INDICATOR LED

■ STATUS INDICATOR LED
SD *
PWR RUN ERR
1
ON ON BL BL
ON ON BL BL
ON ON BL BL
ON ON BL OFF
ON ON BL OFF
ON ON OFF BL
ON ON OFF BL
ON ON OFF OFF
ON ON OFF OFF
ON OFF BL BL
ON OFF BL BL
ON OFF BL OFF
ON OFF BL OFF
ON OFF OFF BL
ON OFF OFF BL
ON OFF OFF OFF
ON OFF OFF OFF
ON OFF ON OFF ON/OFF Faulty Baud Rate and/or Station Address setting
OFF OFF OFF OFF
OFF = OFF, ON = ON, BL = Blinking
*1. SD LED which is blinking may appear to be ON with high baud rate especially when fewer modules are connected.
*2. LED combinations indicated with "----" do not occur in normal operation unless LED failure or the like occurs.
PC CONFIGURATOR
The following parameter items can be set with using PC Configurator Software (model: R7CON).
Refer to the users manual for the R7CON for detailed operation of the software program.
■ INTERFACE SETTING
PARAMETER
Communication Timeout
■ CHANNEL INDIVIDUAL SETTING
PARAMETER
Zero scale
Full scale
Bias
Gain
■ EXTENSION MODULE SETTING
PARAMETER
Output Hold/Clear
SEN TRONIC
STATUS *
RD
2
ON Communicates normally with occasional CRC errors due to noise interference.
ON Communicates normally but the Baud Rate and/or Station Address switches failed.
ERR LED blinks approximately in 0.5 seconds intervals.
OFF ----
ON CRC error detected in the received data. Unable to respond.
OFF ----
ON Normal communication
OFF ----
ON Unable to receive data addressed to the station.
OFF ----
ON Polling response is made but CRC error is detected in received refresh data.
OFF ----
ON CRC error detected in the data addressed to the station.
OFF ----
ON Link is not started.
OFF ----
ON No data addressed to the station. Or unable to receive data addressed to the station
due to noise interference. (Missing parts of the data sent from the master)
OFF Unable to receive data due to wire breakdown
OFF Power input removed or power supply failure.
SETTING RANGE
0.0 – 3276.7 (sec.)
SETTING RANGE
-32000 to +32000
-32000 to +32000
-320.00 to +320.00
-3.2000 to +3.2000
SETTING RANGE
Output Hold
Output Clear
056 222 38 18
AG
DEFAULT SETTING
3.0 (sec.)
DEFAULT SETTING
0
10000
0.00
1.0000
DEFAULT SETTING
Output Hold
mailbox@sentronic.com www.sentronic.com
R7C-DS4N
EM-7801-BA P. 3 / 10
