- Page 1 HOT WATER PRESSURE WASHER HW152EA HW205EBA OPERATOR'S MANUAL INDUSTRIAL BE Power Equipment Inc. 85.610.???
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION Introduction & Identification Numbers ....................3 IMPORTANT SAFETY WARNINGS Safety Overview ..........................4 Pressure Washer Cooling System ..................... 8 SET-UP Fuel and Oil Types ..........................9 Unit Overview ..........................10 Assembly............................11 OPERATION Pre-Operation ..........................13 Motor Start/Stop Procedure....................... -
Page 3: Introduction & Identification Numbers
All the information in this manual is based on the latest product information available at the time of printing. BE Power Equipment reserves the right to make changes at any time without notice or incurring any obligation. -
Page 4: Important Safety Warnings
SAFETY OVERVIEW SAVE THESE INSTRUCTIONS - SAFETY RULES This is the safety alert symbol. It is used to alert you to potential personal injury hazards. Obey all safety messages that follow this symbol to avoid possible injury or death. The safety alert symbol ( ) is used with a signal word (DANGER, CAUTION, WARNING), a pictorial and a safety message to alert you to hazards. - Page 5 SAFETY OVERVIEW GENERAL PRESSURE WASHER SAFETY DANGER – High-Pressure Spray • NEVER point the gun at yourself, anyone else, or animals. • The high-pressure water stream can cut through clothing, skin and underlying tissues leading to serious injury. • If this type of injury occurs, DO NOT TREAT AS A SIMPLE CUT. SEEK EMERGENCY MEDICAL ATTENTION IMMEDIATELY.
- Page 6 SAFETY OVERVIEW WARNING – CHEMICAL DETERGENTS/SOAPS • ALWAYS use detergents explicity designed for a pressure washer. • NEVER use any flammable, corrosive or acidic solutions. • NEVER modify the chemical injector system. • ALWAYS flush the system after using a detergent. Run the machine for at least two minutes with clean water to prevent detergent from drying and building up residue.
- Page 7 SAFETY OVERVIEW ELECTRIC PRESSURE WASHER SAFETY DANGER – RISK OF ELECTROCUTION • NEVER spray an electric pressure washer, its cord, or power source. • NEVER leave the machine exposed to rain or the elements. • NEVER modify the plug or cord. •...
-
Page 8: Pressure Washer Cooling System
PRESSURE WASHER COOLING SYSTEM DO NOT OVERHEAT YOUR MACHINE Do not let your machine overheat. Failure to do so will result in damage, void warranty, or cause injury. Electric motors are air-cooled. Always ensure that the machine is operated in a well-ventilated area where it can draw a steady supply of fresh air. -
Page 9: Fuel And Oil Types
FUEL AND OIL TYPES PUMP OIL TYPE For pressure washer pumps, use only SAE 30W non-detergent oil. Never use motor oil in your pressure washer pump because it will damage the seals. Never overfill the pump. • If your pump has a sight glass, then fill halfway up to the middle of the red dot. •... -
Page 10: Unit Overview
UNIT OVERVIEW Image breakdown: HW152EA PRODUCT FEATURES & COMPONENTS American made Adjustable thermostat heavy duty 6,000 PSI Heavy-duty roll-cage powder up to 89°C/193°F with rupture disk coated 1.5" OD steel tube illuminated rocker switch and frame, with centre balanced hour meter lift hook (above industry standards) Heating coil... -
Page 11: Assembly
ASSEMBLY Your pressure washer will require some assembly. If you have any trouble with this process, please call our tech support department (1-866-850-6662) with your model number. Unpack your pressure washer • Remove all the components, including bags and manuals. •... - Page 12 ASSEMBLY HOSE CONNECTIONS • Quick connect fittings: pull back the collar of the coupler, insert plug, and release the collar. Tug on fittings to confirm a secure lock. • Spray Nozzles: To attach a spray nozzle to the end of the wand, pull back on the collar of the brass fitting.
