ekwb EK-FC7850 Installation And Mounting Manuals

This product is intended for installation only by expert users. Please consult with a qualified technician for installation. Improper installation may result in damage to your equipment. EK Water Blocks assumes no liability
whatsoever, expressed or implied, for the use of these products, nor their installation. The following instructions are subject to change without notice. Please visit our web site at
installation of this product please read important notice, disclosure and warranty conditions printed on the back of the box.
Before you start using this product please follow these basic guidelines:
1. Please carefully read the manual before through before beginning with the installation process!
2. The EK High Flow and EK-PSC type fittings require only a small amount of force to screw them firmly in place since the liquid seal is ensured by the rubber o-ring gaskets.
3. This water block is compatible with CSQ series EK-FC Bridge only!
4. The use of quality, market proved corrosion inhibiting coolants is always strongly recommended for any liquid cooling system.

STEP 1: GENERAL INFORMATION.

STEP 2 cont.: PREPARING YOUR GRAPHIC CARD
1 cont.. REMOVING STOCK COOLER.
encircled screws attaching the factory heat-sink fan solution to the printed circuit board.
There are up 9 screws on the back of the graphic card.
3. APPLYING THERMAL COMPOUND.
AMD
compound: lightly coat GPU chip with for example
Arctic Cooling MX-2 ™,MX-4 ™ or GELID GC-Extreme ™
thermal grease. EKWB recommends to apply thermal
grease in cross form for best performance (see sample
picture).

STEP 3: INSTALLING WATER BLOCK

1. PLACING THERMAL PADS ON PCB.
enough pads to cover all surfaces that need to be covered to make block fully functional). EKWB recommends using small drops of electrically non-conductive (for
example: Arctic Cooling MX-2 ™, MX-4 ™ or GELID GC-Extreme™) thermal grease on each phase regulator (that is being covered with thermal pad "2") in order to even
further improve the thermal performance of the EK-FC7850 series water block.
All disclosures, notices and warranty conditions are being written on the EKWB website. Please read terms of use.
Installation and mounting manual for EK-FC7850 water block
Sample picture of AMD Radeon HD 7850 graphics card (PCB 109-C40337-00)
Remove the stock GPU HSF assembly. Remove all
4. CUTTING THERMAL PADS.
Apply thermal
have to be cut to smaller chunks in order to cover all the VRM components such as MOSFETs and drivers. PLEASE
REMOVE THE PROTECTIVE FOIL FROM BOTH SIDES OF THE THERMAL PADS PRIOR TO INSTALLATION.
Replacement thermal pads @ EKWB web shop: Thermal Pad A – 1mm (100x16mm)
1: Thermal pad A – 1mm
(for memory IC):
1
Place thermal pads on chips so that numbers on chips match size of thermal pads. EKWB made sure users have more than
2
2. CLEANING THE PCB.
all screws securing it to the board. Wipe off the remains (by using non–abrasive
qtip
cloth or , as shown on sample photo) of the original thermal compound until
the components and circuit board are completely clean. EKWB recommends the
use of denatured alcohol for removing TIM leftovers.
Your block comes with thermal pads, some of which are already pre-cut. Others
1 1 1 1
1 1 1
1 1 1
1
1
1
1
1
www.ekwb.com

STEP 2: PREPARING YOUR GRAPHIC CARD.

1. REMOVING STOCK COOLER: Remove encircled screw on
the bracket (required only on certain models):
Carefully detach the original stock cooler after removing
2: Thermal pad A –1mm
(for VRM):
2
th
Released on 5
for updates. Before
of September, 2012.
