APW Wyott XTRM-1 Owner's Manual

Radiant conveyor toaster
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WARNING: California Residents Only. This product can expose you to chemicals
including chromium which is known to the State of California to cause cancer
and birth defects or other reproductive harm. For more information go to www.
P65Warnings.ca.gov.
FOR YOUR SAFETY: Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
WARNING: Improper installation, operation, service or maintenance can cause
property damage, injury or death. Read and understand these instructions
thoroughly before positioning, installing, maintaining or servicing this equipment.
Initial heating of appliance may generate smoke or fumes and must be done in a well ventilated area.
Overexposure to smoke or fumes may cause nausea or dizziness.
APW Wyott
cooking equipment has been engineered to provide you with year-round dependable service
®
when used according to the instructions in this manual and standard commercial kitchen practices.
This manual includes material related to installation, use , cleaning, and care. Exploded view[s], as well as any
available parts list[s] and wiring diagram[s] pertaining to the unit[s] covered by this manual are also included.
This manual must be read and understood by all persons using or installing this appliance. Contact your APW Wyott
dealer if you have any questions concerning installation, use, or maintenance of this equipment.
DO NOT DISCARD THIS MANUAL.
is a registered trademark of APW Wyott®, A Middleby Company. All rights reserved.
DESIGNED SMART. BUILT SOLID.
RADIANT CONVEYOR TOASTER
OWNERS MANUAL
APW Wyott Food Service Equipment Company
265 Hobson St. • Smithville, TN 37166
(800) 527-2100 • apwwyott.com
®
MODELS:
XTRM-1
2M-93100174 REV B (01-23)
