Specifications - Thermolec RVE DCC-9-BOX3 Installation Manual

Do not use any cleaning solvents to clean
the DCC – EVEMS.
Limited warranty
warrants the inte-
1 THERMOLEC LTÉE.
grated controls against any defects for
a period of one year from the shipping
date. The warranty is limited to the
equipment and components supplier
by
THERMOLEC LTÉE.
In case of incorrect installation, inap-
2
propriate use or repairs done by unau-
thorized personnel by
THERMOLEC
, the warranty will be automati-
LTÉE.
cally void.
undertakes to repair
3 THERMOLEC LTÉE.
or replace, at site or at the manufactu-
ring location, at his option, the defec-
tive material only after an evaluation
made by its representative.
. will not be held
4 THERMOLEC LTÉE
liable for damages or delays and will
not be required to pay transport cost
of the EVEMS said to be defective.
shall not be liable
5 THERMOLEC LTÉE.
for any indirect damages or delays
caused by faulty workmanship or
materials.
No indemnity will be paid for repairs,
replacements or modifications wit-
hout a prior written consent supplied
by
THERMOLEC LTÉE.
Any control device or accessory sup-
6
plied with the DCC – EVEMS to be
installed or connected remotely from
the EVEMS will be guaranteed by the
manufacturer only under the special
conditions mentioned in paragraph 5.
The components supplied for repairs
7
are guaranteed for the remaining of
the warranty on the original product or
90 days. The longest period will pre-
vail.
All repairs made at the
8 THERMOLEC
plant are guaranteed for 30 days
LTÉE.
from the date of repairs.

SPECIFICATIONS

DCC-9-BOX is a splitter box specifically designed to make a building's
electrical infrastructures fully ready for electric vehicles at the lowest
possible price.
For bundled installations, taller versions (BOX3 and BOX6) can house 3
or 6 DCC PCBs in order to maximise space usage.
Models Dimensions
(H" x W" x D")
DCC-9-BOX 12" x 12" x 7.5"
DCC-9-BOX-3R 14" x 13" x 8"
DCC-9-BOX3 39" x 14" x 9"
DCC-9-BOX6 78" x 14" x 9"
240/208V AC single phase: L1, L2,
Voltage and wiring
Neutral, Ground.
Terminals size up to 2/0
Certifications
*Approximative and can change without notice.
Total weight
* *
11 lb (4,99 kg)
12 lb (5,44 kg)
40.5 lb (18,37 kg)
81 lb (36,74 kg)
(CU/AL)
V4
5
