OWNER'S MANUAL

LCD MONITOR

Please read this manual carefully before operating your set and
retain it for future reference.
LCD MONITOR MODEL
E2211PU
E2411PU
www.lg.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E2211PU and is the answer not in the manual?

Questions and answers

Summary of Contents for LG E2211PU

  • Page 1: Lcd Monitor

    OWNER’S MANUAL LCD MONITOR Please read this manual carefully before operating your set and retain it for future reference. LCD MONITOR MODEL E2211PU E2411PU www.lg.com...
  • Page 2: Important Precautions

    Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential electrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing.
  • Page 3 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
  • Page 4: On Cleaning

    Important Precautions On Cleaning Unplug the display before cleaning the face of the display screen. Use a slightly damp (not wet) cloth. Do not use an aerosol directly on the display screen because over-spraying may cause electrical shock. When cleaning the product, unplug the power cord and scrub gently with a soft cloth to prevent scratching.
  • Page 5 Accessories !!! Thank for selecting LGE products !!! Please make sure the following items are included with your monitor. If any items are missing, contact your dealer. Power Cord User's Guide/Cards 15-pin D-Sub Signal Cable DVI-D Signal Cable (To set it up, this signal cable may be (This feature is not available in all attached to this product before countries.)
  • Page 6: Connecting The Display

    Connecting the Display E2211PU Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices are turned off. Connecting the stand base Place the monitor with its front facing downward on a cushion or soft cloth.
  • Page 7: Removing The Stand Base

    Connecting the Display E2211PU Use a coin on the back of the stand base and turn the screw clockwise to tighten. Lift and turn the monitor to face towards the front after the connection is made to the female part of the cable you're attaching.
  • Page 8 Connecting the Display E2411PU Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices are turned off. Connecting the stand base Place the monitor with its front facing downward on a cushion or soft cloth. Assemble the Stand Base into the Stand Body.
  • Page 9 Connecting the Display E2411PU Removing the stand base Place the monitor with its front facing downward on a cushion or soft cloth. While pressing the latches, push the stand base in the direction of the arrow to separate from the stand body. IMPORTANT This illustration depicts the general model of connection.
  • Page 10: Positioning Your Display

    Connecting the Display Positioning your display After installation, adjust the angle as shown below. Adjust the position of the panel in various ways for maximum comfort. Tilt Range Swivel Range : 356˚ Height Range : maximum 4.33 inches (110.0 mm) 110.0 mm * Please be sure to remove the Locking...
  • Page 11 Connecting the Display When adjusting the angle of the screen, do not put your finger(s) in between the head of the monitor and the stand body. You can hurt your finger(s). When adjusting the height of the screen, do not put your finger(s) in between the head of the monitor and the stand base.
  • Page 12: Using The Pivot Function

    Connecting the Display Using the Pivot function -The pivot function allows you to rotate the screen 90 degrees clockwise. Lift the monitor to its highest height to utilize the Pivot function. . Landscape & Portrait : You can rotate the panel 90 clockwise.
  • Page 13: Connecting With The Pc

    Connecting the Display Connecting with the PC Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connect signal input cable and power cord in order, then tighten the screw of the signal cable.
  • Page 14 Connecting the Display Put the power cord and cables into the cable holder.(Only E2411PU) Cable Holder Press the power button on the front panel to turn the power on. When monitor power is turned on, the 'Self Image Setting Function' is executed automatically. (Only Analog Mode) Power Button NOTE...
  • Page 15: Connecting The Usb Cable

    Connecting the Display Connecting the USB(Universal Serial Bus) Cable You can use the USB port at the back of the monitor to connect peripherals (USB mouse, USB keyboard, etc.) to the monitor, not to the computer. Two USB Downstream ports Connect these ports to a mouse, USB keyboard,memory stick with current spec under 100mA.
  • Page 16: Front Panel Controls

    Control Panel Functions Front Panel Controls MENU Button OSD LOCKED/UNLOCKED This function allows you to lock the current control settings, so that they cannot be inadvertently changed. Press and hold the MENU button for several seconds. The message "OSD LOCKED" should appear. You can unlock the OSD controls at any time by pushing the MENU button for several seconds.
  • Page 17: Auto Button

