- Page 1 32” LED TV WITH DVB-T2/DVB-C Model NO.: LED-3259TC Instruction Manual www.facebook.com/denverelectronics...
-
Page 2: Table Of Contents
Contents Caution Safety Information Accessories Technical Specification Product Introduction Front View Connections Remote Control 8-10 OSD Menu 11-27 1. INPUT 2. VIDEO 12-13 3. AUDIO 4. TV 15-17 5. SETUP 6. Time Setup 19-20 7. Lock 8. Hotel Mode 22-23 9. -
Page 3: Caution
Caution The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of un-insulated "dangerous voltage” within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to the persons. -
Page 4: Safety Information
Safety Information To ensure reliable and safe operation of this equipment, please read carefully all the instructions in this user guide, especially the safety information below. Electrical safety To prevent overload, don't share the same mains supply socket with too many other items of equipment. -
Page 5: Accessories
Accessories User’s Manual Remote control Converter AV Cable Converter cable cable for AV for YPbPr * Note: The configuration of the components may look different from the following illustration Technical Specification TV System PAL BG/DK/I SECAM BG/DK L/L’ Screen Size 32 inch(diagonal) Resolution 1920x1080... -
Page 6: Product Introduction
Product Introduction Introduction Front View Led Indicator Led Indicator Switch Switch Remote Control window (Keep clear) Remote Control window (Keep clear) (IR) Infrared Receiver: Receives IR signals from the remote control. POWER to turn on and off. Indicator on(Red) Standby mode Indicator off (Null) Power on mode The effective receiving range for the signal is 5-8 metres from the front of the remote... -
Page 7: Connections
Connections Headphone: Connect it to your headphone or other audio equipment. Common Interface: CI slot. USB: USB jack for update, media and PVR. Coax: Digital coaxial output. RF: Connect antenna or cable 75 Ohm coaxial to receive TV signal. RJ45: For automatic upgrades for MHEG5 (Digital Text interactive services) and HD services. -
Page 8: Remote Control
Remote Control The remote control is using Infrared (IR). Point it towards the front of the LED TV. The remote control may not work correctly if it is operated out of range or out of angle. - Page 9 Remote Control NUM. BUTTON&FUNCTION 1 POWER - Press this button to switch on the TV when at standby mode or enter standby mode. 2 MUTE - Press this button to mute or restore sound. 3 CH-/CH+ - Changes the channels up and down. [0-10+]- Directly elect a TV channel CH-List - Display the channel list (only in DTV).
-
Page 10: Fti
Welcome Welcome to use the wizard for initial Setup!! please press [ OK ] start the wizard. Language Please select your language, press []/[] to select, press [ OK ] to confirm:... - Page 11 Country Please select your country, press []/[] to select, press [OK] to cofirm: Tuner Type Please select your tuner type, press []/[] to select, press [OK] to confirm: Option Description Antenna Set the signal type to antenna. When set to Air, TV can catch Tuner analog and DVB-T broadcasting signal.
- Page 12 Scan Please select your scan, press [▼]/[▲] to select, press [OK] to confirm: Option Description Scan Automatically search for channels. Skip the scan and enter to the complete interface. Skip Scan Complete...
-
Page 13: Osd Menu
Input Source Press INPUT to display the input source list, and press ▼/▲ to select and OK to confirm. Using the Remote Control to Display and Navigate the On-Screen Main Menus Press to display the on-screen menu. Use the ◄ or ► buttons to highlight the desired menu icon. -
Page 14: Video
Video Option Description Use the ▼ or ▲ buttons to highlight one of the following options, then Picture Mode press [OK] to enter the sub-menu and press ◄ or ► to adjust. Standard Select for standard picture settings. Recommended for home entertainment. Vivid Select for enhanced picture contrast and sharpness. - Page 15 Option Description Use the ▼ or ▲ buttons to highlight one of the following options, Color then-press [OK] to enter the sub-menu and press ◄ or ► to adjust. Temperature Standard Select to give the white color a neutral tint. Warm Select to give the white color a reddish tint.
-
Page 16: Audio
Audio Option Description Adjust the level of sound coming from the left and right speakers. Press ◄ Balance to decrease balance. Press ► to increase the balance. Adjust the high frequency sounds. Bass Press ◄ to decrease bass. Press ► to increase the bass. Adjust the low frequency sounds. - Page 17 Option Description Use the ▼ or ▲ buttons to highlight one of the following options, then press [OK] to Tuner Mode enter the sub-menu and press ◄ or ► to adjust. Cable Set the signal type to cable. When set to Cable, TV can catch analog and DVB-C broadcasting signal.
- Page 18 Channel Scan Analog Manual Scan Digital Manual Scan Option Description Favorite Network Select Add channels to create a favorite list. Manually add and skip channels in your program list. For detail, please reference page Channel Skip Manually sort channels in your program list. For Channel Sort detail, please reference page 12.
- Page 19 Channel Sort Channel Skip Channel Edit Schedule List...
