DT-2200 A versatile digital receiver with a guaranteed future One of the advantages with DT-2200 is the flexible design. The receiver is equipped with a Common Interface and a card reader (embedded), for adding an access-system. This may for example be Viaccess, Conax, Cryptoworks or Irdeto. Another appreciated function is VBI-text, which allows text TV to be sent over the building net automatically. -
Page 3: Front
6. Data COM1 for upgrading software (PC). 7 . Audio jack right/left (RCA) 8. SVHS jack 9. Video out (1+2) 10. Transport current output Parallel LVDS 11. LNB in 13/18V DC, 350mA, 22kHz 12. IF out Used for future functions (optional) 01042-4 DT-2200 ENG-1.p65 2001-09-26, 08:46... -
Page 4: Smart Card
Insert the module with the programme card into the front of DT-2200 in the DVB/CI socket. In most cases, one side of the module is marked and this side should face the marking for the DVB/CI socket on the DT-2200. -
Page 5: Programming Unit
MENU - save and move to the next menu option. ENTER Self test One of the features of the DT-2200 is the self test. When SelfTest it’s started various parts will be tested and the results will be CA (Cimax) at 0x80 Pass shown on the TV screen. -
Page 6: Menu Information
03 = QPSK lock – when the receiver find and lock the signal. 04 = Video stop – if the program card have no access or the video signal is lost. 05 = Audio stop – if the audio disappeares for any reasons. 01042-4 DT-2200 ENG-1.p65 2001-09-26, 08:46... -
Page 7: Menu Overview
- use this button to activate the menu. De-activate the Info menu. MENU - save and move to the next menu option. NEXT - video PID VPID - audio PID APID - program clock reference PID PCRPID - text-TV PID TextPID 01042-4 DT-2200 ENG-1.p65 2001-09-26, 08:46... - Page 8 MANUAL DT-2200 Programmering All programming is done using the Menu-Enter-Up-Down-Left-Right buttons and the DT-2200 display. TRANSPONDER FREQUENCY “IF FREQUENCY” Press the Menu button. MENU ENTER TRANS FREQ 1559 Use the Up/Down buttons to specify a number. Use the Left/Right buttons to move between the numbers.
-
Page 9: Programming
Press the Enter button to save and move on to the next menu ENTER option. 16/9 ”TV-format” Use the Up/Down buttons to select the 16/9 format. Off= 4/3 16/9 format. Press the Enter button to save and move on to the next menu ENTER option. 01042-4 DT-2200 ENG-1.p65 2001-09-26, 08:46... - Page 10 Important a required channel. CHANGING CHANNEL Switching to another channel within the transponder is simply done by using the buttons and the display on the front panel of the DT-2200. Press the Left button. DISCOVERY (VIDEO) Use the Up/Down buttons to select a channel.
-
Page 11: Information "Menu
MANUAL DT-2200 Information All information is controlled from the display to DT-2200, except CI information, which is displayed on the TV screen. BER “Bit Error Rate” Press the Right button for more information on BER. GOOD EB/NO 10DB Indicates that the signal quality is adequate. - Page 12 0% transparency to 100%. (Deault 50%). Press the Right button six times. SUBTITLE Transp. Use the Up/Down button to select the required transparency. Press the Right button to move to the next step on the menu. 01042-4 DT-2200 ENG-1.p65 2001-09-26, 08:46...
-
Page 13: Pid Setting
Start Trans Scan menu appears. ENTER SCAN Select NO for PID setting. See page 58. Use the Left/Right and Up/Down buttons to set the required PID. Press the Enter button to start the channel search. ENTER 01042-4 DT-2200 ENG-1.p65 2001-09-26, 08:46... -
Page 14: Technical Data
1 Vp-p, (Units may be stacked) BNC female 75Ω Width 19" rack Height 1 rack unit (1HE) TELETEXT TRANSCODER PAL Temperature –10 to +45 Working Reinserted in PAL, VBI –20 to +70 Storage CCIR system B 01042-4 DT-2200 ENG-1.p65 2001-09-26, 08:46... -
Page 15: Connectors
(RS232) (IN) (OUT) F-contact (female) F-contact (female) 2. RX 3. TX 4. GND 9 pin D-sub (hane) Alarm ALARM CONTACT When alarm Center pin=GND occurs: Alarm 0=0 volt A=0V Max. 15mA 1=3,3 volt B=3,3V Operation 01042-4 DT-2200 ENG-1.p65 2001-09-26, 08:46... - Page 16 Art.nr: 92700 macab ab (publ) vannhögsgatan 7, se-231 66 trelleborg. tel: 0410 36 36 00 fax: 0410 36 36 01. e-post: info@macab.se – www.macab.com 01042-4 DT-2200 ENG-1.p65 2001-09-26, 08:46...
