- Page 1 EN User Manual | Oven ZOHNA7K1 ZOHNA7X1 zanussi.com\register...
-
Page 2: Table Of Contents
VISIT OUR WEBSITE TO: Get usage advice, brochures, trouble shooter, service and repair information: www.zanussi.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. INSTALLATION....................7 4. PRODUCT DESCRIPTION................8 5. CONTROL PANEL..................9 6. BEFORE FIRST USE..................9 7. - Page 3 be kept away from the appliance unless continuously supervised. • Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use.
-
Page 4: Safety Instructions
• WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements or the surface of the appliance cavity. • Always use oven gloves to remove or insert accessories or ovenware. •... - Page 5 electrical ratings of the mains power supply. Total power (W) Section of the cable • Always use a correctly installed (mm²) shockproof socket. maximum 3680 3x1.5 • Do not use multi-plug adapters and extension cables. The earth cord (green / yellow cable) must be •...
- Page 6 – do not put water directly into the hot • If you use an oven spray, follow the safety appliance. instructions on its packaging. – do not keep moist dishes and food in 2.5 Internal lighting the appliance after you finish the cooking.
-
Page 7: Installation
3. INSTALLATION 3.1 Building in WARNING! Refer to Safety chapters. (*mm) min. 550 min. 560 ±1 (*mm) min. 550 min. 560 ±1 ENGLISH... -
Page 8: Product Description
3.2 Securing the oven to the cabinet 4. PRODUCT DESCRIPTION 4.1 General overview Control panel Knob for the heating functions Display Control knob (for the temperature) Heating element Lamp Cavity embossment - Aqua cleaning container Shelf support, removable Shelf positions 4.2 Accessories •... -
Page 9: Control Panel
5. CONTROL PANEL 5.1 Retractable knobs To use the appliance press the knob. The knob comes out. 5.2 Sensor fields / Buttons To set the MINUTE MINDER. Hold it for more than 3 seconds to turn on or turn off the oven lamp. To set a clock function. -
Page 10: Daily Use
Step 2 Set the maximum temperature for the function: Let the oven operate for 1 h. Step 3 Set the maximum temperature for the function: Let the oven operate for 15 min. The oven can emit an odour and smoke during preheating. Make sure that the room is ventilated. 7. -
Page 11: Clock Functions
The oven door should be closed during cooking so that the function is not interrupted Heating func‐ Application and the oven operates with the highest tion energy efficiency possible. To clean the oven cavity. Refer When you use this function the lamp to "Care and cleaning"... - Page 12 Step 4 - press to confirm. The display shows the set time. - press repeatedly to change the time of day. - flashes in the display. 8.3 How to set function: Duration Step 1 Set a heating function. Step 2 - press repeatedly.
-
Page 13: Using The Accessories
Step 4 Turn the knob for the temperature to set the hour for the function: Duration. Press: The display shows: Step 5 Turn the knob for the temperature to set the hour for the function: End Time. Press: Step 6 Turn the knob for the temperature to set the minutes for the function: End Time. - Page 14 Wire shelf: Push the shelf between the guide bars of the shelf support and make sure that the feet point down. Deep pan: Push the tray between the guide bars of the shelf support. AirFry: Place the tray on the third shelf position. Place the baking tray on the first shelf position.
-
Page 15: Additional Functions
Make sure the supports of the wire shelf point up. Make sure the supports of the wire shelf point down. 10. ADDITIONAL FUNCTIONS 10.1 How to use: Child lock Refer to "Additional functions" chapter, Using the Child Lock. When the function is on the oven cannot be turned on accidentally. -
Page 16: Hints And Tips
10.6 Safety thermostat safety thermostat which interrupts the power supply. The oven turns on again Incorrect operation of the oven or defective automatically when the temperature drops. components can cause dangerous overheating. To prevent this, the oven has a 11. HINTS AND TIPS Leave the meat for approximately 15 minutes before carving so that the juice does not seep out. - Page 17 (°C) (min) Sweet rolls, 16 pieces baking tray or dripping pan 20 - 30 Rolls, 9 pieces baking tray or dripping pan 30 - 40 Pizza, frozen, 0.35 kg wire shelf 10 - 15 Swiss roll baking tray or dripping pan 25 - 35 Brownie baking tray or dripping pan...
- Page 18 ( °C) (min) Small Conventional Baking tray 20 - 35 cakes, 20 Cooking per tray Small True Fan Baking tray 150 - 160 20 - 35 cakes, 20 Cooking per tray Small True Fan Baking tray 2 and 4 150 - 160 20 - 35 cakes, 20 Cooking...
-
Page 19: Care And Cleaning
12. CARE AND CLEANING WARNING! Refer to Safety chapters. 12.1 Notes on cleaning Clean the front of the appliance only with a microfibre cloth with warm water and a mild de‐ tergent. Clean and check the door gasket around the frame of the cavity. Use a cleaning solution to clean metal surfaces. - Page 20 12.3 How to use: Aqua Clean Step 2 This cleaning procedure uses humidity to Set the function: remove remaining fat and food particles from The function works for 30 min. the oven. Step 3 Turn off the oven. Step 4 Wait until the oven is cold.
- Page 21 Step 5 Hold the door trim (B) on the top edge of the door at the two sides and push inwards to re‐ lease the clip seal. Step 6 Pull the door trim to the front to remove it. Step 7 Hold the door glass panels by their top edge and carefully pull them out one by one.
-
Page 22: Troubleshooting
12.5 How to replace: Lamp Always hold the halogen lamp with a cloth to prevent grease residue from burning on the lamp. WARNING! Risk of electric shock. The lamp can be hot. Before you replace the lamp: Step 1 Step 2 Step 3 Turn off the oven. -
Page 23: Energy Efficiency
14.1 Product Information Sheet according to UK Ecodesign and Energy Labelling Regulations Supplier's name Zanussi ZOHNA7K1 949497022 Model identification ZOHNA7X1 949497021 Energy Efficiency Index 81.2 Energy efficiency class Energy consumption with a standard load, conventional mode 0.93 kWh/cycle Energy consumption with a standard load, fan-forced mode 0.69 kWh/cycle... -
Page 24: Environmental Concerns
Type of oven Built-In Oven ZOHNA7K1 32.0 kg Mass ZOHNA7X1 32.0 kg BS EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam ovens and grills - Meth‐ ods for measuring performance. 14.2 Energy saving The fan and lamp continue to operate. When you turn off the appliance, the display shows the residual heat. - Page 28 867359281-C-042023...