-
Page 13: Pre-Operation
PRE-OPERATION 1. Before operating the pressure washer, ensure you are familiar with all the warnings and safety recommendations. 2. Wear proper clothing and eye protection. 3. Always setup the machine where It is on a level surface. If the machine is not level, it may not start or cause failures. There is sufficient ventilation. -
Page 14: Motor Start/Stop Procedure
START UP PROCEDURE ELECTRIC MOTOR START PROCEDURE 1. Review all the safety warnings at the beginning of the manual. Turn the motor to the off position. 2. Follow all the pre-operation steps before starting. 3. Connect pressure washer to a power source that matches the unit’s requirements. It is critically important to have the pressure washer connected to the correct power source, including volt, amp, phase, and circuit breaker capacity. -
Page 15: Hot Water Start/Stop Procedure
HOT WATER BURNER START/STOP PROCEDURE 1. Fill the black fuel tank with Diesel or Kerosene (No.1 or No.2 grade) 2. Once the motor is running, push the burner toggle switch to the ON position and adjust the thermostat to the desired temperature. CONTROL PANEL TOGGLE SWITCH THERMOSTAT... -
Page 16: Operation
OPERATION GENERAL PRESSURE WASHER OPERATION TECHNIQUES 1. Always follow safety practices as outlined. 2. Always begin spraying at a safe distance from the intended surface and move closer until the desired cleaning effect can be observed. 3. Generally, do not use a 90° spray angle. Instead, it is usually more effective to use a shallower angle so that the reflecting spray can be directed in a safe and controlled direction. -
Page 17: Maintenance
MAINTENANCE PUMP MAINTENANCE PUMP: Change the pump oil after the first 50 hours of operation. After the initial change, every 12 months or 500 hour intervals are recommended. If oil appears dirty or milky, changes may be required in greater frequency. Use SAE 30W non-detergent pump oil and fill only to the center of the oil sight glass. -
Page 18: Maintenance Schedule
MAINTENANCE MAINTENANCE SCHEDULE PROCEDURE DAILY 3 MONTHS 6 MONTHS 9 MONTHS 12 MONTHS Check water pump oil level Change water pump oil Oil leak inspection Fuel leak inspection Water leak inspection Hose inspection Water inlet screen inspection Check diesel fuel filter Replace diesel fuel filter Inspect belts (if applicable) Replace high pressure nozzle... -
Page 19: Pump & Coil Saver Tool
3. We recommend using BE Power Equipment Pump Saver Anti-Freeze. It has a specially designed cap to thread right onto the garden hose fitting of the pump. (Part number 85.490.046, contact your local dealer). -
Page 20: Unit Breakdowns Components Diagram Hw152Ea
DRAWING IS THE SOLE PROPERTY OF Note: Do not scale drawing Weight: Revisions BE POWER EQUIPMENT. Material: Finish: ANY REPRODUCTION IN PART OR AS A Rev. Description Name Date Check Appr. WHOLE WITHOUT THE WRITTEN PERMISSION Initial release OF BE POWER EQUIPMENT IS PROHIBITED. BEPOWEREQUIPMENT.COM... -
Page 21: Parts Reference List Hw152Ea
PARTS REFERENCE LIST MODEL: HW152EA ITEM PART NUMBER DESCRIPTION QTY. 85.202.109 SPRAY GUN 85.202.026 SPRAY WAND 1 & 2 85.205.026 SPRAY GUN AND WAND ASSEMBLY 85.238.251 HOSE, 50' X 3/8" DOUBLE WIRE BRAIDED 72.301.002 TECHTOP 2HP MOTOR 59.400.008 FUEL TANK CAP 85.300.082 PRESSURE SWITCH 85.601.044... -
Page 22: Components Diagram Hw205Eba
Weight: Note: Do not scale drawing Revisions BE POWER EQUIPMENT. Material: Finish: ANY REPRODUCTION IN PART OR AS A Description Name Date Check Appr. WHOLE WITHOUT THE WRITTEN PERMISSION Initial release OF BE POWER EQUIPMENT IS PROHIBITED. Scale: 1:1 BEPOWEREQUIPMENT.COM... -
Page 23: Parts Reference List Hw205Eba
PARTS REFERENCE LIST MODEL: HW205EBA ITEM PART NUMBER DESCRIPTION QTY. 85.202.109 SPRAY GUN 85.202.026 SPRAY WAND 1 & 2 85.205.026 SPRAY GUN AND WAND ASSEMBLY 85.238.251 HOSE, 50’ X 3/8” DOUBLE WIRE BRAIDED 72.301.005 TECHTOP 5HP MOTOR 85.300.083 PRESSURE SWITCH 59.000.123 FUEL TANK CAP 85.601.044... -
Page 24: Troubleshooting
TROUBLESHOOTING SYMPTOM PROBABLE CAUSE REMEDY Motor will not start Various motor problems Refer to the Motor Manual accompanying your unit. Unit components are frozen. Allow to thaw. If any part of the unit becomes frozen; excessive pressure may build up in the unit. This can cause the unit to burst, resulting in possible serious injury to the operator or bystanders. - Page 25 TROUBLESHOOTING SYMPTOM PROBABLE CAUSE REMEDY Blower runs, but Thermostat knob is OFF. Check thermostat knob position. burner will not ignite. Out of fuel. Refuel. Gun trigger is closed/not pressed. Press down on gun trigger. No voltage. Consult Service Department. Fuel pump sucking air. Tighten all fuel intake connections.
-
Page 26: Warranty
OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY IMPLIED WARRANTY OR FITNESS FOR A PARTICULAR PURPOSE. BE Power Equipment does not authorize any of its dealers, service centers, agents, employees or any other party to expand, extend or modify the scope of this warranty in any manner on behalf of BE Power Equipment. - Page 27 NOTES BEPOWEREQUIPMENT.COM...
- Page 28 DO NOT RETURN TO THE STORE FIND YOUR CLOSEST SERVICE CENTRE NE RETOURNEZ PAS AU MAGASIN TROUVEZ VOTRE NO LO DEVUELVA A LA TIENDA CENTRE DE SERVICE LE PLUS PROCHE WE WILL BE GLAD TO ASSIST YOU WITH ANY TECHNICAL ENCUENTRA TU SUPPORT, WARRANTY, OR OTHER QUESTIONS ABOUT CENTRO DE SERVICIO...
