Before operating this product, please read the instructions carefully and save this
manual for future use.
POWER
LIGHT
INPUT
P
COMPONENT
KEYSTONE
Operating Instructions
MENU
ENTER
NORMAL
FREEZE
MODE
MEMORY
ASPECT
USER
VOLUME
MUTE
SD
SD
MENU
TIME
LCD PROJECTOR
Model No.
LCD Projector
PT-L300U
PT-L200U
TQBJ 0120-1
R
Advertisement
Table of Contents
Related Manuals for Panasonic PT-L200U
Summary of Contents for Panasonic PT-L200U
-
Page 1: Lcd Projector
Before operating this product, please read the instructions carefully and save this manual for future use. POWER LIGHT INPUT COMPONENT KEYSTONE Operating Instructions MENU ENTER NORMAL FREEZE MODE MEMORY ASPECT PICTURE USER VOLUME MUTE MENU TIME LCD PROJECTOR Model No. LCD Projector PT-L300U PT-L200U TQBJ 0120-1... -
Page 2: Important Safety Notice
This instruction booklet provides all the necessary operating information that you might require. We hope it will help you to get the most performance out of your new product, and that you will be pleased with your Panasonic LCD projector. - Page 3 Trade Name: Panasonic Responsible party: Matsushita Electric Corporation of America. Address: One Panasonic Way Secaucus New Jersey 07094 Telephone number: 1-800-528-8601 or 1-800-222-0741 Email: pbtsservice@panasonic.com This device complies with Part 15 of the FCC Rules, Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 4: Table Of Contents
Example of connecting to video equipment...18 Example of connecting to equipment compatible with YP Example of connecting to computer ...20 Setting-up ...21 Projection methods...21 Projector position...21 Basic Operation Starting to use...22 Turning on the power...22 Turning off the power...23 On-screen menus...24 Menu screens ...24... -
Page 5: Precautions With Regard To Safety
B Do not attempt to repair the projector yourself, as this can be dangerous. Do not look into the lens while the projector is being used. B Strong light is emitted from the projector’s lens. If you look directly into this light, it can hurt and damage your eyes. - Page 6 Do not place the projector on top of surfaces which are unstable. B If the projector is placed on top of a surface which is sloped or unstable, it may fall down or tip over, and injury or damage could result.
- Page 7 B Doing so may cause the projector to overheat, which can cause fire or damage to the projector. Do not set up the projector in humid or dusty places or in places where the projector may come into contact with smoke or steam.
- Page 8 B If dust is left to build up inside the projector without being cleaned out, it can result in fire or problems with operation. B It is a good idea to clean the inside of the projector before the season for humid weather arrives. Ask your nearest Authorized Service Center to clean the projector when required.
-
Page 9: Accessories
COMPONENT KEYSTONE MENU ENTER NORMAL FREEZE MODE MEMORY ASPECT PICTURE USER VOLUME MUTE MENU TIME LCD PROJECTOR Video/Audio cable [3.0 m (9´10˝), K2KA2FA00001 x1] Power cord (K2CG3FR00001 x 1) AAA batteries for remote control unit (x2) Carrying bag (TPEP008 x1) -
Page 10: Precautions On Handling
If the projector is set up in locations with strong vibration, such as near a motor, or if it is installed inside a vehicle or on board a ship, the projector may be subjected to vibration or shocks which can damage the internal parts and cause malfunctions or accidents. - Page 11 10 hours. About the liquid crystal panel The liquid crystal panel of the projector is built with very high precision technology giving you fine picture details. Occasionally, a few non-active pixels may appear on the screen as a fixed point of blue, green or red.
-
Page 12: Location And Function Of Each Part
Location and function of each part Projector <Top, right and front> # Speaker $ Zoom ring (page 23) % Focus ring (page 23) & Projection lens ' Air inlet ports Do not cover this port. ( Front adjustable legs(L/R) (page 22) - Page 13 Projector <Back and bottom> # Air outlet port Do not cover this port. WARNING Do not bring your hands or other objects close to the air outlet port. B Heated air comes out of the air outlet port. Do not bring your...
- Page 14 <Projector control panel and remote control unit> & B The remote control unit and the projector itself have the same control buttons available. # TEMP indicator (page 51) This indicator illuminates if an abnormally high temperature is detected inside the projector. If...
- Page 15 + KEYSTONE buttons (pages 28 and 29) This button is used to correct keystone distortion of the projected image when the projector position is tilted upward or downward. , NORMAL button (page 27) This button is used to reset the projector adjustment values to the factory default settings.
