Thank you very much for purchasing this product.
* "UCAM-CX80FBBK" is referred to as "this product" in many parts of this manual.
Precautions
This manual describes the necessary precautions you should take for safe operation of this
product.
Observe these precautions carefully to avoid personal injury, damage, fire, and other problems.
Meaning of symbols
Warning
Failure to observe precautions carries the possibility of serious personal injury or death due to
fire, electric shock, or other causes.
Caution
Failure to observe precautions may result in personal injury due to electric shock or other
causes, and may damage other equipment.
Web camera
UCAM-CX80FBBK
User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the UCAM-CX80FBBK and is the answer not in the manual?

Questions and answers

Related Manuals for Elecom UCAM-CX80FBBK

Summary of Contents for Elecom UCAM-CX80FBBK

  • Page 1 UCAM-CX80FBBK User Manual Thank you very much for purchasing this product. * “UCAM-CX80FBBK” is referred to as “this product” in many parts of this manual. Precautions This manual describes the necessary precautions you should take for safe operation of this product.
  • Page 2 Prohibited action Mandatory action Situation that needs attention Notes and reference information Warning If a foreign object (water, metal chips) enters this product, stop using immediately and remove it from your PC. If used as is, it may cause a fire or electric shock. If there are abnormalities, such as when this product is deformed due to heat generation, generating smoke, or giving off...

  • Page 3: Before Using

    This product does not have a waterproof structure. Use or store in a place that is not exposed to liquids such as water. Rain, water spray, juice, coffee, steam, sweat and other liquids may cause a breakdown. Do not use this product with any device that may significantly be affected in the case of this product malfunctioning.

