- Page 1 H3C S3600V2 Switch Series IRF Command Reference Hangzhou H3C Technologies Co., Ltd. http://www.h3c.com Software version: Release 2108 Document version: 6W100-20131130...
- Page 2 Copyright © 2013, Hangzhou H3C Technologies Co., Ltd. and its licensors All rights reserved No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of Hangzhou H3C Technologies Co., Ltd.
- Page 3 Preface The H3C S3600V2 documentation set includes 10 command references, which describe the commands and command syntax options available for the H3C S3600V2 Switch Series Release 2108. The IRF Command Reference describes IRF configuration commands for creating an IRF fabric. It covers the commands for binding physical ports to an IRF port, configuring the member switch ID and priority, and detecting and maintaining the IRF link.
- Page 4 Conventions This section describes the conventions used in this documentation set. Command conventions Convention Description Boldface Bold text represents commands and keywords that you enter literally as shown. Italic Italic text represents arguments that you replace with actual values. Square brackets enclose syntax choices (keywords or arguments) that are optional. Braces enclose a set of required syntax choices separated by vertical bars, from which { x | y | ...
- Page 5 Layer 2 forwarding and other Layer 2 features. Port numbering in examples The port numbers in this document are for illustration only and might be unavailable on your device. About the H3C S3600V2 documentation set The H3C S3600V2 documentation set includes: Category...
- Page 6 Obtaining documentation You can access the most up-to-date H3C product documentation on the World Wide Web at http://www.h3c.com. Click the links on the top navigation bar to obtain different categories of product documentation: [Technical Support & Documents > Technical Documents] –...
-
Page 7: Table Of Contents
Contents IRF configuration commands ······································································································································· 1 display irf ·································································································································································· 1 display irf configuration ··········································································································································· 2 display irf topology ·················································································································································· 3 display irf-port load-sharing mode ·························································································································· 4 display mad ······························································································································································ 6 display switchover state ··········································································································································· 8 ... -
Page 8: Irf Configuration Commands
IRF configuration commands display irf Syntax display irf [ | { begin | exclude | include } regular-expression ] View Any view Default level 1: Monitor level Parameters |: Filters command output by specifying a regular expression. For more information about regular expressions, see Fundamentals Configuration Guide. -
Page 9: Display Irf Configuration
Table 1 Command output Field Description IRF member ID: Switch • ID of the master is prefixed with an asterisk (*) sign. • ID of the device where you are logged in is prefixed with a plus (+) sign. Switch role in the IRF fabric: •... -
Page 10: Display Irf Topology
begin: Displays the first line that matches the specified regular expression and all lines that follow. exclude: Displays all lines that do not match the specified regular expression. include: Displays all lines that match the specified regular expression. regular-expression: Specifies a regular expression, a case-sensitive string of 1 to 256 characters. Description Use display irf configuration to display the basic IRF settings. -
Page 11: Display Irf-Port Load-Sharing Mode
Description Use display irf topology to display the IRF fabric topology. Command output includes member IDs, IRF port state, and adjacencies of IRF ports. Examples # Display the IRF fabric topology. <Sysname> display irf topology Topology Info ------------------------------------------------------------------------- IRF-Port1 IRF-Port2 Switch Link neighbor... - Page 12 member-id/port-number: Specifies an IRF port number. The member-id argument represents an IRF member ID. The port-number argument represents the index number (1 or 2) of the IRF port on the member device. |: Filters command output by specifying a regular expression. For more information about regular expressions, see Fundamentals Configuration Guide.
-
Page 13: Display Mad
destination-mac address, source-mac address irf-port 1/2 Load-Sharing Mode: Layer 2 traffic: packet type-based sharing Layer 3 traffic: packet type-based sharing Table 4 Command output Field Description Global load sharing mode for IRF links: • If no user-defined global load sharing mode has been irf-port Load-Sharing Mode configured, the default global load sharing mode applies. - Page 14 Description Use display mad to display MAD status and settings. Examples # Display brief MAD information. <Sysname> display mad MAD ARP disabled. MAD LACP disabled. MAD BFD disabled. # Display detailed MAD information. <Sysname> display mad verbose Current MAD status: Detect Excluded ports(configurable): Vlan-interface999 Excluded ports(can not be configured):...
