 800W Flex Slot Platinum Hot-plug Low Halogen Power Supply...
Page 152: Hpe 800W Flex Slot Titanium Hot-Plug Low Halogen Power Supply
Specification Value Rated steady-state power 800 W at 100 VAC to 127 VAC input 800 W at 100 VAC to 240 VAC input 800 W at 240 VDC input for China only Maximum peak power 800 W at 100 VAC to 127 VAC input 800 W at 100 VAC to 240 VAC input 800 W at 240 VDC input for China only HPE 800W Flex Slot Titanium Hot-plug Low Halogen Power Supply...
Page 153: Hpe 800W Flex Slot Universal Hot-Plug Low Halogen Power Supply
HPE 800W Flex Slot Universal Hot-plug Low Halogen Power Supply Specification Value Input requirements — Rated input voltage 200 VAC to 277 VAC 380 VDC Rated input frequency 50 Hz to 60 Hz Rated input current 4.4 A at 200 VAC 3.1 A at 277 VAC 2.3 A at 380 VDC Maximum rated input power...
Page 154 Specification Value Rated input power (W) 874 W at -40 VDC input 865 W at -48 VDC input, nominal input 854 W at -72 VDC input Rated input power (BTUs per hour) 2,983 at -40 VDC input 2,951 at -48 VDC input, nominal input 2,912 at -72 VDC input Power supply output Rated steady-state power (W)
Page 155: Hpe 1600 W Flex Slot Platinum Hot-Plug Low Halogen Power Supply
HPE 1600 W Flex Slot Platinum Hot-plug Low Halogen Power Supply Specification Value Input requirements — Rated input voltage 200 VAC to 240 VAC 240 VDC for China only Rated input frequency 50 Hz to 60 Hz Rated input current 8.7 A at 200 VAC 7.2 A at 240 VAC Maximum rated input power...
Page 156: Websites
Storage white papers and analyst reports https://www.hpe.com/storage/whitepapers For additional websites, see Support and other resources. Product websites HPE ProLiant DL180 Gen10 Server product page https://www.hpe.com/servers/dl180-gen10 HPE ProLiant DL180 Gen10 Server support page https://www.hpe.com/support/dl180gen10 HPE ProLiant DL180 Gen10 Server user documents https://www.hpe.com/info/DL180Gen10-docs...
Page 157: Support And Other Resources
Support and other resources Accessing Hewlett Packard Enterprise Support • For live assistance, go to the Contact Hewlett Packard Enterprise Worldwide website: https://www.hpe.com/info/assistance • To access documentation and support services, go to the Hewlett Packard Enterprise Support Center website: https://www.hpe.com/support/hpesc Information to collect •...
Page 158: Remote Support
IMPORTANT: Access to some updates might require product entitlement when accessed through the Hewlett Packard Enterprise Support Center. You must have an HPE Passport set up with relevant entitlements. Remote support Remote support is available with supported devices as part of your warranty or contractual support agreement. It provides intelligent event diagnosis, and automatic, secure submission of hardware event notifications to Hewlett Packard Enterprise, which will initiate a fast and accurate resolution based on your product's service level.
Page 159: Documentation Feedback
Additional regulatory information Hewlett Packard Enterprise is committed to providing our customers with information about the chemical substances in our products as needed to comply with legal requirements such as REACH (Regulation EC No 1907/2006 of the European Parliament and the Council). A chemical information report for this product can be found at: https://www.hpe.com/info/reach For Hewlett Packard Enterprise product environmental and safety information and compliance data, including RoHS and REACH, see:...

HP Enterprise ProLiant DL180 User Manual

Quick Links

Need help?

Questions and answers

Related Manuals for HP Enterprise ProLiant DL180

Summary of Contents for HP Enterprise ProLiant DL180

Table of Contents