  • Page 4: How To Use

    software. Depending on your hardwareʼs processing capabilities, sound quality and video processing may not perform well. Due to the nature of this product and depending on your computer, your computer may stop recognising this product when it enters standby, hibernation or sleep mode. When in use, cancel settings for standby, hibernation or sleep mode.
  • Page 5 One web camera One USB Type-C™ to Type-C cable for connection One USB Type-C to Type-A cable for connection One privacy shutter Name and function of each part ① Camera lens Captures images. ② LED The LED will turn red when the camera is connected to your PC. The LED will turn green during capture.
  • Page 6 Connecting and setting up the camera Attach the privacy shutter Attach the privacy shutter to the lens portion of this product. You can use this product without removing the privacy shutter. * This manual shows illustrations of the camera without a privacy shutter. However, the operations are the same with or without one.
  • Page 7 The following are the restrictions when the USB Type-C to Type A cable is used to connect to your PC's USB A port. The image resolution is restricted to 1920×1080 pixels. The maximum frame rate is restricted to 30FPS. HDR function is unavailable. You are recommended to use USB Type-C connection if your PC has a USB Type-C port.
  • Page 8 Tripods with 1/4 inch (M6×1) screws can be used with this product. Tripods with screws more than 5mm(0.2'') long cannot be attached to this product. Please take note that forcing the screw in may damage the tripod socket. 5mm(0.2'') and below Connect to a PC 1) Start up your PC.
  • Page 9 Using with USB Type-A port Ensure that the connector is correctly oriented to the port. USB Type-C connector can be inserted regardless of orientation. If there is strong resistance when inserting, check the shape and orientation of the connector. Forcibly inserting the connector may damage the connector, and there is a risk of injury.
  • Page 10 You can adjust image quality and various functions of this product by installing the UCAM- CX80FB setup software. ■Get the UCAM-CX80FB settings software Access ELECOMʼs website as shown below and download the latest version of the application. here > Click for the download page.
  • Page 11 4) Select “English” from the drop-down menu and click on “OK”. 5) Click on “Next”.
  • Page 12 6) Click on “Next”. * Tick “Donʼt create a Start Menu folder” so that the software is not registered to your Start Menu. 7) Click on “Next”.
  • Page 13 * An icon will be created on your desktop if “Create a desktop shortcut” is ticked. 8) Click on “Install”. 9) Click on “Finish”.
  • Page 14 ■Set up using the UCAM-CX80FB settings software 1) Run the software with the camera connected to your PC. Click “ELECOM” then “UCAM-CX80FB” in order from the start menu. The UCAM-CX80FB settings software will start running. The following message will appear if the camera is not connected to your PC.
  • Page 15 Show the Settings frame. Show the Information frame. ② Frame Change various settings and display information on the settings software. You can scroll down in the settings frame. ③ Preview Preview camera images. ■Description of each type of setting ePTZ Drag the digital zoom bar to adjust the camera range.
  • Page 16 Exposure Enable or disable automatic exposure. The following manual sliders for settings will appear if Exposure is disabled. “Gain” Adjust the image gain (brightness). (0dB to 6dB) “Exposure time” Adjust the camera exposure time. (-1 to -8) White Balance Enable or disable automatic white balance. The following sliders will appear if this is disabled.
  • Page 17 Enabling gamma settings will disable backlight compensation. To enable, click “Enable” on the confirmation page. Backlight Compensation Enable or disable backlight compensation. Enabling this allows the camera to automatically adjust for natural color when the backlight is strong. Gamma settings will be reset to default if backlight compensationn is enabled. To enable, click “Enable”...
  • Page 18 one video frame. Enabling this reduces overexposure or underexposure even in large venues with high lighting contrast and allows you to take images of people in natural color. To enable HDR, this product must be connected to your PCʼs USB Type-C port. The following message will be displayed if it is connected via a USB-A port.
  • Page 19 Auto Frame Enable or disable automatic zoom (function to automatically adjust camera range by detecting people). The following sliders will appear if this is enabled. “Sensitivity” Set up the amount of time taken before the camera range is adjusted following detection of movement of people or changes in the number of people within the field of view.
  • Page 20 You can adjust image quality and various functions of this product by installing the UCAM- CX80FB setup software. ■Get the UCAM-CX80FB settings software Access ELECOMʼs website as shown below and download the latest version of the application. here > Click for the download page.
  • Page 21 The installation of the UCAM-CX80FB settings software is now complete. ■Set up using the UCAM-CX80FB settings software 1) Run the software with the camera connected to your PC. Click the “UCAM-CX80FB” icon in the “Applications” folder. The UCAM-CX80FB settings software will start running. The following message will appear if the camera is not connected to your PC.
  • Page 22 ① Frame operations icon Control the operations of frames. Switch between showing and hiding frames. Show the Settings frame. Show the Information frame. ② Frame Change various settings and display information on the settings software. You can scroll down in the settings frame. ③...
  • Page 23 Changing the shooting range manually while the auto frame is enabled will disable it. To enable, click “Enable” on the confirmation page. Exposure Enable or disable automatic exposure. The following manual sliders for settings will appear if automatic exposure is disabled. “Gain”...
  • Page 24 Image Adjustment Drag each slider to adjust the image quality. “Brightness” Adjust the brightness of the image. (0 to 200) “Contrast” Adjust the contrast of the image. (0 to 200) “Hue” Adjust the hue of the image. (0 to 180) “Saturation”...
  • Page 25 Enabling this allows the camera to automatically adjust for natural color when the backlight is strong. Gamma settings will be reset to default if backlight compensation is enabled. To enable, click “Enable” on the confirmation page. Enable or disable HDR. Multiple images with different exposure time are taken and composited in real time to create one video frame.
  • Page 26 Anti-flicker To reduce flicker caused when shooting under fluorescent lighting, select 50Hz or 60Hz to match the regional electrical frequency where this product is used. Auto Zoom Enable or disable automatic zoom (function to automatically adjust camera range by detecting people). The following sliders will appear if this is enabled.
  • Page 27 Tracking Active Speakers Enable or disable Tracking Active Speakers. Enabling this allows the device to recognise the speaker using AI technology and highlight the speaker with the “Voice animation”. Speaker detection can only be performed using the microphone built into this product. Using chat software and online meeting services (Windows) * The screen and operation may change with each software version.
  • Page 28 3) Click on “Settings”. 4) Click on “Audio&Video”. 5) Select the camera from “Camera” under “VIDEO”.
  • Page 29 If the camera preview appears, it is operating correctly. If multiple cameras are connected, select “ELECOM 4K Webcam”. 6) Select the audio device from “Microphone” under “AUDIO”.
  • Page 30 Select “Microphone (Webcam Internal Mic)” if using the built-in microphone. You can now use this product with Skype. Microsoft Teams The description below uses images from “Microsoft Teams v.1.4.00.22472”. 1) Check that the camera is connected to your PC before starting up Microsoft Teams.
  • Page 31 3) Click on “Settings”. 4) Click on “Devices”. 5) Select the camera from “Camera”.
  • Page 32 If the camera preview appears, it is operating correctly. If multiple cameras are connected, select “ELECOM 4K Webcam”. 6) Select the audio device from “Microphone”. Select “Microphone (Webcam Internal Mic)” if using the built-in microphone. You can now use this product with Microsoft Teams.
  • Page 33 Zoom The description below uses images from “Zoom v.5.7.7” 1) Check that the camera is connected to your PC before starting up Zoom. 2) Click on the “Settings” icon. The “Settings” page will appear. 3) Click on “Video”. 4) Select the camera from “Camera”.
  • Page 34 If the camera preview appears, it is operating correctly. If multiple cameras are connected, select “ELECOM 4K Webcam”. 5) Click on “Audio”. 6) Select the audio device from “Microphone”.
  • Page 35 Select “Microphone (Webcam Internal Mic)” if using the built-in microphone. You can now use this product with Zoom. Cisco Webex Meetings The description below uses images from “Cisco Webex Meetings v.41.9.3.16”. 1) Check that the camera is connected to your PC before starting up Cisco Webex Meetings.
  • Page 36 4) Select the camera to be used. If the camera preview appears, it is operating correctly. If multiple cameras are connected, select “ELECOM 4K Webcam”. 5) Click on the ▼ on the right of “Audio Option”.
  • Page 37 6) Select the audio device from “Microphone”. Select “Microphone (Webcam Internal Mic)” if using the built-in microphone. You can now use this product with Cisco Webex Meetings. Google Meet 1) Check that the camera is connected to your PC. Access Google Meet on your web browser and log in.
  • Page 38 3) Click on “movie” and select the camera to be used from “Camera”. If the camera footage appears, it is operating correctly. If multiple cameras are connected, select “ELECOM 4K Webcam”. 4) Click on “audio” and select the audio device from “Microphone”.
  • Page 39 Select “Microphone (Webcam Internal Mic)” if using the built-in microphone. You can now use this product with Google Meet. Using chat software and online meeting services (Mac) * The screen and operation may change with each software version. In such circumstances, please refer to the software's help or the manual.
  • Page 40 3) Click on “Settings”. 4) Click on “Audio&Video”. 5) Select the camera from “Camera” under “VIDEO”.
  • Page 41 If the camera preview appears, it is operating correctly. If multiple cameras are connected, select “UCAM-CX80FB”. 6) Select the audio device from “Microphone” under “AUDIO”.
  • Page 42 Select “Webcam Internal Mic” if using the built-in microphone. You can now use this product with Skype for Mac. Microsoft Teams The description below uses images from “Microsoft Teams v.1.4.00.22265”. 1) Check that the camera is connected to your PC before starting up Microsoft Teams.
  • Page 43 3) Click on “Settings”. 4) Click on “Devices”. 5) Select the camera from “Camera”.
  • Page 44 If the camera preview appears, it is operating correctly. If multiple cameras are connected, select “UCAM-CX80FB”. 6) Select the audio device from “Microphone”.
  • Page 45 Select “Webcam Internal Mic” if using the built-in microphone. You can now use this product with Microsoft Teams. Zoom The description below uses images from “Zoom v.5.7.5”. 1) Check that the camera is connected to your PC before starting up Zoom. 2) Click on the “Settings”...
  • Page 46 The “Settings” page will appear. 3) Click on “Video”. 4) Select the camera from “Camera”. If the camera preview appears, it is operating correctly. If multiple cameras are connected, select “UCAM-CX80FB”.
  • Page 47 5) Click on “Audio”. 6) Select the audio device from “Microphone”. Select “Webcam Internal Mic” if using the built-in microphone. You can now use this product with Zoom. Cisco Webex Meetings The following explanation uses images from “Cisco Webex Meetings v.41.9.0.19961”. 1) Check that the camera is connected to your PC before starting up Cisco Webex Meetings.
  • Page 48 3) Click on the ▼ on the right of “Video Option”. 4) Select the camera to be used. If the camera preview appears, it is operating correctly. If multiple cameras are connected, select “UCAM-CX80FB”.
  • Page 49 5) Click on the ▼ on the right of “Audio Option”. 6) Select the audio device from “Microphone”. Select “Webcam Internal Mic” if using the built-in microphone. You can now use this product with Cisco Webex Meetings. Google Meet 1) Check that the camera is connected to your PC. Access Google Meet on your web browser and log in.
  • Page 50 3) Click on “Video” and select the camera to be used from “Camera”. If the camera footage appears, it is operating correctly. If multiple cameras are connected, select “UCAM-CX80FB”. 4) Click on “Audio” and select the audio device from “Microphone”.