-
Page 15: Display Switchover State
Field Description Vlan-interface3 mad ip address 192.168.2.2 VLAN interface used for BFD MAD, and the MAD IP address configured 255.255.0.0 member 1 for each member on this interface. mad ip address 192.168.2.3 255.255.0.0 member 2 display switchover state Syntax display switchover state [ slot member-id ] [ | { begin | exclude | include } regular-expression ] View Any view Default level... -
Page 16: Irf Auto-Update Enable
Field Description The subordinate switch is bulk-backing up data from Batch backup the master. The subordinate switch is backing up real-time data Realtime backup to slave from the master switch. The subordinate switch is transitioning to be the Data smooth master. -
Page 17: Irf Domain
To avoid an update failure, make sure the switch has efficient space for the new system software image. If the switch you are adding to the IRF fabric is incompatible with the software version running on the master, the software auto-update function cannot work correctly. If software auto-update function is disabled, you must manually update the switch with the system software image of the master. -
Page 18: Irf Mac-Address Persistent
Sets the IRF link down report delay in milliseconds. The value range is 0 to 10000. If your IRF fabric requires a fast master/subordinate or IRF link switchover or has deployed the BFD or GR feature, H3C recommends setting the delay to 0 seconds. Description Use irf link-delay to set the delay for the IRF ports in the IRF fabric to report a link down event. -
Page 19: Irf Member Description
Description Use irf mac-address persistent to configure IRF bridge MAC persistence so the IRF fabric continues to use the bridge MAC address of the old master as its bridge MAC address for a period of time after a master re-election. Use undo irf mac-address persistent to disable IRF bridge MAC persistence so the IRF fabric changes its bridge MAC address as soon as the master leaves. -
Page 20: Irf Member Priority
[Sysname] irf member 1 description F1Num001 irf member priority Syntax irf member member-id priority priority undo irf member member-id priority View System view Default level 3: Manage level Parameters member-id: Specifies an IRF member ID. priority: Sets priority in the range of 1 to 32. The greater the priority value, the higher the priority. A member with higher priority is more likely to be the master. -
Page 21: Irf Member Renumber
irf member renumber Syntax irf member member-id renumber new-member-id undo irf member member-id renumber View System view Default level 3: Manage level Parameters member-id: Specifies the current ID of an IRF member switch. The value range is 1 to 10. new-member-id: Assigns a new ID to the IRF member switch. -
Page 22: Irf Switch-To
# Cancel the change in the preceding example before rebooting the switch. [Sysname] irf member 2 renumber 2 Warning: Renumbering the switch number may result in configuration change or loss. Continue?[Y/N]y irf switch-to Syntax irf switch-to member-id View System view Default level 3: Manage level Parameters... -
Page 23: Irf-Port
irf-port Syntax irf-port member-id/port-number undo irf-port member-id/port-number View System view Default level 3: Manage level Parameters member-id/port-number: Specifies an IRF port number. The member-id argument represents the IRF member ID. The port-number argument represents the index of the port on the member switch, and must be 1 or 2. -
Page 24: Irf-Port-Configuration Active
Parameters destination-ip: Distributes traffic across IRF member links based on destination IP address. destination-mac: Distributes packets across IRF member links based on destination MAC address. source-ip: Distributes packets across IRF member links based on source IP address. source-mac: Distributes packets across IRF member links based on source MAC address. Description Use irf-port load-sharing mode to set the global or port-specific load sharing mode for IRF links. - Page 25 After connecting the physical ports between two switches and bind them to the correct IRF ports, you must use this command to activate the settings on the IRF ports to merge the two switches into one IRF fabric. After an IRF port is activated, its link state in the display irf topology command output changes from DIS or DOWN to UP.
-
Page 26: Mad Arp Enable
mad arp enable Syntax mad arp enable undo mad arp enable View VLAN interface view Default level 3: Manage level Parameters None Description Use mad arp enable to enable ARP MAD. Use undo mad arp enable to disable ARP MAD. By default, ARP MAD is disabled. -
Page 27: Mad Enable
View VLAN interface view Default level 3: Manage level Parameters None Description Use mad bfd enable to enable BFD MAD. Use undo mad bfd enable to disable BFD MAD. By default, BFD MAD is disabled. BFD MAD uses the BFD protocol for detecting multi-active collisions, and can work with or without intermediate devices. -
Page 28: Mad Exclude Interface
H3C device that also supports LACP MAD packets. When you use LACP MAD, follow these guidelines: The intermediate device must be an H3C device that support extended LACP for MAD. • If the intermediate device is in an IRF fabric, assign this fabric a different domain ID than the LACP •... -
Page 29: Mad Ip Address
IRF physical ports and those manually configured to not shut down. If a port must be kept in up state for special purposes such as Telnet connection, exclude it from the shutdown action. To avoid problems, H3C recommends not excluding any ports except the ports used for Telnet and MAD. -
Page 30: Mad Restore
By default, no MAD IP address is configured on any VLAN interface. To use BFD MAD, you must configure a MAD IP address on a BFD MAD enabled VLAN interface for each IRF member, and make sure all the MAD IP addresses are on the same subnet. To avoid problems, make sure a BFD MAD-enabled VLAN interface has only IP addresses assigned with the mad ip address command. -
Page 31: Port Group Interface
No restriction. Make sure the physical ports at both ends of an IRF link are using the same operating mode. For an aggregate IRF link, H3C recommends configuring the same operating mode for all physical IRF ports at both ends. - Page 32 Examples # Bind GigabitEthernet 3/0/25 to IRF port 3/1. <Sysname> system-view [Sysname] interface gigabitethernet 3/0/25 [Sysname-GigabitEthernet3/0/25] shutdown [Sysname-GigabitEthernet3/0/25] quit [Sysname] irf-port 3/1 [Sysname-irf-port3/1] port group interface gigabitethernet 3/0/25 [Sysname-irf-port3/1] quit [Sysname] interface gigabitethernet 3/0/25 [Sysname-GigabitEthernet3/0/25] undo shutdown...
-
Page 33: Index
Index D I M P irf member renumber,14 switch-to,15 display irf,1 irf-port,16 display irf configuration,2 irf-port load-sharing mode,16 display irf topology,3 irf-port-configuration active,17 display irf-port load-sharing mode,4 display mad,6 display switchover state,8 mad arp enable,19 mad bfd enable,19 enable,20 irf auto-update enable,9 mad exclude interface,21...