-
Page 16: Connector Panel
<Connector panel> <PT-L300U> <PT-L200U> # AUDIO L-R input jacks (page 18) $ VIDEO input jack (page 18) This jack is used to input video signals from a video equipment such as a video deck. % S2 VIDEO input connector (page 18 and 30) -
Page 17: Using The Remote Control Unit
B If strong light is allowed to shine onto the remote control signal receiver, correct remote control operation may not be possible. Place the projector as far away from light sources as possible. B If facing the remote control unit... -
Page 18: Connections
Connections Notes on connections B Read the instruction manual for each system component carefully before connecting it. B Turn off the power supply for all components before making any connections. B If the cables necessary for connecting a component to the system are not included with the component or available as an option, you may need to fashion a cable to suit the component concerned. -
Page 19: Example Of Connecting To Equipment Compatible With Yp ) Signals
NOTE: B Refer to page 61 for a list of compatible YP to the projector. B Only one audio system circuit is available for the AUDIO IN L-R jacks, so if you wish to change the audio input source, you will need to remove and insert the appropriate plugs. -
Page 20: Example Of Connecting To Computer
B Only one audio system circuit is available for the AUDIO IN L-R jacks, so if you wish to change the audio input source, you will need to remove and insert the appropriate plugs. B The PT-L200U does not have a DVI-D input (DVI-D IN) connector. Computer To DVI-D... -
Page 21: Setting-Up
Setting-up Projection methods The projector can be set up so that any one of the following four projection methods can be used. Select whichever projection method matches the setting-up method. (The projection method can be set from the OPTION menu. Refer to page 40 for details.) -
Page 22: Starting To Use
$ Connect the accessory power cord. % Press the MAIN POWER switch to the “|” side to turn on the power. The power indicator on the projector will illuminate red. & Press the POWER button. The power indicator on the projector will flash green. -
Page 23: Turning Off The Power
% Wait until the power indicator on the projector illuminates red (until the cooling fan stops). Do not in any way cut power to the projector while the cooling fan is still operating. Be careful not to switch off the MAIN POWER switch of the projector, unplug the power cord from the electrical outlet or turn off in-line switches such as tabletop power switches. -
Page 24: On-Screen Menus
On-screen menus Menu screens The various settings and adjustments for this projector can be carried out by selecting the operations from on-screen menus. The general arrangement of these menus is shown below. MAIN MENU M E N U K E Y S T O N E... - Page 25 X G A S E L E C T A D J * “GAMMA ADJUST” is not displayed by PT-L200U. * “W-BAL R”, “W-BAL G” and “W-BAL B” are not displayed when DVI signal is being input. POSITION menu (page 38)
-
Page 26: Menu Operation Guide
ENTER button. The menu screen for the item will then be displayed. Unavailable on-screen menu items This projector has unadjustable items and unusable functions depending on the signal being input. When an item cannot be adjusted or a function cannot be used, the... -
Page 27: Returning A Setting To The Factory Default
Returning a setting to the factory default If you press the NORMAL button on the remote control unit, you can return settings to the factory default settings. However, the operation of this function varies depending on which screen is being displayed. B When a menu screen is being displayed P I C T U R E... -
Page 28: Correcting Keystone Distortion
Correcting keystone distortion When either the projector or the screen is tilted, the keystone distortion will affect the image. You can correct the image proportions by the following procedure. For PT-L300U Horizontal and vertical keystone distortion can be corrected by following procedures. - Page 29 B Vertical and horizontal keystone distortion can be corrected to ±30° of the angle of tilt by PT-L300U. Vertical keystone distortion can be corrected to ±30° of the angle of tilt by PT-L200U. However, the greater the correction amount, the more the picture quality will deteriorate, and the harder it will become to achieve a good level of focus.
-
Page 30: Setting The Aspect
Keep this in mind when selecting the aspect ratio. B If using this projector in places such as cafes or hotels with the aim of displaying programmes for viewing for a commercial purpose or for public... - Page 31 ASPECT 4:3 Input signal 16:9 Squeezed signal (image contracted horizontally) JUST 4:3 Input signal ZOOM Letter box signal V SCROLL 4:3 Input signal S4:3 4:3 Input signal S16:9 (PT-L300U only) Input signal Horizontal expansion of projected image Horizontal expansion of projected image (Center of image is less distorted) Expansion preserves original ratio...
