The Garden Gym Squat and bench press bracket Installation Manual

NB- Before you start!
Ensure that the pull up bar is solid. You will connect the
brackets to the pull up bar which can create movement in the
foundations. We recommend that you let the pull up bar
concrete harden before starting.
fitted to a 1m pull up bar without an integrated dip station.
Squat and bench press bracket
Installation guide
NB The bracket can ONLY be
General guidance
These instructions are provided as a guide to help you
install your equipment. Depending on the type of ground
conditions it may be necessary to modify the installation.
If you are unsure, please consult a qualified professional
or contact the Garden Gym Team. The installation should
be carried out by 2 people. Before digging you must
ensure that there is no risk of encountering services such
as drains or electricity.
The Garden Gym does not accept any liability in relation
to the installation and subsequent use of the gym
relating to incorrect or improper installation.
You will need
16mm Auger bit and drill, socket set, cloves, ladder, level