  • Page 51: Specifications

    Select “Webcam Internal Mic” if using the built-in microphone. You can now use this product with Google Meet. Specifications Compatible models USB3.0 interface-equipped Windows OS and/or macOS devices Supported OS Windows 10, Windows 8.1, macOS 11.4 BigSur Remarks on supported OS * You may be required to update or install a service pack with each new OS version.
  • Page 52 Effective pixel count Approx. 8.3 megapixels Number of colors Approx. 16.7 million colors (24bit) Still image (recorded pixels) Maximum 33.2 megapixels (depends on software used) Video (recorded pixels) Max 3840×2160 pixels Max frame rate 60FPS (~1920×1080 pixels) 30FPS (~3840×2160 pixels) * Resolution is restricted to 30FPS when connected to your PC using USB-A.

  • Page 53: Intellectual Property Rights

    conditions 90% RH (without condensation) Storage environment Temperature -10°C to +60°C / 140°F to 104°F; humidity: up conditions to 90% RH (without condensation) Compliance status Model/모델명/设备型号/型號: UCAM-CX80FB China / 中国 Korea / 대한민국 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

  • Page 54: Support Information

    ELECOM CO., LTD. owns the copyright to this manual. All products and company names on this product and the package are trademarks or registered trademarks of their respective owners. Duplicating and transferring this document in part or whole is prohibited.
  • Page 55 Specifications and external appearance of this product may be changed without prior notice for the purpose of product improvement. ELECOM is not responsible for any damages to, or failure of other devices caused by using this product. A customer who purchases outside Japan should contact the local retailer in the country of purchase for enquiries.
