- Page 1 DAID SERIES Impact Drill USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
INDEX 1. IMPORTANT SAFETY INFORMATION ....................3 2. SPECIFICATIONS ........................... 5 3. NOTE: SYMBOLOGY ..........................5 4. SETUP ..............................6 5. GENERAL OPERATING INSTRUCTIONS ....................7 6. MAINTENANCE AND SERVICING ......................8 7. EXPLODED VIEW AND SPARE PARTS LIST ..................10 WARRANTY ............................... -
Page 3: Important Safety Information
SAVE THIS MANUAL ! You will need this manual for safety instructions, operating procedures and warranty. Put it and the original sales receipt in a safe dry place for future reference. 1. IMPORTANT SAFETY INFORMATION General Power Tool Safety Warnings WARNING: Read all safety warnings and instructions. - Page 4 17. If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used. Use of these devices can reduce dust-related hazards. 18. Only use safety equipment that has been approved by an appropriate standards agency. Unapproved safety equipment may not provide adequate protection.
-
Page 5: Specifications
2. SPECIFICATIONS DAID550L DAID600L Power: 550 W Power: 600 W No load speed: 0-3000 rpm No load speed: 0-3000 rpm Chuck: 13 mm Chuck: 13 mm Impact rate: 0-48000 bpm Impact rate: 0-48000 bpm Max drill capacity: Max drill capacity: Steel: 13 mm Steel: 13 mm Concrete: 13 mm... -
Page 6: Setup
4. SETUP Before Use Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the beginning of this manual including all text under subheadings therein before set up or use of this product. WARNING: TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION: Release the Trigger, make sure the Trigger lock is not engaged and unplug the tool from its electrical outlet before adjus- ting the tool or installing accessories. -
Page 7: General Operating Instructions
5. GENERAL OPERATING INSTRUCTIONS This tool is designed for drilling into almost any material. For drilling into wood, metal, and plastics, use it in the regular (non-hammer) setting. For drilling holes in stone or concrete, use special masonry drill bits and the hammer setting. Operating the chuck 1. -
Page 8: Maintenance And Servicing
Metal Drilling Tips 1. Use high speed steel, carbide or specialty bits for metal drilling. 2. Secure work piece to keep it from moving during the drilling operation. 3. Use a punch (not included) to create a dimple for the bit to start. 4. - Page 9 2. AFTER USE, wipe external surfaces of the tool with clean cloth. 3. TO CLEAN: The ventilation openings should be kept clean and free of dirt and debris. Wear ANSI-approved safety goggles and NIOSH-ap- proved dust mask/respirator before clea- ning ducts.
-
Page 10: Exploded View And Spare Parts List
7. EXPLODED VIEW AND SPARE PARTS LIST DAID550L DAID600L... - Page 11 Part name Unit Screw M5 × 20 - left Keyless chuck 13mm output shaft Woodruff key 10 × 3 Dust ring Bearing 6001 O-Ring 12 big gear wheel Taper spring Flat pad 8.1 × 12 × 0.5 688 bearing Oil slinger Bracket as-impact 608 bearing Rotor...
- Page 12 DAID750L DAID850L...
- Page 13 Part name Unit Screw M5 × 20 - left Keyless chuck 13mm output shaft Woodruff key 10 × 3 Dust ring Bearing 6001 Circlip 12 for shaft big gear wheel Taper spring Flat pad 8.1 × 12 × 0.5 688 bearing Oil slinger Bracket as-impact 608 bearing...
- Page 14 EC DECLARATION OF CONFORMITY We: YONGKANG LINGWEI ELECTRIC CO.,LTD Jinguquan Industrial Zone, Huajie, YongKang City,Zhejiang P.R. China Declare that the Product detailed below: Impact Drill Models: DAID550L - DAID600L - DAID750L - DAID850L Brand: Satisfies the requirement of the Council Directives: Machinery Directive 2006/42/EC Electromagnetic Compatibility Directive EMC 2014/30/EU Name and address of authorized person to compile the technical file:...
-
Page 15: Warranty
WARRANTY CARD Product model Date of sale Company Serial number Client's signature Username The product is in good conditions and fully complete. Read and agree the terms of the warranty. GUARANTEE The warranty period starts from the date of sale of the products and covers 2 years for all power products. During the warranty period, free failures caused due to the use of poor-quality materials in the production and manufacturer workmanship admitted fault are removed. - Page 16 Manufactured under license of Daewoo International Corporation, Korea...
