- Page 1 DAID1050D Impact Drill USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. DESCRIPTION ............................5 2. ITEMS SUPPLIED ............................ 5 3. TECHNICAL DATA ........................... 5 4. SAFETY REGULATIONS ........................5 5. BEFORE STARTING WORK........................6 6. STARTING WORK ........................... 7 7. MAINTENANCE ............................8 8. ORDERING REPLACEMENT PARTS ..................... 8 WARRANTY .............................. -
Page 6: Description
1. DESCRIPTION(FIG.1) 1 Chuck 2 Function Knob 3 L/R Knob 4 Lock-On Button 5 On-off Switch 6 Gear Knob 7 Auxiliary Handle 8 Depth Stop 2. ITEMS SUPPLIED - Impact Drill - Chuck - Chuck Key - Depth stop - Auxiliary handle 3. -
Page 7: Before Starting Work
- Do not use in areas where there are vapours or flammable liquids - Always pull the plug out of the socked before cleaning or making changes to the machine - Protect the power cable from damage. Oil and acid can damage the cable - Never overload the machine - Secure all workpiece sufficiently - Important! It is imperative to follow all national safety regulations concerning installation,... -
Page 8: Starting Work
6. STARTING WORK (FIG.1) 6.1 Switching ON/OFF - Switching on: Press the operating switch (5). - Continuous duty: Lock the switch (5) with the locking button (4). - Switching off: Press the operating switch (5) briefly and let go. 6.2 Handle attachment (Fig-4) For reasons of safety, only use the hammer drill with auxiliary handle(7). -
Page 9: Maintenance
2=HIGH SPEED - lower torque - for drilling small diameters 6.8 Direction of Rotation(Fig. 10) Your impact drill can run in both clockwise and counterclockwise. To set the desired direction by pushing the L/R Knob(3) . - When L/R Knob is not properly set in position, the On-off Switch can not be activated. ! Change direction of rotation only when the tool is at a complete standstill. -
Page 10: Warranty
