Do not install the DCC stack:
- Outdoor
- In a location where it would be at risk of being damaged
- Nearby inflammable materials, explosives or fuels, chemical
products and vapors.
3. Before installation, check the DCC stack mounting position.
Warranty automatically void if the DCC is installed incorrectly.
STEP 3: INSTALLATION
1. Remove the cover screws (4 per cover) and remove each of the front
covers;
2. Position the DCC stack at the intended location;
3. Fix the DCC stack with the anchors suitable for the type of surface;
4. Check that the DCC stack is adequately fixed to the floor.
STEP 4: DUCT INSTALLATION
The ducts can be installed according to the layout chosen by the installer:
- On the back of the stack, for each DCC box, to the corresponding meter
socket if the DCCs and the meters are back-to-back:
DCC-9-BOX6
WARNING
SIDE VIEW
Meter Stack
- On the sides, from the upper and lower junction boxes of the DCC stack:
- Downwards and/or upwards from the upper and lower junction boxes
of the DCC stack:
STEP 5: CONDUCTOR CONNEXIONS
See label within the box.
The location of the terminals of the main power supply and of
the panel is modified from the DCC-9 generation 2.1.
Please pay attention to the indications "L1" and "L2" in the box.
STEP 6: SECURE AND RE-ENERGIZE
1. Secure : Put the cover back on each DCC;
2. Re-energize : Supply electrical power to the DCC.
STEP 7: IDENTIFICATION
1. Register all the information of the charging station owner (address
and parking space) in the space provided on the cover of each DCC;
2. Register all configuration settings of the main power supply (essential
load) in the space provided on the cover.
DCC-9-BOX3 & DCC-9-BOX6
WARNING
