Wired Controller Wiring Instruction
Communication Wiring
Communication wiring length (m/ft)
< 100m/328ft
≥100m/328ft  and  <200m/656ft
≥200m/656ft  and  <300m/984ft 
≥300m/984ft    and  <400m/1312ft
≥400m/1312ft  and  <500m/1640ft
*Ground only one end of the shielded cable
Wiring Diagrams
C
B
A
0 .3mm
x3-core shielded wire
2
(22AWG,3wire)
0 .5mm
x3-core shielded wire
2
(20AWG,3wire)
0 .75mm
x3-core shielded
2
wire (18AWG,3wire)
1 .25mm
x3-core shielded wire
2
(16AWG,3wire)
2mm
x3-core shielded wire
2
(14AWG,3wire)
18
Wire Size
red
yellow
white
