Elecom UCAM-E1C10 Series Setup Manual page 4

Installing in Windows 2000
1.
Load the Install Disk into the CD-ROM
drive.
2. Click on " ファイル名を指定して実行 ..."
in the Start menu and, when the 「ファイル
名を指定して実行」window appears, type
"D:¥setup.exe" into the text box and click
on the
"D" is the CD-ROM drive of your PC.
Normally, it is the D drive.
3.
Click on the
4. Select "完全" and then click on the
button.
4
button.
button.
5.
Click on the
Installation will begin.
6.
Click on the
7.
Peel off the sticker from the USB connec-
tor of the PC camera.
8.
Plug the USB connector of the PC cam-
era into a USB port of the PC.
The PC camera may be connected
and disconnected while power to the
PC is ON.
Do not try plugging the USB connector
in upside-down.
button.
button.
Though this PC camera consumes a
maximum 100 mA of power, because
of specifications, connect it to a USB
port that supplies 500 mA.