-
Page 32: Selecting The Picture Mode
Selecting the picture mode You can select the appropriate picture mode for the type of projected image by the following procedure. (The picture mode can be also selected in the PICTURE menu.) # Press the MODE PICTURE button to display the PICTURE menu. P I C T U R E M O D E $ Select an item by pressing the I or H buttons. -
Page 33: Using The Shutter Function
Using the shutter function The shutter function can be used to momentarily turn off the picture and sound from the projector when the projector is not being used for short periods of time, such as during breaks in meetings or when carrying out preparation. -
Page 34: Adjusting The Picture
Adjusting the picture Use the F and G buttons to select an item, and then use the I and H buttons to change the setting for that item. For items with bar scales, press the ENTER button or the I or H buttons to display the adjustment screen, and then use the I or H buttons to make the adjustment. -
Page 35: Tint
C O L O R T E M P . C O L O R T E M P . * “USER” will not be displayed by PT-L200U. This is used to adjust the white areas of the picture if they appear bluish or reddish. -
Page 36: White Balance R/G/B
When adjusting the black or neutral color area of the picture, adjust it using BRIGHT R or BRIGHT B. WHITE BALANCE R/G/B (PC only) This is used to adjust the white areas of the picture if they appear colourised. Press the I button to make the selected color lighter. -
Page 37: Projecting Srgb Compatible Pictures
Projecting sRGB- compatible pictures sRGB is an international color reproduction standard (IEC61966-2- 1) established by the International Electrotechnical Commission (IEC). If you would like the colours in sRGB-compatible pictures to be reproduced more faithfully, make the following settings. # Press the F or G button to select “PICTURE MODE”, and then use the I or H button to select “NATURAL”. -
Page 38: Adjusting The Position
Adjusting the position When the input signal is from a PC, first select AUTO SETUP and then press the ENTER button to initiate automatic positioning. If the optimum setting is not obtained when AUTO SETUP is carried out, adjust by the following procedure. -
Page 39: Aspect
B A C K C O L O R This sets the color which is projected onto the screen when no signal is being input to the projector. This sets the background color for the left/right margins when the 4:3 aspect ratio is selected. -
Page 40: 4:3 H-Pos
This setting should be changed in accordance with the projector setting-up method. Set to “DESK” when setting up the projector on a desk or similar, and set to “CEILING” when suspending the projector from the ceiling using the ceiling bracket which is sold separately. -
Page 41: Sd Memory Card
However, only files in ASF format can be played back. Note when using SD memory cards Do not turn off the projector’s power or remove an SD memory card from the projector while the SD memory card is in use (while the access indicator is flashing). -
Page 42: Inserting And Removing The Sd Memory Card
Insert the SD memory card so that it is facing the correct way. # Open the slot cover at the side of the projector. $ Insert the SD memory card as shown in the illustration below. Insert the SD memory card with... -
Page 43: About The Sd Menu
About the SD menu The still image data and moving image data that is stored on SD memory cards can be played back using the SD menu. Displaying the SD menu Press the SD button to change the display to the SD CARD screen. PICTURE SLIDE SHOW VIDEO... -
Page 44: Playing Back Still Images
Playing back still images The PICTURE option lets you play back still image data. # Use the F and G buttons to select “PICTURE”, and then press the ENTER button. PICTURE SLIDE SHOW VIDEO B If there is no still image data that can be played back, the following screen is not displayed. -
Page 45: Slide Playback Of Still Images
Slide playback of still images “SLIDE SHOW” lets you play back still images in a certain order using one of three available playback methods. Use the F and G buttons to select an item, and then press the ENTER button. Use the I and H buttons to change the setting for the selected item. - Page 46 H button to 1/11 play back the previous still image. NOTE: B When editing the user settings, slide playback settings that have not been created using this projector cannot be edited. SETTING2 REPEAT INTERVAL...
- Page 47 Editing user settings You can use the user setting edit screen that is displayed when you select “SETTING” during slide playback on the previous page to add, move and delete still images from the list of images for slide playback and also to change playback settings.
- Page 48 SETUP This describes how to set the playback interval and angle of rotation for still images in the user settings. # Use the F, G, I and H buttons to select a still image from the user settings, and then press the ENTER button. $ Select “SETTING”...
-
Page 49: Playing Back Moving Images
(frame dropout) or they may appear as mosaic patterns, but this is normal. B If the projector has been used to enlarge the images, some movie data may appear lower in resolution, but this is normal. -
Page 50: Error Displays
SD MENU button, turn off the projector’s power while referring to “Turning off the power” on page 23, and then turn the power back on again. -
Page 51: Indicators
problem. - Page 52 Problem unit. B Does “REPLACE LAMP” appear on Possible the screen after cause the projector is turned on? B This occurs when the operation time for the lamp unit is nearing 1800 hours. (when LAMP POWER has been set to Remedy “HIGH”) Ask your...