    (display mode). The best display mode is E2211PU/E2411PU : 1920 x 1080 When two input signals are connected, you can select the INPUT Button input signal (D-SUB/DVI) you want. When only one signal (SOURCE Hot key) is connected, it is automatically detected.
  • Page 18: On Screen Display (Osd) Control Adjustment

    On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls.
  • Page 19: On Screen Display(Osd) Selection And Adjustment

    On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. : D-SUB(Analog signal) input DSUB : DVI-D(Digital signal) input DVI-D Main menu Sub-menu Supported input Description MENU To adjust the volume VOLUME DSUB DVI-D...
  • Page 20 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Press the MENU Button, then the main menu of the OSD appears.
  • Page 21 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description To adjust the volume of headphone/Speaker. To adjust the brightness of the screen. WIDE Switch to full screen mode according to input image signal. ORIGINAL Change the input image signal ratio to original.
  • Page 22 On Screen Display(OSD) Selection and Adjustment Main menu Description To adjust the contrast of the screen. To choose the language in which the control names are displayed. Restore all factory default settings except "LANGUAGE." Press the buttons to reset immediately. Exit : Exit : Move : Select another sub-menu...
  • Page 23 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Press the SUPER ENERGY SAVING Button, then the main menu of the OSD appears.
  • Page 24 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description Turn on the SUPER ENERGY SAVING fuction. When current setting value is ON,the SUPER SAVING color is green. Turn off the SUPER ENERGY SAVING function.Now the monitor is LED SAVING function. When current setting value is OFF,the SUPER SAVING color is gray.
  • Page 25 Saving Data depends on the Panel. So,those values should be different from each panel and panel vendor. LG accumulate those values using integrated function with 10 minutes broadcast video signal. LED Saving means that how much power can be saved using WLED Panel instead of CCFL panel.
  • Page 26: Troubleshooting

    Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the • Check and see if the power cord is connected display connected? properly to the power outlet. Is the power indicator •...
  • Page 27: Display Image Is Incorrect

    Troubleshooting Display image is incorrect Display Position is • Press the AUTO button to automatically adjust incorrect. your display image to the ideal setting. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display.
  • Page 28 • Be sure to install the display driver from the display display driver? driver CD (or diskette) that comes with your display. Or, you can also download the driver from our web site: http://www.lg.com. • Make sure to check if the video card supports Plug&Play function.
  • Page 29: Specifications

    Specifications E2211PU Display 54.6 cm (21.5 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 54.6 cm 0.248 x 0.248 mm (Pixel pitch) Horizontal Freq. 30 kHz to 83 kHz (Automatic) Sync Input Vertical Freq. 56 Hz to 75 Hz (Automatic) Input Form Separate Sync.
  • Page 30 Specifications E2411PU Display 60.9 cm (24 inch) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size : 60.9 cm 0.276 x 0.276 mm (Pixel pitch) Horizontal Freq. 30 kHz to 83 kHz (Automatic) Sync Input Vertical Freq. 56 Hz to 75 Hz (Automatic) Input Form Separate Sync.
  • Page 31: Preset Modes (Resolution)

    Specifications Preset Modes (Resolution) E2211PU/E2411PU Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 31.468 720 x 400 31.469 640 x 480 37.500 640 x 480 37.879 800 x 600 46.875 800 x 600 48.363 1024 x 768 60.023 1024 x 768 67.500...
  • Page 32: Installing The Wall Mount Plate

    Installing the Wall mount plate This monitor satisfies the specifications of the Wall mount plate or the interchange device. After moving the product to face downward, make sure to place it on a soft cloth or a cushion to avoid surface damage.
  • Page 33 Installing the Wall mount plate Install the Wall mount plate. Wall mount plate(Separate purchase) This is stand-type or wall mount type and is connectable with Wall mount plate. Please refer to the installation guide for more details, which is provided when Wall mount plate is purchased.
  • Page 34 Make sure to read the Safety Precautions before using the product. Keep the OWNER’S MANUAL(CD) in an accessible place for furture reference. The model and serial number of the SET is ENERGY STAR is a set of power-saving located on the back or one side of the SET. guidelines issued by the U.S.Environmental Record it below should you ever need service.

This manual is also suitable for:

E2211pu-bnE2411puE2411pu-bnE2211puxE2411pux
