PART NAMES

BOTTOM VIEW
8
V
(Do not leave rack in microwave
unless cooking on rack.)
Front
Back
1 Microwave oven door with see-through window
2 Door hinges
3 Waveguide cover:
DO NOT REMOVE.
4 Turntable motor shaft
5 Microwave oven light
It will light when microwave oven is operating or
door is open.
6 Rack holders
7 Safety door latches
The microwave oven will not operate unless the
door is securely closed.
8 Handle
9 Light hi/lo/off pad
Press the light hi/lo/off pad once for high, twice
for low and three times to turn off the light.
10 Vent hi/lo/off pad
Press the vent hi/lo/off pad once for high
speed, twice for low speed and three times to
turn off the fan.
11 Auto-Touch control panel
12 Time display: Digital display, 99 minutes, 99
seconds
13 Ventilation openings
® Filter Access Door
PureAir
14
®
PureAir Microwave Carbon Filter
15
16 Menu label
17 Removable turntable
The turntable will rotate clockwise or counter-
clockwise. Only remove for cleaning.
18 Removable turntable support
First, carefully place the turntable support on the
motor shaft in the center of the microwave oven
floor. Place the support ring on the microwave oven
floor. Then, place the turntable on the turntable
support securely.
19 Rack for 2-level cooking/ reheating
20 Light cover
21 Grease filters
