- Page 1 OWNER’S MANUAL TRINITY PRO 4-TIER NSF 72" x 30" x 72" WIRE SHELVING RACK Model # TIJZ-0949 / TIJPBA-0949...
-
Page 2: Parts List
PARTS LIST Your TRINITY Pro 4-Tier NSF 72"x30"x72“ Wire Shelving Rack should include the following parts. Please inspect box contents to ensure you have received all components. If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY Customer Service: 800.985.5506 or customerservice@trinityii.com. - Page 3 ASSEMBLY INSTRUCTIONS STEP 1 For easiest assembly, do not attach TOP POLES (B) and BOTTOM POLES (A) until instructed. Once A (4) E (4) connected, these will be posts for the rack. Screw each FEET LEVELER (E) into bottom of each BOTTOM POLE (A).
- Page 4 ASSEMBLY INSTRUCTIONS STEP 3 Place SHELF (C) on its side and slide each BOTTOM POLE (A) through each corner cylinder on SHELF (C). Make sure SHELF (C) corner cylinders are positioned C (1) over SLIP SLEEVES (D). Stand the unit upright. Note: •...
- Page 5 ASSEMBLY INSTRUCTIONS STEP 5 Screw TOP POLE (B) into BOTTOM POLE (A). B (4) Repeat for each remaining TOP POLE (B). Note: The top of each TOP POLE (B) is indicated by a BLACK END CAP. STEP 6 Repeat Step 4 to install other SHELVES (C) as desired.
-
Page 6: Service Parts List
SERVICE PARTS LIST – TIJZ-0949 TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description XBK-01-011-2543 Slip Sleeve XBK-98-010-2535 Feet Leveler ZSV-04-006-3600 Top Pole XBK-23-004-2514 End Cap ZSV-01-013-2523 Pole Connector ZSV-03-075-7230 Shelf ZSV-04-043-3600 Bottom Pole © 2019 TRINITY - 800.985.5506... - Page 7 SERVICE PARTS LIST – TIJPBA-0949 TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description XBK-01-011-2543 Slip Sleeve XBK-98-010-2535 Feet Leveler PBA-04-006-3600 Top Pole XBK-23-004-2514 End Cap ZSV-01-013-2523 Pole Connector PBA-03-075-7230 Shelf PBA-04-043-3600 Bottom Pole © 2019 TRINITY - 800.985.5506...
-
Page 8: Care And Maintenance
WARNINGS 1. Read and understand all instructions. Failure to follow all instructions may result in injury and/or damage. 2. The warnings, cautions, and instructions discussed in this manual cannot cover all possible conditions or situations that may occur. The user must always be aware of the environment where the product will be placed and make sure to use the product in a safe and responsible manner. -
Page 9: Product Registration
PRODUCT REGISTRATION Thank you for purchasing a TRINITY Pro 4-Tier NSF 72"x30"x72“ Wire Shelving Rack. In order to register your product and receive streamlined customer service, please fill out the following Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at www.trinityii.com or (3) scan and email the form to customerservice@trinityii.com. - Page 10 © 2019 TRINITY - 800.985.5506...
-
Page 11: Year Limited Warranty
Trinity International Industries (“Trinity”) warrants to the original consumer purchaser (“Purchaser”) of the TRINITY Pro 4-Tier NSF 72"x30"x72“ Wire Shelving Rack (“Product”) that each Product shall be free from defects in workmanship and materials for a period of 1 year from the date of original purchase. Trinity’s... - Page 12 CONTACT US QUESTIONS? NEED PARTS? WE ARE HERE TO HELP! Please feel free to contact us. There are no questions too small, or any problems too big. We’re committed to providing our customers with the highest level of service. TRINITY Customer Service TEL: 800.985.5506 FAX: 310.347.4134 EMAIL: customerservice@trinityii.com...