-
Page 20: Setup
Setup Option Description OSD Language Set the On-Screen-Display language. Aspect Ratio Choose from, 4:3, 16:9, Zoom1, Zoom2, and Panorama. Blue Screen Set the screen to blue or not when having no signal. Interaction Set the channel to interaction or not when having no signal. Channel MHEG PIN Set the MHENG PIN Protection or not when having no signal. -
Page 21: Time Setup
Time Setup Option Description Set the time zone. Time Zone: Press ◄ or ► to select the time zone. Set the current date/time. Time: Press ◄/►/[OK] to adjust. Set the sleep time. Sleep Timer: Press ◄ or ► to select the sleep time. Auto Sleep: Set the Auto Sleep off. - Page 22 Option Description Audio Use the ▼ or ▲ buttons to highlight one of the following options, then Language press [OK] to enter the sub-menu and press ◄ or ► to adjust. Audio language 1st Set the first language for the audio, Audio language 2nd Set the second language for the audio, First Time Set the first time installation.
-
Page 23: Lock
Lock Option Description Use the ▼ or ▲ buttons to highlight one of the following options, then Password press [OK] to select it and then you will enter the password interface. After entering the correct password, you will see the submenu as the picture below. -
Page 24: Hotel Mode
Hotel Mode HOTEL Press ▲ ▼ to select Hotel Mode and press OK button and enter the code by the number buttons to enter HOTEL MODE menu (the original password is 0000). Hotel Mode: Press ▲ ▼ to select Hotel Mode and press ◄►to select the ON or OFF. Source Lock: press ▲... - Page 25 Set the channel/program block on or off. System Lock Set the channel source be locked. Channel Block Program Block Set the program source be locked. Enter the 4-digital new password and confirm it. Change Password Set the items in the lock menu to default values. Clear All...
-
Page 26: Pvr Menu
PVR Menu PVR function is only available for DTV, includes Record and Playback function. Note When PVR function is in progress, please don't unplug the power and the external USB device at well. When PVR function is active, the power indicator will blink with red and green consecutively. Before start recording a program, please make sure the external USB device is connected. - Page 27 After disk setup then press ►/ll button on remove control start timeshift, the screen is to stop and have time to show -00:00:01 ... moving around: After timeshift some time, if you want to watch the program, press the ►/▌key to enter the play mode. Press the ■...
- Page 28 Schedule Type Press blue button enter to sub-menu. Press ◄/► button select the schedule type as Record and Reminder. Repeat Type Press ◄/► button select the repeat type as Once, Daily and Week. In record mode, status bar does not any operating, it will start automatically recording when time is up. NOTE: The difference between the record mode and reminder mode.
-
Page 29: Vga
Option Description Use the ▼ or ▲ buttons to highlight one of the following options, then press Auto [OK] to enter the sub-menu press ◄ or ► to adjust. Adjust Select to automatically adjust the display position and phase of the picture when the TV receives an input signal from the connected PC. -
Page 30: Usb
Press INPUT to display the input menu, and select USB. For details, Photo Page29. Music Page 30. Video Page 31. Text Page 32. For this interface, you can press MENU to display the menu after select one file, no mater it is a music or video/Photo... -
Page 31: Photo
PHOTO Press MENU to display the menu. Play Press ENTER to pause or play the music. Repeat None/Repeat One/Repeat All Press ENTER to select the repeat mode. Shuffle On/Off Press ENTER to play orderly or disorderly. Rotate Rotate the photo clockwise/counterclockwise. Duration Press ENTER to display the information about the current music. -
Page 32: Music
Music Press MENU to display the menu. Pause Press ENTER to pause or play the music. Repeat None/Repeat One/Repeat All Press ENTER to select the repeat mode. Shuffle On/Off Press ENTER to play orderly or disorderly. Show info Press ENTER to display the information about the current music. Hide Spectrum Press ENTER to hide or show the spectrum. -
Page 33: Video
Video Press MENU to display the menu. Pause Press ENTER to pause or play the video. Repeat None/Repeat One/Repeat All Press ENTER to select the repeat mode. Show info Press ENTER to display the information about the current video. Picture mode Press ENTER to select the picture mode. -
Page 34: Text
Text Press MENU to display the menu. Pause Press ENTER to pause or play the text automatically. Repeat None/Repeat One/Repeat All Press ENTER to select the repeat mode. Shuffle On/Off Press ENTER to play orderly or disorderly. Font Press ENTER to enter the submenu to set the Size/Style/Color. Show info Press ENTER to display the information about the current video. -
Page 35: Simple Troubleshooting
Simple Troubleshooting If the display fails or performance dramatically deteriorates check the Display in accordance with the following instructions. Remember to check the peripherals topinpiont the source of the failure. If the display still fails to perform as expected, connect your helpline for assistance. No power - Check all connections to the TV. - Page 37 ALL RIGHTS RESERVED, COPYRIGHT DENVER ELECTRONICS A/S Electric and electronic equipment and included batteries contains materials, components and substances that can be hazardous to your health and the environment, if the waste material (discarded electric and electronic equipment and batteries) is not handled correctly.
