- Page 1 GARO GNM3D-RS485 and GARO GNM3D-LP RS485 as DLM meter DLM = Dynamic Loadbalancing Meter Installation and Programming Manual (EN) GARO AB Box 203, SE–335 25 Gnosjö info@garo.se garo.se...
-
Page 2: Table Of Contents
TABLE OF CONTENT INFORMATION MODBUS CONNECTION Warnings ELECTRICAL CONNECTION POWER CABLES DLM METER SETTINGS Touch area Modbus address information Set the Modbus Address Set/varify the Baudrate Set/varify the Parity and stopbit Confirm settings... -
Page 3: Information
Warnings All information in this guide is valid for both Make sure the electrical power is off before start of GARO GNM3D-RS485 (GARO art nr 108047) installation process. GARO GNM3D-LP RS485 (GARO art nr 109306). All electrical installation must be performed by an auhorized electrician. -
Page 4: Electrical Connection Power Cables
ELECTRICAL CONNECTION POWER CABLES F=Fuse 315mA if required by local regulation 1-6: section 2.5-16 mm², torque 2.8 Nm 7-12, N: section 1.5 mm², torque 0.4 Nm DLM METER SETTINGS Touch area... - Page 5 ”Longpress” center touch area until you see ”PASS”. ”Longpress” both left and right touch area to bypass the password. The blinking ”0” will stop to blink after 2 seconds.
-
Page 6: Modbus Address Information
Click left touch area until you see ”AddrESS”. Modbus address information For a stand alone wallbox, recommended address is 002. This mode will paus the charging process if available current in the system is below 6A. 6A is the minimum av EV can charge according to standard. -
Page 7: Set The Modbus Address
Set the Modbus Address 1. Longpress touch area. 00”1” starts to blink. 2. Click left or right touch area to modify the figure. 3. Longpress touch area to change to next figure and repeat step 2. 4. When the adress is correct, longpress touch area to confirm the address. -
Page 8: Set/Varify The Baudrate
Set/varify the Baudrate Click left touch area until ”bAud” is visible. Default is ”9.6” and this is correct. If you need to change baud, longpress center touch area and click left or right touch area until 9.6 is visible. Confirm by longpress touch area . -
Page 9: Confirm Settings
Confirm settings 1. Click left touch area until ”End” is visible. 2. Longpress center touch area when ”End” is visible and the setting is confirmed. 3. The square is blinking when DLM meter have communication with the wallbox.