-
Page 53: Cleaning And Replacing The Air Filter
Cleaning and replacing the air filter If the air filter becomes clogged with dust, the internal temperature of the projector will rise, the TEMP indicator will flash and the projector power will turn off. The air filter should be cleaned every 100 hours of use, depending on the location where the projector is being used. -
Page 54: Replacing The Lamp Unit
Make sure that your hands are not slippery when using the screwdriver. NOTE: B The projector is not supplied with a replacement lamp unit. Please ask your dealer for details. Lamp unit product no.: ET-LAE100 CAUTION:... -
Page 55: Lamp Unit Replacement Procedure
NOTE: B If the lamp usage time has passed 2000 hours (when LAMP POWER has been set to “HIGH”), the projector will switch to standby mode after approximately 10 minutes of operation. The steps * to - on the next page should thus be completed within 10 minutes. -
Page 56: Turn Off The Power
MAIN POWER switch. NOTE: B If the POWER button on the projector does not illuminate red when the MAIN POWER switch is turned on, turn the MAIN POWER switch off again and check that the lamp unit and the lamp unit cover are securely installed. -
Page 57: Before Calling For Service
B The lens cover may still be attached to the lens. fuzzy. B The lens focus may not have been set correctly. B The projector may not be at the correct distance B The lens may be dirty. B The projector may be tilted too much. (Refer to COLOR is too light or B COLOR or TINT adjustment may be incorrect. - Page 58 (Refer to page 35.) B There may be a problem with the video tape or other signal source. B A signal which is not compatible with the projector may be being input. (Refer to page 61.) B The cable may be too long.
-
Page 59: Specifications
Power supply: Power consumption: Amps: LCD panel: Panel size (diagonal): Aspect ratio: Display method: Drive method: Pixels: PT-L300U: PT-L200U: Lens: Lamp: Luminosity: PT-L300U: PT-L200U: Scanning frequency: Horizontal scanning frequency: 30 kHz–70 kHz Vertical scanning frequency: 50 Hz–87 Hz Dot clock frequency:... - Page 60 COMPONENT IN: DVI-D IN (PT-L300U only): AUDIO IN: SD memory card slot: Cabinet: Dimensions: Width: Height: Length: PT-L300U PT-L200U Weight: Operating environment: Temperature: Humidity: Certifications: <Remote control unit> Power supply: Operating range: Weight: Dimensions: Width: Height: Length: <Options> Ceiling bracket Projection Screen *Specifications are subject to change without notice.
-
Page 61: Appendix
Appendix List of compatible signals Display Mode resolution (dots)* NTSC/M-NTSC/PAL-M/PAL60 720 x 480i PAL/PAL-N/SECAM 720 x 576i 525i 720 x 480i 625i 720 x 576i 525p 720 x 483 HDTV60 1 920 x 1 080i HDTV50 1 920 x 1 080i 750P 1 280 x 720 VGA400... -
Page 62: Connector Pin Wiring
Connector pin wiring B The pin layout and signal names for the S2 VIDEO input connector are shown below. & External view B The pin layout and signal names for the RGB input connector are shown below. External view Pin No. Earth (Luminance signal) Earth (Color signal) Luminance signal... -
Page 63: Projection Dimensions Calculation Methods
B The pin assignments on the DVI-D input connector are as follows (interface with TMDS connector on a personal computer) Pin No. Signal T.M.D.S data 2- T T.M.D.S data 2+ T.M.D.S data 2/4 shield & T.M.D.S data 4- T.M.D.S data 4+ DDC clock DDC data T.M.D.S data 1-... -
Page 64: Dcf Standard
DCF standard This projector can only play back image files which comply with the DCF specification. The DCF specification imposes the following conditions. Image files or folders which do not conform to these conditions cannot be recognised by the projector. -
Page 65: Dimensions
Dimensions 65.4(2 9/16) 280(11) Trademark acknowledgements B The SD logo is a trademark. B VGA and XGA are trademarks of International Business Machines Corporation. B Macintosh is a registered trademark of Apple Computer, Inc. B S-VGA is a registered trademark of the Video Electronics Standards Association. - Page 66 NOTES IMPORTANTES CONCERNANT LA SÉCURITÉ AVERTISSEMENT: POUR REDUIRE LES RISQUES DE FEU OU DE CHOC ÉLECTRIQUE, NE PAS EXPOSER CE PRODUIT À L’EAU OU À L’HUMIDITÉ Alimentation: Ce projecteur LCD est conçu pour fonctionner sur secteur de 100 V - 240 V, 50 Hz/60 Hz seulement. ATTENTION: Le cordon d’alimentation secteur fourni avec le projecteur peut être utilisé...
