- Page 1 OWNER’S MANUAL TRINITY PRO 36” LOCKER CABINET Model # TSNPBK-0610 Important / Important / Importante FOR QUICK & EASY 3D ASSEMBLY INSTRUCTIONS Intelligent Instructions Directives intelligentes POUR DES DIRECTIVES D’ASSEMBLAGE 3D RAPIDES ET FACILES Instrucciones Inteligentes PARA INSTRUCCIONES DE ENSAMBLAJE RÁPIDAS Y SENCILLAS EN 3D...
- Page 2 © 2020 TRINITY - 800.985.5506...
-
Page 3: Parts List
PARTS LIST Your TRINITY PRO 36“ Locker Cabinet should include the following parts. Please inspect box contents to ensure you have received all components. If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY Customer Service: 800.985.5506 or customerservice@trinityii.com. - Page 4 ASSEMBLY INSTRUCTIONS STEP 1 Lay CABINET BODY (A) gently on its back. Two people are needed, do NOT attempt this alone. Screw FEET LEVELER (D) fully into each pre-installed nut on four corners of cabinet bottom. Stand cabinet right side up. Move it to desired location.
-
Page 5: Usage Instructions
USAGE INSTRUCTIONS OPEN AND CLOSE DOOR Stopper Plate Lift up door handle to release it from slot on handle base plate, rotate it forward and pull it to open door. Close door by making sure ends of door bar is pushed against the stopper plate both on top and bottom. - Page 6 SERVICE PARTS LIST – TSNPBK-0610 TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description PBK-18-020-3624 Cabinet Body XSV-02-017-0001 Shelf Support XSV-09-009-0004 Door Hinge XSV-01-010-0616 Handle Screw XBS-02-030-0002 Right Handle Base Plate XBS-02-030-0001 Left Handle Base Plate...
-
Page 7: Care And Maintenance
WARNINGS Read and understand all instructions. Failure to follow all instructions may result in injury and/or damage. The warnings, cautions, and instructions discussed in this manual cannot cover all possible conditions or situations that may occur. The user must always be aware of their environment and ensure that they use the product in a safe and responsible manner. - Page 8 © 2020 TRINITY - 800.985.5506...
-
Page 9: Product Registration
PRODUCT REGISTRATION Thank you for purchasing a TRINITY PRO 36” Locker Cabinet. In order to register your product and receive streamlined customer service, please fill out the following Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at www.trinityii.com or (3) scan and email the form to customerservice@trinityii.com. - Page 10 © 2020 TRINITY - 800.985.5506...
-
Page 11: Year Limited Warranty
Trinity International Industries (“Trinity”) warrants to the original consumer purchaser (“Purchaser”) of the TRINITY PRO 36” Locker Cabinet (“Product”) that each Product shall be free from defects in workmanship and materials for a period of 1 year from the date of original purchase. Trinity’s obligation under this warranty... - Page 12 CONTACT US QUESTIONS? NEED PARTS? WE ARE HERE TO HELP! Please feel free to contact us. There are no questions too small, or any problems too big. We’re committed to providing our customers with the highest level of service. TRINITY Customer Service TEL: 800.985.5506 FAX: 310.347.4134 EMAIL: customerservice@trinityii.com...
