Summary of Contents for Daewoo DAED4506
- Page 1 DAED4506 Electric drill USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
- Page 2 INDEX 1. GENERAL SAFETY RULES ........................2 2. SPECIFIC SAFETY RULES ........................3 3. TECHNICAL SPECIFICATIONS ......................3 4. DESCRIPTION ............................4 5. FUNCTIONAL DESCRIPTION ....................... 4 6. OPERATION ............................5 7. MAINTENANCE ............................6 WARRANTY ..............................7...
- Page 3 1. GENERAL SAFETY RULES WARNING: Read and understand all instructions. Failure to follow ali instructions listed below may result in electric shock, tire and/or serious personal injury. SAVE THESE INSTRUCTIONS Work area safety 1. Keep work area clean and well lit. Cluttered and dark areas invite accidents . 2.
- Page 4 power tool accidentally. 18. Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users. 19.
- Page 5 4. DESCRIPTION Keyless Chuck Forward/ Reverse Lock on Button Trigger Switch 5. FUNCTIONAL DESCRIPTION CAUTION: Always be sure that the tool is switched off and unplugged befare adjusting or checking function on the tool. Switch action CAUTION: • Befare plugging in the tool, always check to see that the switch trigger actuates properly and returns to the "OFF"...
- Page 6 lnstalling or removing drill bit Hold the ring and turn the sleeve counterclockwise to open the chuck jaws. Place the bit in the chuck as far as it will go Hold the ring firmly and turn the sleeve clockwise to tighten the chuck. To remove the bit, hold the ring and turn the sleeve counter clockwise.
- Page 7 WARRANTY CARD Product model Date of sale Company Serial number Client's signature Username The product is in good conditions and fully complete. Read and agree the terms of the warranty. GUARANTEE The warranty period starts from the date of sale of the products and covers 1 year for all power products. During the warranty period, free failures caused due to the use of poor-quality materials in the production and manufacturer workmanship admitted fault are removed.
- Page 8 Manufactured under license of Daewoo International Corporation, Korea...
