Spitzer LIGHTING ASE Series Installation Manual

ASE SERIES
SPORTS AND HIGH OUTPUT FLOOD
PRODUCT PARAMETER
INPUT VOLTAGE 120-277V, 347-480V
RATING IP65
CONTROL 0-10V, WIRELESS CONTROL

PRE - INSTALLATION

•Carefully remove the fixture from the carton.
•Before beginning assembly, installation, or operation of product, make sure all parts
are present. Compare parts with package contents list and diagram on previous
page. If any part is missing or damaged, do not attempt to assemble, install or
operate the product. Contact customer service for replacement parts.
• Tools required for assembly (Not Included): screwdriver, phillips screwdriver, pliers,
electrical tape, wire cutters, safety glasses, ladder, wire stripper.
www.spitzerlighting.com
I N S T A L L A T I O N M A N U A L
BE SURE THE POWER IS OFF! RISK OF ELECTRICAL SHOCK: Always use the switch to power off. Do not perform
any operations while this unit is powered on. The electrical system you want to connect the device to must be
grounded. Read the instructions before using or powering this device. The safety instructions must remain with
the unit in case of transfer. Any damage to the device linked to an inappropriate use is excluded from support by
the warranty. Before connecting, make sure that the current and voltage are compatible with this device. We highly
recommend that all installations are made by QUALIFIED ELECTRICIAN. We are NOT responsible by any means for
the use or misuse of the following information. We are NOT responsible in whole or part for any harm or damage
that may or may not be caused. We reserve the right to revise the components of any product, due to part availability
or change ETL, CUL, UL standards without assuming any obligation or liability to modify any products previously
manufactured and without notice. These instructions do not cover all details of variations in equipment, nor do they
provide every possible contingency to be met. Turn off / unplug power when installing or service device.
WARNING: Read all safety precautions and installation instructions carefully before installing or servicing this
fixture. Failure to comply with these instructions could result in a potentially fatal electric shock, fire, and/or
property damage.
• All electrical work must conform to the National Electric Code (NEC) and all applicable local codes and ordinances.
• Only qualified personnel shall install and maintain the luminaires. Spitzer recommends that a licensed electrician
install and maintain the luminaire. Verify the safety of existing power distribution system before beginning
installation. Failure to follow Operating Instructions may lead to death, Severe Injury, or Property Damage.
• Fixtures must be grounded and installed in accordance with the National Electrical Code and all local codes. If
you are not sure if your power system is grounded, DO NOT install the luminaire. Contact a licensed electrician for
information on proper grounding methods as required by the electrical code. FAILURE TO FOLLOW THIS WARNING
MAY LEAD TO DEATH, SEVERE INJURY, OR PROPERTY DAMAGE.
• Turn off power and allow to cool before performing any electrical or control work. FAILURE TO FOLLOW THIS
WARNING MAY LEAD TO DEATH, SEVERE INJURY, OR PROPERTY DAMAGE.
• DO NOT make or alter any open holes in the luminaire. Do not modify the luminaire.
• Risk of eye injury! Eye protection is required at all times during the installation, operation, and maintenance of the
luminaire. The high intensity light produced by the luminaire can cause severe damage to the eye if viewed directly
at close range. Avoid being in front of a luminaire that is on or wear suitable light blocking protective eye wear such
as welding goggles. The luminaire should be positioned so that prolonged staring into the luminaire at a distance
closer than 10m is not expected.
• NEVER point the aiming laser at any person or animal as it can cause permanent damage to eyes. Use laser only
for aiming fixtures as directed.
• CAUTION - RISK OF FIRE
• This product is not available for several special environments, such as places with corrosive gas liquids or high
pressure water vapor.
• This luminaire is designed to operate in ambient temperatures ranging from -40 C to 55 C -40℉ to 131℉
WARNING: Changes or modifications to this unit not expressly approved by the party responsible for compliance
could void the user authority to operate the equipment.
NOTES: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
INSTALLATION (Guide 1, Default)
