Cub Cadet CC-4222V2 Operating Instructions Manual page 12

How to Adjust Brush Height:
1. Place one hand on adjustment lever and use other hand to pull outward on
plunger.
2. Move handle downwards to lower the brush height or upwards to raise the
brush height.
3. Align the plunger with the nearest hole and release to select height setting.
Offset Sweeping:
1. Remove both pins from drawbar.
2. Slide drawbar on hitch cross tube to farthest holes on desired side.
3. Re-pin both pins.
4. Resume normal towing of sweeper.
5. Durring opertion be mindful of wider towpath of sweeper
Periodic Maintenance:
• Tighten fasteners as needed before each use.
• Empty hopper and thoroughly clean Lawn Sweeper after each use.
• Remove any materials that have wrapped around brushes or brush shaft
after each use.
• Lubricate wheel bearings and gears annually with a light coating of white
lithium grease.
Operating Instructions
11
