Ancona AN-1145 User Instructions

Glass canopy 30"

Advertisement

Quick Links

MODEL:
AN-1145
Glass Canopy 30"
IMPORTANT SAFETY INSTRUCTIONS
Carefully read the following important information regarding
installation safety and maintenance.
Keep these instructions for future reference.
11/19/2015 MAAN1145-02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AN-1145 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ancona AN-1145

  • Page 1 MODEL: AN-1145 Glass Canopy 30" IMPORTANT SAFETY INSTRUCTIONS Carefully read the following important information regarding installation safety and maintenance. Keep these instructions for future reference. 11/19/2015 MAAN1145-02...
  • Page 2: Important Safety Notice

    IMPORTANT SAFETY NOTICE READ AND SAVE THESE INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE INSTALLING AND OPERATING THIS APPLIANCE The installation in this manual is intended for qualified installers, service technicians or persons ● with similar qualified background. Installation and electrical wiring must be done by qualified professionals and in accordance with all applicable codes and standards, including fire-rated construction.
  • Page 3 IMPORTANT SAFETY NOTICE READ AND SAVE THESE INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE INSTALLING AND OPERATING THIS APPLIANCE WARNING: TO REDUCE RISK OF A RANGE TOP GREASE FIRE: a) Never leave surface units unattended at high settings. Boilovers cause smoking and greasy spillovers that may ignite.
  • Page 4: Parts Supplied

    PARTS SUPPLIED: 1 FILTER...
  • Page 5 VENTING REQUIREMENTS: HEIGHT & CLEARANCE: • Vent system must terminate to the outside (Roof or side wall). • DO NOT terminate the vent system in an attic or other enclosed area. • DO NOT use 4” (10.2 cm) laundry-type wall caps.
  • Page 6: Calculating Vent System Length

    IMPORTANT: • A minimum of 6” round or 3-1/4 x 10” rectangular duct (purchased separately) must be used to maintain maximum airflow efficiency. • Always use rigid type metal/aluminum ducts if available to maximize airflow when connecting to provided duct. •...
  • Page 7: Venting Methods

    VENTING METHODS: • This range hood is factory set for venting through the roof or wall. • Vent work can terminate either through the roof or wall. To vent through a wall, a 90° elbow is needed. IMPORTANT: NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, •...
  • Page 8: Electrical Requirements

    ELECTRICAL REQUIREMENTS: IMPORTANT: Observe all governing codes and ordinances. It is the customer’s responsibility to contact a qualified electrical installer. If codes permit and a separate ground wire is used, it is recommended that a qualified electrician determine that the ground path is adequate. A 120-Volt, 60 Hz, AC-only, fused electrical supply is required on a separate 15-amp circuit, fused on both sides of the line.
  • Page 9 PREPARATIONS: Advanced Preparations: • Be familiar with the controls of the range hood by reading through Range Hood Operations, Page 13. • Place the range hood on a flat, stable surface. Connect the range hood to a designated standard outlet (120-Volt, 60Hz, AC only) and turn on the range hood.
  • Page 10 INSTALLATION: INSTALLATION: Installations (refer to Page 4 for parts): Installations (refer to Page 4 for parts): NOTE: Use threaded drywall anchors only when NOTE: Use threaded drywall anchors only when mounting the hood on sheet rock. Mounting mounting the hood on sheet rock. Mounting the hood on wall studs or lumbars is highly the hood on wall studs or lumbars is highly recommended.
  • Page 11 INSTALLATION CONTINUE: Step 5: Installing the damper • Fix the damper on the top vent of hood with 4 screws (requires screw E). • If ventilation system is equipped with an external air duct with a different diameter, apply a reduction fitting. •...
  • Page 12 INSTALLATION CONTINUE: Step 7: Installing the decorative chimney and inner chimney bracket • Remove the protective coating from the inner chimney. Carefully slide the inner chimney down into the outer chimney. • Use 2 screws (requires screw F) to fix the two chimneys together with the lower chimney bracket, make sure inside chimney is moving freely.
  • Page 13: Control Panel Operation

    CONTROL PANEL OPERATION: Control Panel Layout and Buttons Configurations: Lights: Press the light button to turn halogen lights on and off. Power Settings: once the motor starts to operate at low speed. Press the Press the again and the motor will reach medium speed. once Press the again and the motor will reach high speed.
  • Page 14: Replacing The Bulbs

    REPLACING THE BULBS: Replacing the light bulbs: • This range hood uses halogen bulbs: 20W 12V type G4. • Make sure the range hood is unplugged or turn OFF breaker. • Place a flat-head screwdriver between light cover and housing to remove cover. •...
  • Page 15 6 2/5"(163mm) 11 7/8"(302mm) 11 1/4"(286mm) 11 3/4"(298mm) 9 1/16"(231mm) 4 1/2"(115mm) 4 1/2"(115mm) 1 5/8" 3 1/8"(82mm) 3 1/8"(82mm) (40mm) 1 1/8" 5/8"(16mm) (28mm) 9 15/16"(253mm)
  • Page 16 MEASUREMENTS AND DIAGRAMS: Height of range hood: 22.4” - 41.8” (569mm -1061mm). This range hood can reach a 9' ceiling if installed at 30.5" from the cooking surface. 10.8" 19.6" to 39" (275 mm) (500 mm to 992 mm) 2.72” 19.6”...
  • Page 17: Troubleshooting

    TROUBLE SHOOTING: 1) If the range hood or halogen light does not • Check if the range hood has been plugged in, operate after installation: make sure that all power has been turned back ON,fused not blown and all electrical wiring are properly connected.
  • Page 18: Range Hood Assembly

    RANGE HOOD ASSEMBLY: AL. Filter G4 Halogen light puck Switch panel Rubber strip Switch box Electronic switch Switch box cover Switch bracket Blower Propeller Motor Inlet grid Housing set Hook Outlet Power cord PCB box base PCB box cover Glass Outer chimney Outer chimney bracket Inner chimney...
  • Page 19: Specifications

    SPECIFICATIONS: Body design Stainless steel 120V / 60Hz (USA & Canada standard) cETLus Certified Power Rating Total input power 270W(230W + 2 x 20W) Motor Input Power 230W Total Ampere 2.2A (2.0A+2 x 0.1A) Levels of speed control 3 levels Radio frequency interference protected Interference Protection 400 CFM...
  • Page 20: Blower Assembly

    BLOWER ASSEMBLY: Description Description Incabloc Rubber Blower Aluminum Cover Wind Wheel Nut Plastic Wind Net Wind Wheel Sealing Gasket Motor ELECTRICAL ASSEMBLY: Description Description PCB box base Capacitor PCB box cover...
  • Page 21 USE AND CARE INFORMATION: Operations: • Read and understand all instructions and warnings in this manual before operating the appliance. Save these instructions for future reference. • Always leave safety grills and filters in place. Without these components, operating fans could catch on to hair, fingers and loose clothing.
