INSTALLATION INSTRUCTIONS
NS22HM
This is a safety alert symbol and should never be ignored. When you see this symbol on labels or in manuals, be alert to
the potential for personal injury or death.
Installation and servicing of air conditioning equipment
can be hazardous due to internal refrigerant pressure
and live electrical components. Only trained and
qualified service personnel should install or service
this equipment. Installation and service performed by
unqualified persons can result in property damage,
personal injury, or death.
ELECTRICAL SHOCK HAZARD!
Risk of electrical shock. Disconnect all
remote power supplies before installing
or servicing any portion of the system.
Failure to disconnect power supplies
can result in property damage, personal
injury, or death.
IMPORTANT
The Clean Air Act of 1990 bans the intentional venting
of refrigerant (CFCs, HCFCs and HFCs) as of July
1, 1992. Approved methods of recovery, recycling or
reclaiming must be followed. Fines and/or incarceration
may be levied for noncompliance.
GE Appliances
A Haier Company
Appliance Park
Louisville, KY 40225
508311G01 / 31-5000754
This manual must be left with the homeowner for future reference.
WARNING
WARNING
Variable Capacity Heat Pump

Table of Contents

Application ...................................................................1
General ........................................................................2
Installation ...................................................................2
Refrigerant Piping ........................................................4
Outdoor Unitary Control.............................................18
Unit Operation ...........................................................20
Start-Up .....................................................................20
Maintenance ..............................................................23
Homeowner Information ............................................23
Start-Up and Performance Checklist .........................26
Sharp metal edges can cause injury. When installing
the unit, use care to avoid sharp edges.

Application

These units are designed for use in residential and light
commercial type buildings. Units should be installed with
approved indoor matches listed in the Air-Conditioning,
Heating and Refrigeration Institute (AHRI) Directory of
Certified Products. Refer to http://www.ahridirectory.org.
*P508311G01*
Issue 2250
WARNING
(P) 508311G01
Page 1 of 26
