UCAM-N1D30
UCAM-N1D30
SETUP GUIDE
SETUP GUIDE
* The names of products or companies appearing in this guide are the trademarks or registered trademarks of their respective owners. Symbols ® and ™ are omitted from names in this text.
Series
Series
Package Check.........................................................................2
Precautions in Handling............................................................2
Precautions in Use ...................................................................2
Operating Environment.............................................................3
Names of Parts.........................................................................3
Checking Your Windows Version...............................................4
Installing the Driver Utility .........................................................5
Checking Driver Utility Installation ............................................8
Uninstalling the Driver Utility.....................................................9
Image Setup
Image Setup ...........................................................................10
If the Webcam Does Not Work ...............................................11
For Inquiries About this Product .............................................11
Specifications .........................................................................12
Advertisement
Table of Contents
Related Manuals for Elecom UCAM-N1D30 Series
Summary of Contents for Elecom UCAM-N1D30 Series
-
Page 1: Table Of Contents
UCAM-N1D30 UCAM-N1D30 Series Series SETUP GUIDE SETUP GUIDE Before Use Package Check.................2 Precautions in Handling............2 Precautions in Use ..............2 Operating Environment.............3 Names of Parts.................3 Webcam Installation and Setup Checking Your Windows Version..........4 Installing the Driver Utility ............5 Checking Driver Utility Installation ..........8 Uninstalling the Driver Utility.............9 Image Setup Image Setup ................10... -
Page 2: Before Use
Use a commercially available lens blower brush carefully packaged, if something is missing, con- or tissues to remove dust. tact the place of purchase or ELECOM’s Custom- • The webcam is designed to receive power over er Service Center to obtain what is needed. -
Page 3: Operating Environment
Operating Environment CPU......1 GHz or faster Intel Pentium III OS ......Windows XP or later, Windows 2000 SP4 or later ® ® Mac OS not supported. Memory ....256 MB or more HDD......260 MB or more Graphic memory ..32 MB or more DirectX.....9.0 or later USB 2.0 port (Must supply 5V, 500 mA of power.) Broadband connection such as ADSL, etc. -
Page 4: Webcam Installation And Setup
Webcam Installation and Setup This section explains how to install the included Driver Utility and connect the webcam.The webcam can be used with Adobe Photoshop and Microsoft Imaging, as well as operated as a TWAIN device. When ® used with these image processing applications, VGA size still pictures can be taken. Checking Your Windows Version For Windows XP To use this webcam with Windows XP , you re-... -
Page 5: Installing The Driver Utility
Installing the Driver Utility in Windows XP Load the included CD-ROM into the CD- ROM drive of your PC. Select「マイコンピュータ」from the Start menu. Check the version here. This example shows Service Pack 4. Installing the Driver Utility This section explains how to install the Driver Util- Double-click on the CD-ROM drive where ity and connect the webcam to your PC.The Driv- you loaded the CD-ROM in Step 1. - Page 6 Click on the button. Click on the button. Installation begins. Click on the button. Peel the sticker off the USB connector of the webcam. Plug the USB connector of the webcam into a USB port of the PC that supports USB 2.0. The New Hardware Detection Wizard ap- pears.
- Page 7 Installing the Driver Utility in Windows 2000 Select「はい、今すぐコンピュータを再起 Load the included CD-ROM into the CD- 動します。」and click on the ROM drive of your PC. button. The PC restarts. Double-click on「マイコンピュータ」on the desktop. Peel the sticker off the USB connector of the webcam.
-
Page 8: Checking Driver Utility Installation
Click on the Devices menu and check that Checking Driver Utility Installation a checkmark appears next to "UCAM- This section explains how to check whether the N1D30 Series". Driver Utility was installed correctly or not. If it does not, click on "UCAM-N1D30 Series"... -
Page 9: Uninstalling The Driver Utility
Utility. Follow this procedure to uninstall the Driv- er Utility when no longer necessary or for oth- er reasons. If using Windows XP, select「すべてのプ ログラム」>> "UCAM-N1D30 Series" >> "Uninstall", from the Start menu. If using Windows 2000, select「プロ グラム」>> "UCAM-N1D30 Series" >>... -
Page 10: Image Setup
Image Setup 「カスタムプロパティページ」(Custom Prop- The webcam setup windows can be called from video capture software and video chat software. erties Page) tab These setup windows enable you to adjust white balance, etc. Settings are made from the two tabs on the Prop- erties window. -
Page 11: Appendix
Appendix If the Webcam Does Not Work For Inquiries About this Product Check the version of your OS. ELECOM Customer Service Center TEL : 0570-084-465 This webcam runs only on Service Pack 4 and FAX : 0570-050-012 later versions of Windows 2000 and Service Pack [Business Hours] 9:00 - 12:00 13:00 - 18:00 1 and later versions of Windows XP . -
Page 12: Specifications
Specifications Webcam Image receiving element 1/4" CCD sensor Max. resolution 640 x 480 pixel Max. frame rate 30 fps (Same for VGA, QVGA and CIF) Colors 16.77 million (24-bit) Max. current consumption 14 mA while on standby, 104 mA while running Interface USB 2.0 dedicated (Does not support USB 1.1) External dimensions... - Page 13 -MEMO-...
- Page 14 -MEMO-...
- Page 15 USB Connection PC Camera Setup Guide UCAM-N1D30 Series Published by … ELECOM Corporation 1st Edition … February 18, 2005 C06001 C6-WU-1 © 2005 ELECOM Corporation. All rights reserved.
- Page 16 USB Connection PC Camera Setup Guide...
