M2M enginko MCF-LW13IO Operating Manual

Table of Contents
MCF-LW13IO Operating Manual
Important safety information
Read this manual before attempting to install the device! Failure to observe recommendations included in this manual may be dangerous or cause a
violation of the law. The manufacturer will not be held responsible for any loss or damage resulting from not following the instructions of this
operating manual.
Do not dismantle or modify in any way.
Avoid mechanical stress
Do not use any detergent or alcohol to clean the device.
Do not mount in horizontal position.
Disposal information for users
Pursuant to and in accordance with Article 14 of the Directive 2012/19/EU of the European Parliament on waste electrical and electronic
equipment (WEEE).
The barred symbol of the rubbish bin shown on the equipment indicates that, at the end of its useful life, the product must be collected separately from
other waste.
1. Description
The MCF-LW13IO is a LoRaWAN® actuator that allows to switch ON and OFF a 230Vac~, 8A load. It also reads the status of a 230Vac~ input. This device can
transmit the status of its input and control the output through the LoRaWAN® network. It can be used for industrial process control and home automation, water
treatment, agriculture irrigation and similar applications. Input can be used as pulse counter.
2. Overview
2.1 Technical data
CPU Cortex M0+
