- Page 1 Santafe installation guide Installation Guide SANTAFE...
- Page 2 Santafe installation guide 1. Head unit 2. GPS Antenna 3. Steering Wheel Remote Control 4. Hands-free Microphone 5. Amp Unit 6. Center speaker 7. Radio antenna 8. Glass antenna...
- Page 3 Santafe installation guide Be sure to disconnect the battery cable before beginning installation. ㅡ 1 Remove one screw (Drive seat) 1. Remove one screw (Drive seat) 2. Carefully pry off lower panel and pull down it. SCREW...
- Page 4 Santafe installation guide From here 3. Carefully pry off crush pad Center garnish from the crush pad. CAUTION CAUTION - Use a protect tape when you use a screwdriver or hand-remover to pry off center garnish. - Check a 7 clips after pry off center garnish. - Use a gloves to protect your hands and parts.
- Page 5 Santafe installation guide 2 SCREW 4. Remove center Speaker with 2 screws.
- Page 6 Santafe installation guide 2 SCREW 5. Remove a A/C control unit. 6. Pry off Center fascia form the crush pad and check a clip of center fascia.
- Page 7 Santafe installation guide 7. Connect the jacks to the head unit 8 Carefully insert a head unit and bolt it to the body 8. Carefully insert a head unit and bolt it to the body.
